TOYOTA CAMRY 2000 Service Repair Manual SEAT BELT EXTENDER: 98 ± 00 ± BO002±00 January 21, 2000
Page 6 of 7
Failure to follow the recommendations indicated below could result in less effectiveness
of the seat belt restraint system in c

SEAT BELT EXTENDER: '98 ± '00 ± BO002±00 January 21, 2000
Page 6 of 7
Failure to follow the recommendations indicated below could result in less effectiveness
of the seat belt restraint system in case of vehicle collision, causing personal injury.
The Seat Belt Extender must not be used:
A. By anyone other than for whom it was provided (name recorded on seat belt
extender).
B. In any vehicle and/or seat position other than the one for which it was provided.
C. When the Seat Belt Extender is provided for rear seat positions (with automatic
locking retractor), make sure the retractor is locked when in use.
If your seat belt cannot be fastened securely because it is not long enough, a
personalized seat belt extender is available from your Toyota dealer free of charge.
Please contact your local Toyota dealer so that the dealer can order the proper required
length for the extender. Bring the heaviest coat you expect to wear for proper
measurement and selection of length. Additional ordering information is available at your
Toyota dealer.
CAUTION:
When using the seat belt extender, observe the following. Failure to follow these
instructions could result in less effectiveness of the seat belt restraint system in case
of vehicle accident, increasing the chance of personal injury.
Never use the Seat Belt Extender if you can COMFORTABLY fasten the seat belt
without it.
The Seat Belt Extender must never be used with any child safety seats.
Remember that the extender provided for you may not be safe when used on a
different vehicle, or for another person or at a different seating position than the
one originally intended for.
To connect the extender to the seat
belt, insert the tab into the seat belt
buckle so that the ªPRESSº signs on
the buckle±release buttons of the
extender and the seat belt are both
facing outward as shown.
You will hear a click when the tab locks
into the buckle.
When releasing the seat belt, press on
the buckle±release button on the
extender, not
on the seat belt. This helps
prevent damage to the vehicle interior
and extender itself.
When not in use, remove the extender and store in the vehicle for future use.
Owner
Instructions
Seat Belt Extender
Seat Belt Release

Page 4442 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SEAT BELT EXTENDER: 98 ± 00 ± BO002±00 January 21, 2000
Page 7 of 7
SEAT BELT EXTENDER WORKSHEET
PLEASE COPY THIS ORIGINAL WORKSHEET FOR EACH EXTENDER NEEDED
CAUTIONS:
�To minimize the chance and

SEAT BELT EXTENDER: '98 ± '00 ± BO002±00 January 21, 2000
Page 7 of 7
SEAT BELT EXTENDER WORKSHEET
PLEASE COPY THIS ORIGINAL WORKSHEET FOR EACH EXTENDER NEEDED
CAUTIONS:
To minimize the chance and/or severity of injury in an accident, the seat belt
extender must only be used:
1 By the person for whom it was provided
2 In the seat position for which it was provided
The seat belt extender must never be used with any child safety seats.
When the seat belt extender is provided for rear seat positions (with automatic
locking retractor), make sure the retractor is locked when extender belt is in use.
DEALERSEAT BELT EXTENDER APPLICATIONAPPLICANT
DEALER CODEDEALER NAMEAPPLICANT NAME
ADDRESSADDRESS
CITY & STATEZIPCITY & STATEZIPPHONE
EMPLOYEE NAMEMODEL YEARBODY TYPESEATING POSITIONVEHICLE IDENTIFICATION NUMBER
DIRECTIONS FOR DETERMINING PROPER EXTENDER LENGTH
1.Place the seat in the position the applicant normally uses
2.With applicant in the seat, wearing thickest coat expected to be worn, pull belt all the way out and try to buckle
belt
If the belt latches into buckle and feels comfortable against upper chest area, an extender is not needed.
If belt does not buckle continue with step 3
If buckle latches but belt has no slack remaining, continue with step 3
3.Measure distance between applicant's navel and seat belt buckle (dimension A) and enter on worksheet
4.With belt all the way out, measure distance between latch tip and buckle tip (dimension B) and enter on
worksheet
NOTE: If belt latches but there is no slack enter zero as dimension B
5.Subtract dimension B from dimension A and record number in check number box on worksheet
6.Seat belt extender length is dimension B rounded up to next extender length (without exceeding check number)
NOTE: If extender length exceeds check number, an extender can not be provided to the
customer
Dimension A:
NAVEL TO BUCKLEDimension B:
LATCH TO BUCKLE
BuckleBuckle NavelLatch
A
B
SEAT BELT EXTENDER CALCULATION
DIMENSION A:DIMENSION B:CHECK NUMBER:
SEAT BELT EXTENDER AUTHORIZATION
The same seat belt extender can be used for right and left seating applications. Each seat belt extender will have
a label identifying the owner, VIN and seating position. Seat belt extenders are available only in black.
Applicant's Signature: _________________________________________ Date: ______________________
(Actual user of seat belt extender)

