Page 1105 of 4770

Genuine Toyota Chemicals
Toyota offers a complete line of products to help you keep
your Toyota looking and running like new. To safeguard your
vehicle’s appearance, you’ ll find everything from fabric spot
remover and glass cleaner to liquid car wash and touch- up paint.
When it’s time to get under the hood (or under the car), products
such as fuel injector cleaner, brake fluid and silicone spray will
help you get the job done. All of these products are formulated
specifically for use with Toyota vehicles, so you can be confident
you’re giving your vehicle the best care possible, inside and out.
Genuine Toyota Antifreeze Coolant
Genuine Toyota Long Life Antifreeze Coolant is the same
high quality, factory- fill product found in all new Toyotas. You’ ll
know it by its distinctive red color. It provides maximum protec-
tion and durability without the use of harmful silicates. And
because it’s compatible with non- metallic materials, it helps
extend the life of water- pump seals. Don’ t trust your engine
to anything less than the best: Genuine Toyota Long Life
Antifreeze Coolant.
Genuine Toyota Motor Oil
Your Toyota’s engine features highly advanced technology
to ensure superior performance, reliability and fuel economy.
Genuine Toyota Motor Oil is formulated with a special combi-
nation of lube- base stocks and an additive blend to maximize
the benefits of this technology. Make sure you’re getting the
most out of your engine by always putting the best into it:
Genuine Toyota Motor Oil.
Do-It-Yourself Products
TOYOTA MAINTENANCE & REPAIR SUPPORT13
Page 1106 of 4770

If you plan to perform your own maintenance or repairs on your
Toyota, be sure to check out your nearby Toyota Parts Center
(TPC). More than 475 Toyota dealerships now have a TPC,
which is an in- dealership parts store offering a wide selection
of automotive products. All TPCs feature a complete line of
Genuine Toyota maintenance parts and car- care products for
“do- it- yourselfers.”
In addition to Toyota maintenance and repair products, TPCs
offer free technical advice to Toyota owners who want to service
their own vehicles. You’ ll also find model- specific parts applica-
tion guides and how- to brochures covering most common
maintenance jobs. Both are provided to customers free of charge.
Toyota Parts Centers are open during regular dealership hours;
many also have extended evening and weekend hours. If you’re
a do- it- yourselfer, stop by and experience the service, selection
and value offered by your local TPC.
TOYOTA MAINTENANCE & REPAIR SUPPORT
Toyota Parts Centers
14
Page 1107 of 4770

If you’ ll be doing some of your own maintenance and repair work
on your vehicle, a Toyota service manual will be one of your most
valuable tools. Toyota offers three types of manuals to assist
do- it- yourselfers. To order any of the following manuals, call
Toyota’s service publications department at (800) 622- 2033.
Vehicle Repair Manual
This is the same manual used by professional technicians in Toyota
dealerships throughout the United States. It is fully illustrated and
includes maintenance and repair procedures for all vehicle mechan-
ical systems. It also includes instructions for vehicle tune- ups.
Electrical Systems Manual
This manual provides detailed wiring diagrams for each electri-
cal system in your vehicle, along with troubleshooting tips and
repair procedures.
Automatic Transmission/Transaxle Repair Manual
This manual includes complete procedures for overhauling the
automatic transmission/transaxle of your vehicle.For information on basic do- it- yourself maintenance items,
see the “General Maintenance and Care” and “Do- It-
Yourself Maintenance” sections of your
Owner’s Manual.
Toyota Service Manuals
TOYOTA MAINTENANCE & REPAIR SUPPORT15
Page 1108 of 4770

Vehicle Service Agreements
By covering the cost of repairs that are no longer covered by
warranty, a vehicle service agreement protects you from unex-
pected repair costs down the road. Many service agreements
also cover services such as towing and car rental that minimize
the inconvenience of a mechanical breakdown.
Through Genuine Toyota Financial Services, Toyota offers
service agreement plans to meet the needs of almost every
customer. Under these plans, repairs are made only by autho-
rized Toyota dealerships using Genuine Toyota Parts. This
means you always get original- equipment quality installed
by factory- trained technicians.
Your Toyota dealer can help you select the service agreement
plan that’s best for you. Be sure to request a plan from Genuine
Toyota Financial Services to get the highest level of quality,
service and peace of mind.
Pre-Paid Maintenance
An excellent way to ensure that your Toyota receives regular
maintenance — and to protect yourself from increases in vehicle
service costs — is to pay for maintenance services in advance.
Toyota offers pre- paid maintenance plans for both new and
used vehicles. Both plans cover oil- and- filter changes, lubrica-
tion of key chassis parts and a 19- point vehicle inspection. The
plans also include 24- hour roadside assistance, timed service
reminders and a computerized history of each service visit.
To meet differing customer needs, Toyota’s pre- paid mainte-
nance plans offer a variety of options for service intervals and
coverage length. Ask your Toyota dealer to help you select the
options that are best for you.
TOYOTA MAINTENANCE & REPAIR SUPPORT
Service Agreements & Pre-Paid Maintenance
16
Page 1109 of 4770

