± BODYSEAT BELT PRETENSIONER
BO±129
2477 Author: Date:
1. SEAT BELT PRETENSIONER DEPLOYMENT WHEN
SCRAPPING VEHICLE
HINT:
Have a battery ready as the power source to deploy the airbag.
(a) Check functioning of SST
CAUTION:
When deploying the seat belt pretensioner, always use the
specified SST: SRS Airbag Deployment Tool.
SST 09082±00700, 09082±00740
(1) Connect the SST to battery.
Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip to the battery neg-
ative (±) terminal.
HINT:
Do not connect the yellow connector which will be connected
with the seat belt pretensioner.
(2) Check functioning of SST
Press the SST activation switch, and check the LED
of the SST activation switch lights up.
CAUTION:
If the LED lights up when the activation switch is not being
pressed, SST malfunction is probable, so definitely do not
use the SST.
(b) Install the SST.
(1) Remove the front door scuff plate.
(2) Remove the center pillar lower garnish.
(3) Disconnect the pretensioner connector as shown in
the illustration.
(4) Buckle the front seat belt and check that there is no
looseness and slack in the front seat inner belt and
front seat outer belt.
SST 09082±00700, 09082±00740
Page 2090 of 4770

H01880
SST SST
R13455
10 m (33 ft) or more BO±130
± BODYSEAT BELT PRETENSIONER
2478 Author: Date:
(5) Connect the 2 SST, then connect them to the seat
belt pretensioner.
SST 09082±00700, 09082±00740
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of secondary lock of the
twin lock.
(6) Move the SST to at least 10mm (33 ft) from the front
of the vehicle.
(7) Close all the doors and windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(8) Connect the SST red clip the battery positive (±) ter-
minal and the black clip to the negative (+) terminal.
(c) Deploy the airbag.
(1) Confirm that no one is inside the vehicle or within 10
m (33 ft) area around of the vehicle.
(2) Press the SST activation switch and activate the
seat belt pretensioner.
HINT:
The seat belt pretensioner operates simultaneously as the LED
of the SST activation switch light up.
(d) Disposal of front seat outer belt (with seat belt pretension-
er).
CAUTION:
The front seat outer belt is very hot when the seat belt
pretensioner is deployed, so leave it alone for at least
30 minutes after deployment.
Use gloves and safety glasses when handling a front
seat outer belt with deployed seat belt pretensioner.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat outer belt with
deployed seat belt pretensioner.
When scrapping a vehicle, activate the seat belt preten-
sioner and scrap the vehicle with operated front seat out-
er belt still installed.
Page 2091 of 4770

AB0158
SSTBattery
H01880
SST SST
H01881SST SST
± BODYSEAT BELT PRETENSIONER
BO±131
2479 Author: Date:
2. DEPLOYMENT WHEN DISPOSING OF FRONT SEAT
OUTER BELT ONLY
NOTICE:
When disposing of the front seat outer belt (with seat
belt pretensioner) only, never use the customer's ve-
hicle to deploy the seat belt pretensioner.
Be sure to following the procedure given below when
deploying the seat belt pretensioner.
HINT:
Have a battery ready as the power source when deploying the
seat belt pretensioner.
(a) Remove the front seat outer belt
(See page BO±123)
HINT:
Cut the belt near the seat belt retractor.
(b) Check functioning of SST.
(See step 1±(a))
SST 09082±00700, 09082±00740
(c) Install the SST.
(1) Connect the 2 SST, then connect them to the seat
belt pretensioner.
SST 09082±00700, 09082±00740
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Locate the front seat outer belt on the ground and
cover it by the disc wheel with tire.
NOTICE:
Place the front seat outer belt shown in the illustration.
(3) Move the SST to as least 10 m (33 ft) from the disc
wheel.
NOTICE:
Take care not to damage the SST wire harness.
Page 2092 of 4770

