CAMRY - MAJOR TECHNICAL SPECIFICATIONS
5
10
15
20
25
30
35
40
45
50
55
60
65
70
U.S.A.
4-Door SedanCanada
LE XLE CE LE
5
MCV20L-CEMNKA MCV20L-A(C)EPNKA MCV20L-A(C)EPGKA SXV20L-AEMDKK SXV20L-AEPDKK S

Page 50 of 4770

TOYOTA CAMRY 2000 Service Repair Manual CAMRY - MAJOR TECHNICAL SPECIFICATIONS
1st Gear km / h (mph) Angle of Approach degrees
Angle of Departure degrees
ItemArea
Body Type
Vehicle Grade
Model Code
OverallLength mm (in.)
Width mm (in.)
Heig

CAMRY - MAJOR TECHNICAL SPECIFICATIONS
1st Gear km / h (mph) Angle of Approach degrees
Angle of Departure degrees
ItemArea
Body Type
Vehicle Grade
Model Code
OverallLength mm (in.)
Width mm (in.)
Height*
1mm (in.)
Wheel Base mm (in.)
TreadFront mm (in.)
Rear mm (in.)
Effective Head RoomFront mm (in.)
Rear mm (in.)
Front mm (in.)
Rear mm (in.)
Front mm (in.)
Rear mm (in.)
Front mm (in.)
Rear mm (in.) Effective Leg Room
Shoulder Room
Overhang
Min. Running Ground Clearance mm (in.)
Curb Weight
Gross Vehicle WeightFront kg (lb)
Rear kg (lb)
Total kg (lb)
Front kg (lb)
Rear kg (lb)
Total kg (lb)
Fuel Tank Capacity (US.gal., lmp.gal)
Luggage Compartment Capacity m
3 (cu.ft.)
Max. Speed km / h (mph)
Max. Cruising Speed km / h (mph)
Max. Permissible
Speed
Turning Diameter
(Outside Front)2nd Gear km / h (mph)
3rd Gear km / h (mph)
4th Gear km / h (mph)
Wall to Wall m (ft.)
Curb to Curb m (ft.)
Engine Type
Valve Mechanism
Bore x Stroke mm (in.)
Displacement cm
3 (cu.in.)
Compression Ratio
Carburetor Type
Research Octane No. RON
Max. Output (SAE-NET) kW / rpm (HP@rpm)
Max. Torque (SAE-NET) N
.m / rpm (lb-ft@rpm)
Battery Capacity (5HR) Voltage & Amp. hr.
Generator Output Watts
Starter Output kW
Clutch Type
Transaxle Type
Transmission Gear
Ratio
Differential Gear Ratio (Final)
Brake Type
Parking Brake Type
Brake Booster Type and Size in.
Proportioning Valve Type
Suspension Type
Stabilizer Bar
Steering Gear Type
Steering Gear Ratio (Overall)
Power Steering TypeIn First
In Second
In Third
In Fourth
In Fifth
In Reverse
Front
Rear
Front
Rear
Front
Rear
5
10
15
20
25
30
35
40
45
50
55
60
65
70
Major Dimensions & Vehicle Weights Performance Engine Engine
Chassis
Electrical
Canada
4-Door Sedan
CE LE
0 to 100 km / h sec.
0 to 400 m sec. Acceleration
Counter Gear RatioXLE
U.S.A.
6
MCV20L-AEPDKK MCV20L-AEPGKK SXV23L-AEPNCA
4790 (188.6)
1780 (70.1) 1785 (70.3) 1780 (70.1)
1420 (55.9)
2670 (105.1)
1545 (60.8)
1520 (59.8)
980 (38.6), 950 (37.4)*
2980 (38.6)
940 (37.0), 914 (36.0)*2940 (37.0)
1102 (43.4)
901 (35.5)
1427 (56.2)
1425 (56.1)
975 (38.4)
1145 (45.1)
135 (5.3)130 (5.1)
1616
1616
860 (1896) 920 (2028) 860 (1896)
540 (1190) 545 (1202) 595 (1312)
1400 (3086) 1465 (3230) 1455 (3208)
1040 (2290)970 (2140)
900 (1985)950 (2095)
1940 (4275)1920 (4235)
70 (18.5, 15.4)
135 (35.7, 29.2)*5, 43 (11.4, 9.5)*6
0.399 (14.1)0.332 m3 *7, 8.921 ft3 *8
210 (130)180 (112)
ÐÐ
ÐÐÐ
ÐÐÐ
70 (43)66 (41)
127 (79)119 (74)
ÐÐÐ
ÐÐÐ
11.9 (39.0)
11.4 (37.4)
1MZ-FE5S-FNE
24-Valve, DOHC16-Valve, DOHC
87.5 x 83.0 (3.44 x 3.27)87.0 x 91.0 (3.43 x 3.58)
2995 (182.7)2164 (132.0)
10.5 : 111.0 : 1
SFI
91 or higher130
143 / 5200 (192@5200)88 / 5200 (118@5200)
281 / 4400 (207@4400)178 / 2400 (131@2400)
12-55
960
1.4
ÐÐÐ
A541EA140E
2.8102.810
1.5491.549
1.0001.000
0.7350.706
ÐÐÐ
2.296
0.945
3.9334.176
Ventilated Disc
Solid DiscL.T. Drum
Drum
Tandem 8.5º + 8.5º
Dual-P Valve
MacPherson Strut
MacPherson Strut
STD
STD
Rack and Pinion
17.4 : 1
Integral Type
*
1: Unladed Vehicle *5: Water Volume
*2: With Moon Roof *6: Equivalent Gasoline Capacity
*3: Produced by TMC *7: VDA
*4: Produced by TMMK *8: SAE Suitcase

