Page 665 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Braze BODY PANEL REPLACEMENTRE-43

Page 666 of 4770

TOYOTA CAMRY 2000 Service Repair Manual mm in. 50.20 INSTALLATION Butt Weld Body Sealer Butt Weld Body Sealer about 5 mm 1. Before temporarily installing the new parts, apply body sealer to the wheel arch. HINT: 1) Apply body sealer about 5

Page 667 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Braze 2. Temporarily install the new parts and check the fit of the luggage compartment door and rear combination light. BODY PANEL REPLACEMENTRE-45

Page 668 of 4770

TOYOTA CAMRY 2000 Service Repair Manual QUARTER WHEEL HOUSING OUTER PANEL (ASSY): Right Side REMOVAL (With the quarter panel removed.) Quarter Panel Outer Reinforcement Roof Side Outer Panel 1. After removing the roof side outer panel and q

Page 669 of 4770

TOYOTA CAMRY 2000 Service Repair Manual INSTALLATION Assembly Mark 2. Before welding the new parts, temporarily install the quarter panel and check the fit. 1. Determine the position of the new parts by the assembly marks of the inner and o

Page 670 of 4770

TOYOTA CAMRY 2000 Service Repair Manual QUARTER WHEEL HOUSING OUTER PANEL (ASSY): Left Side REMOVAL (With the quarter panel removed.) Quarter Panel Outer Reinforcement Roof Side Outer Panel 1. After removing the roof side outer panel and qu

Page 671 of 4770

TOYOTA CAMRY 2000 Service Repair Manual INSTALLATION Assembly Mark 1. Determine the position of the new parts by the assembly marks of the inner and outer panels.2. Before welding the new parts, temporarily install the quarter panel and che

Page 672 of 4770

TOYOTA CAMRY 2000 Service Repair Manual BODY LOWER BACK PANEL (ASSY) REMOVAL BODY PANEL REPLACEMENTRE-50