Determining the Proper
Maintenance Interval
Depending on your circumstances, you should obtain mainte-
nance for your Toyota every 5, 000 miles or every 7, 500 miles.
Follow these guidelines to determine which interval to use.
5,000-Mile Intervals
Use 5, 000- mile intervals if you primarily operate your vehicle
under any of the following conditions:
•Driving on unpaved or dusty roads.
•Towing a trailer or using a camper or car- top carrier.
•Repeated trips of less than five miles in temperatures
below freezing.
7,500-Mile Intervals
Use 7, 500- mile intervals if you primarily operate your vehicle
under conditions other than those listed above.
Following the Maintenance Log Charts
The Scheduled Maintenance Log identifies the maintenance
required at each mileage interval and corresponding time interval
based on mileage of 1, 250 miles per month. If you drive more than
1, 250 miles per month, you should obtain maintenance at the indi-
cated mileage interval rather than the indicated time interval.
If you choose 5,000- mile intervals, follow the maintenance
instructions shown below non- shaded headings such as this one:
5,000 Miles or 4 Months
If you choose 7, 500- mile intervals, follow the maintenance
instructions shown below shaded headings such as this one:
7, 500 Miles or 6 Months
At 15,000- mile increments, the 5,000- mile and 7, 500- mile
intervals coincide. Therefore, shaded and non- shaded headings
appear together, as in this example:
15,000 Miles or 12 Months
15,000 Miles or 12 Months
Determining Your Vehicle’s Maintenance Needs
SCHEDULED MAINTENANCE LOGS17
Page 1110 of 4770

SCHEDULED MAINTENANCE LOGS18
Determining Your Vehicle’s Maintenance Needs
Special Operating Conditions
In addition to standard maintenance items, the Scheduled
Maintenance Log indicates services that should be performed
on vehicles that are driven under especially demanding condi-
tions. Specific conditions require specific services, as indicated
below. The Scheduled Maintenance Log indicates at which
mileage/time intervals each service should be performed.
You should perform these additional maintenance services if
you drive
primarilyunder any of the conditions noted. If you
drive only occasionally under these conditions, it is not neces-
sary to perform the additional services.
Driving on Rough, Muddy or Snow-Melted Roads
•Rotate tires
•Inspect ball joints and dust cover
•Inspect brake linings/drums and brake pads/discs
•Inspect drive shaft boots
•Inspect nuts and bolts on chassis and body
•Inspect steering linkage
•Re- torque drive shaft flange bolts*
•Lubricate propeller shaft and re- torque bolts*
Driving on Salt-Covered Roads
•Lubricate propeller shaft and re- torque bolts*
Driving on Unpaved or Dusty Roads
•Inspect brake linings/drums and brake pads/discs
•Inspect or change engine air filter
•Lubricate propeller shaft and re- torque bolts *
Extensive Idling or Low-Speed Driving
for Long Distances
•Inspect brake linings/drums and brake pads/discs
* Applies to selected models. See the Scheduled Maintenance Log for details.
Page 1111 of 4770
SCHEDULED MAINTENANCE LOGS19 Towing a Trailer or Using a Camper
or Car-Top Carrier
•Inspect brake linings/drums and brake pads/discs
•Inspect nuts and bolts on chassis and body
•Replace differential oil
•Replace transmission fluid or oil
•Replace transfer oil *
•Lubricate propeller shaft and re- torque bolts*
Off-Road Maintenance
If you own a Land Cruiser or a four- wheel drive RAV4,
Tacoma or 4Runner, you should check the following items
daily whenever you drive off- road through deep sand, mud
or water:
•Brake lines and hoses
•Brake linings/drums and brake pads/discs
•Engine air filter
•Differential oil
•Steering linkage
•Transfer oil
•Transmission fluid or oil
•Wheel bearings
For all four- wheel drive vehicles except RAV4, you should
also lubricate the propeller shafts daily.
Determining Your Vehicle’s Maintenance Needs
Page 1112 of 4770

SCHEDULED MAINTENANCE LOGS20
The following descriptions are provided to give you a better
understanding of the maintenance items that should be per-
formed on your vehicle. The Scheduled Maintenance Log
indicates at which mileage/time intervals each item should be
performed. Please note that many maintenance items should be
performed only by a qualified technician.
For further information on maintenance items you can per-
form yourself, see the “General Maintenance and Care” and
“Do- It-Yourself Maintenance” sections of your
Owner’s Manual.
Automatic Transmission Fluid
or Manual Transmission Oil
Inspect each component for signs of leakage. If you discover any
leakage, have it repaired by a qualified technician immediately.
Ball Joints and Dust Covers
Check the suspension and steering linkage ball joints for loose-
ness and damage. Check all dust covers for deterioration and
damage. A qualified technician should perform these inspections.
Brake Lines and Hoses
Visually inspect for proper installation. Check for chafing,
cracks, deterioration and evidence of leaking. Replace any deteri-
orated or damaged parts immediately. A qualified technician
should perform these operations.
Explanation of Maintenance Items
