Page 3593 of 4770

P12799
P12585
P12752
1011 12
1416
15
1 23 4
5
6
7 8
913
P12603
S06200
Joint Surface
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
EM±87
1373 Author: Date:
26. CHECK CRANKSHAFT THRUST CLEARANCE
Using a dial indicator, measure the thrust clearance while prying
the crankshaft back and forth with a screwdriver.
Standard thrust clearance:
0.04 ± 0.24 mm (0.0016 ± 0.0095 in.)
Maximum thrust clearance: 0.30 mm (0.0118 in.)
If the thrust clearance is greater than maximum, replace the
thrust washers as a set.
Thrust washer thickness:
1.930 ± 1.980 mm (0.0760 ± 0.0780 in.)
27. REMOVE MAIN BEARING CAPS AND CHECK OIL
CLEARANCE
(a) Uniformly loosen and remove the 8 main bearing cap
bolts and seal washers, in the several passes, in the se-
quence shown.
(b) Uniformly loosen and remove the 16 main bearing cap
bolts, in several passes, in the sequence shown.
(c) Using a screwdriver, pry out main bearing caps. Remove
the 4 main bearing caps, lower bearings and (No.2 main
bearing cap only) 2 lower thrust washers.
NOTICE:
Pull up the main bearing cap little by little to the right and
the left by turns and pay attention not to damage the joint
surface of the cylinder block and the main bearing cap.
HINT:
Keep the lower bearing and main bearing cap together.
Arrange the main bearing caps and lower thrust washers
in correct order.
Page 3594 of 4770

P12495
P12980
Plastigage
P12954
P12993
EM±88
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
1374 Author: Date:
(d) Lift out the crankshaft.
HINT:
Keep the upper bearings together with the cylinder block.
(e) Clean each main journal and bearing.
(f) Check each main journal and bearing for pitting and
scratches.
If the journal or bearing is damaged, replace the bearings. If
necessary, replace the crankshaft.
(g) Place the crankshaft on the cylinder block.
(h) Lay a strip of Plastigage across each journal.
(i) Install the 4 main bearing caps. (See page EM±101)
Torque:
12 pointed head bolts:
1st: 22 N´m (225 kgf´cm, 16 ft´lbf)
2nd: Turn extra 90°
Hexagon head bolts:
27 N´m (275 kgf´cm, 20 ft´lbf)
NOTICE:
Do not turn the crankshaft.
(j) Remove the main bearing caps. (See steps (a) to (c) )
(k) Measure the Plastigage at its widest point.
Standard oil clearance:
No.1 and No.4 journals0.014 ± 0.036 mm (0.0006 ± 0.0014 in.)
No.2 and No.3 journals0.026 ± 0.048 mm (0.0010 ± 0.0019 in.)
Maximum clearance:
No.1 and No.4 journals0.05 mm (0.0020 in.)
No.2 and No.3 journals0.06 mm (0.0024 in.)
If the oil clearance is greater than maximum, replace the bear-
ings. If necessary, replace the crankshaft.
Page 3595 of 4770

P12734
Number MarkNo.3
Number
MarkNo.4 No.2
No.1
No.3
No.4 No.2
No.1
Number Mark
EXAMPLE: Cylinder block º06º (A)
+ Crankshaft º08º (B)
= Total number 14 (Use bearing º5º) No.1 and No.4 journal bearings
Cylinder block (A)
Crankshaft (B)+
Total number º º: Number mark
0 ± 5 12 ± 176 ± 11 18 ± 23 24 ± 28
º3º º4º º5º º6º º7º Use bearing
EXAMPLE: Cylinder block º06º, Crankshaft º08º
= Use bearing º5º No.1 and No.4 journal standard bearings selection chart
Crankshaft
number markCylinder block number mark
00
01
02
03
04
05
06
07
08
09
10
11
1200 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
4
5 3
3
3
3
3
3
4
4
4
4
43
3
3
3
3
4
4
4
4
4
4
5
53
3
3
3
4
4
4
4
4
4
5
5
53
3
3
4
4
4
4
4
4
5
5
5
53
3
4
4
4
4
4
4
5
5
5
5
53
4
4
4
4
4
4
5
5
5
5
5
54
4
4
4
4
4
5
5
5
5
5
5
64
4
4
4
4
5
5
5
5
5
5
6
64
4
4
4
5
5
5
5
5
5
6
6
64
4
4
5
5
5
5
5
5
6
6
6
64
4
5
5
5
5
5
5
6
6
6
6
64
5
5
5
5
5
5
6
6
6
6
6
65
5
5
5
5
5
6
6
6
6
6
6
75
5
5
5
5
6
6
6
6
6
6
7
75
5
5
5
6
6
6
6
6
6
7
7
75
5
5
6
6
6
6
6
6
7
7
7
75
5
6
6
6
6
6
6
7
7
7
7
7
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
EM±89
1375 Author: Date:
HINT:
If using a bearing, replace it with one having the same number.
If the number of the bearing cannot be determined, select the
correct bearing by adding together the numbers imprinted on
the cylinder block and crankshaft, then refer to the table below
for the appropriate bearing number. The No.1 and No.4 journal
bearings have 5 standard bearing sizes, marked º3º, º4º, º5º, º6º
and º7º accordingly. The No.2 and No.3 journal bearings have
5 standard bearing sizes, marked º1º, º2º, º3º, º4º and º5º ac-
cordingly.
Page 3596 of 4770