Page 51 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 5S±FE ENGINE
± 5S±FE ENGINEEG1±1

Page 52 of 4770

TOYOTA CAMRY 2000 Service Repair Manual DESCRIPTION
The 5S±FE engine is an in±line, 4±cylinder, 2.2 liter DOHC 16±valve engine.
ENGINE MECHANICAL
± 5S±FE ENGINEENGINE MECHANICALEG1±2

Page 53 of 4770

TOYOTA CAMRY 2000 Service Repair Manual The 5S±FE engine is an in±line, 4±cylinder engine with the cylinders numbered 1±2±3±4
from the front. The crankshaft is supported by five bearings inside the crankcase. These bearings
are made o

The 5S±FE engine is an in±line, 4±cylinder engine with the cylinders numbered 1±2±3±4
from the front. The crankshaft is supported by five bearings inside the crankcase. These bearings
are made of aluminum alloy.
The crankshaft is integrated with eight weights for balance. Oil holes are placed in the center of
the crankshaft to supply oil to the connecting rods, bearing, pistons and other components.
The firing order is 1±3±4±2. The cylinder head is made of aluminum alloy, with a cross flow
type intake and exhaust layout and with pent±roof type combustion chambers. The spark plugs
are located in the center of the combustion chambers.
The intake manifold has four independent long ports and utilizes the inertial supercharging effect
to improve engine torque at low and medium speeds.
Exhaust and intake valves are equipped with irregular pitch springs made of special valve spring
carbon steel which are capable of functioning no matter what the engine speed.
The intake camshaft is driven by a timing belt, and a gear on the intake camshaft engages with
a gear on the exhaust camshaft to drive it. The cam journal is supported at five places between
the valve lifters of each cylinder and on the front end of the cylinder head. Lubrication of the cam
journals and gears is accomplished by oil being supplied through the oiler port in the center of the
camshaft.
Adjustment of the valve clearance is done by means of an outer shim type system, in which valve
adjusting shims are located above the valve lifters. This permits replacement of the shims without
removal of the camshafts.
Pistons are made of high temperature±resistant aluminum alloy, and a depression is built into
the piston head to prevent interference with the valves.
Piston pins are the full±floating type, with the pins fastened to neither the piston boss nor the
connecting rods. Instead, snap rings are fitted on both ends of the pins, preventing the pins from
falling out.
The No.1 compression ring is made of steel and the No.2 compression ring is made of cast iron.
The oil ring is made of a combination of steel and stainless steel. The outer diameter of each
piston ring is slightly larger than the diameter of the piston and the flexibility of the rings allows
them to hug the cylinder walls when they are mounted on the piston. Compression rings No.1 and
No.2 work to prevent gas leakage from the cylinder and the oil ring works to scrape oil off the
cylinder walls to prevent it from entering the combustion chambers.
The cylinder block is made of cast iron. It has four cylinders which are approximately twice the
length of the piston stroke. The top of each cylinder is closed off by the cylinder head and the
lower end of the cylinders becomes the crankcase, in which the crankshaft is installed. In
addition, the cylinder block contains a water jacket, through which coolant is pumped to cool the
cylinders.
The oil pan is bolted onto the bottom of the cylinder block. The oil pan is an oil reservoir made of
pressed sheet steel. A dividing plate is included 'inside the oil pan to keep sufficient oil in the
bottom of the pan even when the vehicle is tilted. This dividing plate also prevents the oil from
making waves when the vehicle is stopped suddenly and the oil shifts away from the oil pump
suction pipe.
The 5S±FE engine uses two balance shafts. The balance shafts are fitted in balance shaft
housings that are located at the bottom of the cylinder block. The No. 1 balance shaft is driven by
the drive gear of the crankshaft No.3 counterweight at twice the speed of the crankshaft. The No.
2 balance shaft is driven by the No±1 balance shaft at the same speed in the same direction as the
crankshaft. The balance shafts are designed to eliminate secondary inertia force from the engine,
thereby reducing the engine noise (booming noise).
± 5S±FE ENGINEENGINE MECHANICALEG1±3

Page 54 of 4770

TOYOTA CAMRY 2000 Service Repair Manual PREPARATION
SST (SPECIAL SERVICE TOOLS)
09222±30010 Connecting Rod Bushing Remover
& Replacer09201±70010 Valve Guide Bushing Remover & Replacer
(09213±00060) Bolt set (09213�

Page 55 of 4770

TOYOTA CAMRY 2000 Service Repair Manual (09248±05011) Valve Lifter Press
(09248±05021) Valve Lifter Stopper
09226±10010 Crankshaft Front & Rear Bearing
Replacer
09616±30011 Steering Worm Bearing Adjusting
Screw Wrench09224±74010 Engine

Page 56 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Plug for vacuum hose, fuel hose
etc.
Battery specific gravity gauge09256±00030 Hose Plug Set
09904±00010 Expander Set
Piston ring compressorEngine tune±up tester Connecting rod aligner
Precision st