R05181
10 m (33 ft) or more
H01882
BO±132
± BODYSEAT BELT PRETENSIONER
2480 Author: Date:
(d) Deploy the seat belt pretensioner.
(1) Connect the SST red clip to the battery positive (+)
terminal and black clip to the battery negative (±)
terminal.
(2) Check that no one is within 10 m (33 ft) area around
of the disc wheel.
(3) Press the SST activation switch and activate the
seat belt pretensioner.
HINT:
The seat belt pretensioner operates simultaneously as the LED
of the SST activation switch lights up.
(e) Disposal of front seat outer belt (with seat belt pretension-
er).
CAUTION:
The front seat outer belt is very hot when the seat belt
pretensioner is deployed, so leave it alone for at least
30 minutes after deployment.
Use gloves and safety glasses when handling a front
seat outer belt with deployed seat belt pretensioner.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat outer belt with
deployed seat belt pretensioner.
(1) Remove the disc wheel and SST.
(2) Place the front seat outer belt in a vinyl bag, tie the
end tightly and dispose of in it the same way as oth-
er general parts.
Page 2093 of 4770
BO0NK±01
± BODYSEAT BELT PRETENSIONER
BO±133
2481 Author: Date:
REPLACEMENT
REPLACE REQUIREMENTS
In the following cases, replace the seat belt pretensioner.
If the seat belt pretensioner has been activated.
If the seat belt pretensioner has been found to be faulty in troubleshooting.
If the front seat outer belt has been found to be faulty during the check in items 1±(b) or 2±(b).
If the front seat outer belt has been dropped.
CAUTION:
For removal and installation of the seat belt pretensioner, see page BO±126 and BO±134.
Be sure to follow the correct procedure.
Page 2094 of 4770

BO0NL±01
H01352
BO±134
± BODYSEAT BELT PRETENSIONER
2482 Author: Date:
INSTALLATION
NOTICE:
Never use seat belt pretensioner from another vehicle.
When replace parts, replace them with new parts.
1. INSTALL FRONT SEAT OUTER BELT
(a) Install the front seat belt parts by following the reverse or-
der of removal and torque the following bolts.
(1) Front seat outer belt retractor
Torque: 7.8 N´m (80 kgf´cm, 69 in.´lbf)
(2) Seat belt shoulder anchor
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(3) Seat belt floor anchor
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
NOTICE:
Make sure that the front seat outer belt is installed
with the specified torque.
If the front seat outer belt has been dropped, or there
are cracks, dents or other defects in the case or con-
nector, replace the front seat outer belt with a new
one.
When installing the front seat outer belt, take care that
the wiring does not interfere with other parts and is
not pinched between other parts.
(b) Connect the pretensioner connector as shown in the il-
lustration.
(c) w/ Seat Belt Warning:
Connect the retractor switch connector.
2. INSTALL THESE PARTS:
(a) Center pillar lower garnish
(b) Front door scuff plate
Page 2095 of 4770

BE09Y±01
± BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE±1
2221 Author: Date:
BODY ELECTRICAL SYSTEM
PRECAUTION
Take care to observe the following precautions when performing inspections or removal and replacement
of body electrical related parts.
1. HEADLIGHT SYSTEM
Halogen bulbs have pressurized gas inside and require special handling. They can burst if scratched
or dropped. Hold a bulb only by its plastic or metal case. Don't touch the glass part of a bulb with bare
hands.
2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
The CAMRY is equipped with an SRS (Supplemental Restraint System) such as the driver airbag and
front passenger airbag. Failure to carry out service operation in the correct sequence could cause the
SRS to unexpectedly deploy during servicing, possibly leading to a serious accident. Before servicing
(including removal or installation of parts, inspection or replacement), be sure to read the precaution-
ary notices in the RS section.
3. AUDIO SYSTEM
If the negative (±) terminal cable is disconnected from the battery, the preset AM, FM 1 and FM 2 sta-
tions stored in memory are erased, so make sure to note the stations and reset them after the negative
(±) terminal cable is reconnected to the battery.
If the negative (±) terminal cable is disconnected from the battery, the ºANTI±THEFT SYSTEMº will
operate when the cable is reconnected, but the radio, tape player and CD player will not operate. Be
sure to input the correct ID number so that the radio, tape player and CD player can be operated again.
4. MOBILE COMMUNICATION SYSTEM
If the vehicle is equipped with a mobile communication system, refer to precautions in the IN section.
Page 2096 of 4770

BE09Z±03
BE±2
± BODY ELECTRICALBODY ELECTRICAL SYSTEM
2222 Author: Date:
PROBLEM SYMPTOMS TABLE
