± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±677
912 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to LOOK, and wait at least for 20 se-
cond.
(b) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(c) Clear DTC stored in memory.
(See page DI±626)
(d) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(e) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(f) Check DTC.
(See page DI±626)
OK:
DTC B0110/43 is not output.
HINT:
Codes other than code B0110/43 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
For the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 3098 of 4770

W03859H02275H03247
Squib (RH)Airbag
Sensor
Assembly
SFR+ SFR±u" Sub Wire Harness
(±) (+)
W03859H02276H03248
Squib (RH)Airbag
Sensor
Assembly
SFR+ SFR±u" Sub Wire Harness
(±) (+)
DI±678
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
913 Author: Date:
5 Check sub wire harness.
PREPARATION:
(a) Disconnect sub wire harness connector on the airbag
sensor assembly side.
(b) Release the airbag activation prevention mechanism of
the sub wire harness connector on the airbag sensor as-
sembly side. (See page DI±626)
CHECK:
For the connector (on the sub wire harness side) between the
side airbag assembly and the sub wire harness, measure the
resistance between SFR+ and SFR±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace sub wire harness.
OK
6 Check harness between airbag sensor assembly and sub wire harness.
PREPARATION:
Release the airbag activation prevention mechanism of the air-
bag sensor assembly connector. (See page DI±626)
CHECK:
For the connector (on the sub wire harness side) between the
airbag sensor assembly and sub wire harness, measure the re-
sistance between SFR+ and SFR±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween airbag sensor assembly and sub wire
harness.
OK
For the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 3099 of 4770

H01019W03859H01180
Squib (RH)Airbag
Sensor
Assembly
(±) (+)
SFR+ SFR±
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±679
914 Author: Date:
DTC B0111/44 Open in Side Squib (RH) Circuit
(TMC Made)
CIRCUIT DESCRIPTION
The side squib circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0111/44 is recorded when an open is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0111/44
Open circuit in SFR+ wire harness or SFR± wire harness
of squib
Side squib (RH) malfunction
Airbag sensor assembly malfunctionSide airbag assembly (RH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI±670.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (RH) circuit.
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (RH) and the airbag sensor assembly,
measure the resistance between SFR+ and SFR±.
OK:
Resistance: Below 1 W
NG Repair or replace harness or connector be-
tween side airbag assembly (RH) and airbag
sensor assembly.
OK
DI1BA±03
Page 3100 of 4770

AB0118
R13006AB0119
H01020
W03860
H01070H01181
Squib (RH)Airbag
Sensor
Assembly
SFR+
E1 SFR±
TcACC
or
DTC B0111/44
ON " u
DLC1
DI±680
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
915 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR± of the con-
nector (on the side airbag assembly side) between the
side airbag assembly (RH) and the airbag sensor assem-
bly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0111/44 is not output.
HINT:
Codes other than code B0111/44 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 3101 of 4770

AB0118
R13006AB0119H01021
H01070H01182
"u
E1 TcACC ON
orAirbag
Sensor
Assembly Squib (RH)
DTC B0111/44 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±681
916 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0111/44 is not output.
HINT:
Codes other than code B0111/44 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 3102 of 4770

H02272W03859H02315
Squib (RH)Airbag
Sensor
Assembly
SFR+ SFR±
DI±682
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
917 Author: Date:
DTC B0111/44 Open in Side Squib (RH) Circuit
(TMMK Made)
CIRCUIT DESCRIPTION
The side squib circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0111/44 is recorded when an open is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0111/44
Open circuit in SFR+ wire harness or SFR± wire harness
of squib
Side squib (RH) malfunction
Airbag sensor assembly malfunctionSide airbag assembly (RH)
Airbag sensor assembly
Wire harness
Sub wire harness
WIRING DIAGRAM
See page DI±674.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (RH) circuit.
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (RH) and the airbag sensor assembly,
measure the resistance between SFR+ and SFR±.
OK:
Resistance: Below 1 W
NG Go to step 5.
OK
DI1L0±02
Page 3103 of 4770

AB0118
R13006AB0119W03860
H01070
H02273
H03249
Squib (RH)Airbag
Sensor
Assembly
SFR+
E1 SFR±
TcACC
or
DTC B0111/44
ON " u
DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±683
918 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR± of the con-
nector (on the side airbag assembly side) between the
side airbag assembly (RH) and the airbag sensor assem-
bly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0111/44 is not output.
HINT:
Codes other than code B0111/44 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 3104 of 4770

AB0118
R13006AB0119H01070
H02274
H03250
"u
E1 TcACC ON
orAirbag
Sensor
Assembly Squib (RH)
DTC B0111/44 DLC1
DI±684
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
919 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0111/44 is not output.
HINT:
Codes other than code B0111/44 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