EXAMPLE: Cylinder block º06º (A)
+ Crankshaft º08º (B)
= Total number 14 (Use bearing º3º) No.2 and No.3 journal bearings
Cylinder block (A)
Crankshaft (B)+
Total number º º: Number mark
0 ± 5 12 ± 176 ± 11 18 ± 23 24 ± 28
º1º º2º º3º º4º º5º Use bearing
EXAMPLE: Cylinder block º06º, Crankshaft º08º
= Use bearing º3º No.2 and No.3 journal standard bearings selection chart
Crankshaft
number markCylinder block number mark
00
01
02
03
04
05
06
07
08
09
10
11
1200 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
2
3 1
1
1
1
1
1
2
2
2
2
21
1
1
1
1
2
2
2
2
2
2
3
31
1
1
1
2
2
2
2
2
2
3
3
31
1
1
2
2
2
2
2
2
3
3
3
31
1
2
2
2
2
2
2
3
3
3
3
31
2
2
2
2
2
2
3
3
3
3
3
32
2
2
2
2
2
3
3
3
3
3
3
42
2
2
2
2
3
3
3
3
3
3
4
42
2
2
2
3
3
3
3
3
3
4
4
42
2
2
3
3
3
3
3
3
4
4
4
42
2
3
3
3
3
3
3
4
4
4
4
42
3
3
3
3
3
3
4
4
4
4
4
43
3
3
3
3
3
4
4
4
4
4
4
53
3
3
3
3
4
4
4
4
4
4
5
53
3
3
3
4
4
4
4
4
4
5
5
53
3
3
4
4
4
4
4
4
5
5
5
53
3
4
4
4
4
4
4
5
5
5
5
5 EM±90
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
1376 Author: Date:
Page 3597 of 4770

± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
EM±91
1377 Author: Date:
Reference
ItemMarkmm (in.)
Cylinder block main journal bore diameter
(A)º00º
º01º
º02º
º03º
º04º
º05º
º06º
º07º
º08º
º09º
º10º
º11º
º12º
º13º
º14º
º15º
º16º66.000 (2.5984)
66.001 (2.5985)
66.002 (2.5985)
66.003 (2.5985)
66.004 (2.5986)
66.005 (2.5986)
66.006 (2.5987)
66.007 (2.5987)
66.008 (2.5987)
66.009 (2.5988)
66.010 (2.5988)
66.011 (2.5989)
66.012 (2.5989)
66.013 (2.5989)
66.014 (2.5990)
66.015 (2.5990)
66.016 (2.5990)
Crankshaft main journal diameter (B)º00º
º01º
º02º
º03º
º04º
º05º
º06º
º07º
º08º
º09º
º10º
º11º
º12º61.000 (2.4016)
60.999 (2.4015)
60.998 (2.4015)
60.997 (2.4015)
60.996 (2.4014)
60.995 (2.4014)
60.994 (2.4013)
60.993 (2.4012)
60.992 (2.4012)
60.991 (2.4012)
60.990 (2.4012)
60.989 (2.4011)
60.988 (2.4011)
Standard bearing center wall thickness
(TMC made)º1º
º2º
º3º
º4º
º5º
º6º
º7º2.486 ± 2.489 (0.0979 ± 0.0980)
2.489 ± 2.492 (0.0980 ± 0.0981)
2.492 ± 2.495 (0.0981 ± 0.0982)
2.495 ± 2.498 (0.0982 ± 0.0983)
2.498 ± 2.501 (0.0983 ± 0.0985)
2.501 ± 2.504 (0.0985 ± 0.0986)
2.504 ± 2.507 (0.0986 ± 0.0987)
Standard bearing center wall thickness
(TMMK made)º1º
º2º
º3º
º4º
º5º
º6º
º7º2.485 ± 2.488 (0.0978 ± 0.0980)
2.488 ± 2.491 (0.0980 ± 0.0981)
2.491 ± 2.494 (0.0981 ± 0.0982)
2.494 ± 2.497 (0.0982 ± 0.0983)
2.497 ± 2.500 (0.0983 ± 0.0984)
2.500 ± 2.503 (0.0984 ± 0.0985)
2.503 ± 2.506 (0.0985 ± 0.0987)
(l) Completely remove the Plastigage.
28. REMOVE CRANKSHAFT
(a) Lift out the crankshaft.
(b) Remove the 4 upper main bearings and 2 upper thrust
washers from the cylinder block.
HINT:
Arrange the main bearing caps, bearings and thrust washers in
the correct order.
Page 3598 of 4770
P12404
P12405
P12403
P12416
60°C
P12415
EM±92
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
1378 Author: Date:
29. CHECK FIT BETWEEN PISTON AND PISTON PIN
Try to move the piston back and forth on the piston pin.
If any movement is felt, replace the piston and pin as a set.
30. REMOVE PISTON RINGS
(a) Using a piston ring expander, remove the 2 compression
rings.
(b) Remove the 2 side rails and oil ring by hand.
HINT:
Arrange the piston rings in the correct order only.
31. DISCONNECT CONNECTING ROD FROM PISTON
(a) Using a small screwdriver, pry out the 2 snap rings.
(b) Gradually heat the piston to approx. 60°C (140°F).
(c) Using a plastic±faced hammer and brass bar, lightly tap
out the piston pin and remove the connecting rod.
HINT:
The piston and pin are a matched set.
Arrange the pistons, pins, rings, connecting rods and
bearings in the correct order.
Page 3599 of 4770
EM0YS±01
P12499
Z09222
P12498
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
EM±93
1379 Author: Date:
INSPECTION
1. REMOVE GASKET MATERIAL
Using a gasket scraper, remove all the gasket material from the
top surface of the cylinder block.
2. CLEAN CYLINDER BLOCK
Using a soft brush and solvent, thoroughly clean the cylinder
block.
NOTICE:
If the cylinder is washed at high temperatures, the cylinder
liner sticks out beyond the cylinder block, so always wash
the cylinder block at a temperature of 45°C (113°F) or less.
3. INSPECT TOP SURFACE OF CYLINDER BLOCK FOR
FLATNESS
Using a precision straight edge and feeler gauge, measure the
surface contacting the cylinder head gasket for warpage.
Maximum warpage: 0.07 mm (0.0028 in.)
If warpage is greater than maximum, replace the cylinder block.
4. INSPECT CYLINDER FOR VERTICAL SCRATCHES
Visually check the cylinder for vertical scratches.
If deep scratches are present, replace the cylinder block.
Page 3600 of 4770

Z09220
1
Thrust
Direction
Axial
Direction 1
22
A
B
C10 mm
10 mm (0.39 in.)
(0.39 in.) Front
P12500
P12497
P12507
EM±94
± ENGINE MECHANICAL (1MZ±FE)CYLINDER BLOCK
1380 Author: Date:
5. INSPECT CYLINDER BORE DIAMETER
Using a cylinder gauge, measure the cylinder bore diameter at
positions A, B and C in the thrust and axial directions.
Standard diameter:
87.500 ± 87.512 mm (3.4449 ± 3.4453 in.)
Maximum diameter: 87.52 mm (3.4457 in.)
If the diameter is greater than maximum, replace the cylinder
block.
6. REMOVE CYLINDER RIDGE
If the wear is less than 0.2 mm (0.008 in.), using a ridge reamer,
grind the top of the cylinder.
7. INSPECT 12 POINTED HEAD MAIN BEARING CAP
BOLTS
Using vernier calipers, measure the tension portion diameter of
the bolt.
Standard diameter:
7.500 ± 7.600 mm (0.2953 ± 0.2992 in.)
Minimum diameter: 7.20 mm (0.2835 in.)
If the diameter is less than minimum, replace the bolt.
8. CLEAN PISTON
(a) Using a gasket scraper, remove the carbon from the pis-
ton top.