Page 4443 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 7
BO002-01Title:
SEAT BELT EXTENDER
Models:
99 ± 01 Model Year
Technical Service
BULLETIN
January 26, 2001

TSB UPDATE NOTICE:
The information contained

Toyota Supports ASE CertificationPage 1 of 7
BO002-01Title:
SEAT BELT EXTENDER
Models:
'99 ± '01 Model Year
Technical Service
BULLETIN
January 26, 2001

TSB UPDATE NOTICE:
The information contained in this TSB updates BO020±00 dated August 11, 2000.
Revised text is red
and underlined.
Toyota customers who find it necessary to
increase the length of their seat belts may obtain
Seat Belt Extenders at no cost through their local
Toyota dealer.
The extender is available in 6 inch,
9 inch, 12 inch, 15 inch and 18 inch lengths.
The extender is available only in black.
Owners are informed of the Seat Belt Extender
availability through the Toyota Owner's Manual
included in each vehicle.
The customer (individual requiring the extender) must visit a Toyota dealership to have
the required measurements made and to complete the Seat Belt Extender worksheet.
The worksheet will allow the proper fitting and selection of a Seat Belt Extender for the
customer. The dealership personnel should then determine the applicable part number
and place a
Critical Order through the TDN Parts Network.
The dealership service department should complete the affixed Seat Belt Extender
Customer Information Label and review the ªOwner Instruction Sheetº with the customer.
The dealership should give a copy of the completed worksheet to the customer and keep
the original in the customer's file.
To assure utmost owner satisfaction, it is recommended that a dealership designate one
person to coordinate all activities related to the Seat Belt Extender issue.
It is recommended that dealerships do not
stock Seat Belt Extenders due to the need
for proper fitting to individual customers.
This bulletin contains the following information:
Procedure and Sample Label Page 2. . . . . . . . . .
Application Charts Pages 3±4. . . . . . . . . . . . . . . . . . . .
Part Number Information Page 5. . . . . . . . . . . . . .
Owner Instructions Page 6. . . . . . . . . . . . . . . . . . .
Seat Belt Extender Worksheet Page 7. . . . . . . . .
1999 through 2001 model year Toyota vehicles.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
BODY
Introduction
Seat Belt
Extender
Applicable
Vehicles
Warranty
Information

Page 4444 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SEAT BELT EXTENDER: 99±01 MODEL YEAR ± BO002-01 January 26, 2001
Page 2 of 7
1. Owner requests a Seat Belt Extender from dealer.
2. Dealer verifies the need for a Seat Belt Extender and obtains a

Page 4445 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Page 3 of 7 FRONT SEAT ± EXTENDER APPLICATION
MODELTYPE010099
RAV4±R±5R±5R±5
ECHO±K±5K±5±
COROLLATMMC PRODUCTIONQ±4Q±4Q±4COROLLANUMMI PRODUCTIONQ±4Q±4Q±4
PRIUS±N±7±±
MR2 SPYDER±

Page 4446 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SEAT BELT EXTENDER: 99±01 MODEL YEAR ± BO002-01 January 26, 2001
Page 4 of 7REAR SEAT ± EXTENDER APPLICATION
MODELTYPE010099
RAV4W/TOKAI RIKAR±5R±5*1R±5*1
RAV4W/QSS±Q±4*2Q±4*2
ECHO±R±5

Page 4447 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Page 5 of 7 PART NUMBER PREFIX: 73399±
SERIESLENGTHSERIES6 INCH9 INCH12 INCH15 INCH18 INCH
R±5±16060±16070±16080±16090±16100
N±1±12060±12070±12080±12090±12100
N±5±20110±20120±20130±2

Page 4448 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SEAT BELT EXTENDER: 99±01 MODEL YEAR ± BO002-01 January 26, 2001
Page 6 of 7
Failure to follow the recommendations indicated below could result in reduced
effectiveness of the seat belt restraint

SEAT BELT EXTENDER: '99±'01 MODEL YEAR ± BO002-01 January 26, 2001
Page 6 of 7
Failure to follow the recommendations indicated below could result in reduced
effectiveness of the seat belt restraint system in case of vehicle collision, causing
personal injury.
The Seat Belt Extender must not be used:
a. By anyone other than for whom it was provided (name recorded on seat belt
extender).
b. In any vehicle and/or seat position other than the one for which it was provided.
c. When the Seat Belt Extender is provided for rear seat positions (with automatic
locking retractor), make sure the retractor is locked when in use.
If your seat belt cannot be fastened securely because it is not long enough, a
personalized Seat Belt Extender is available from your Toyota dealer free of charge.
Please contact your local Toyota dealer so that the dealer can order the proper required
length for the extender. Bring the heaviest coat you expect to wear for proper
measurement and selection of length. Additional ordering information is available at your
Toyota dealer.
CAUTION:
When using the Seat Belt Extender, observe the following. Failure to follow these
instructions could result in reduced effectiveness of the seat belt restraint system in
case of vehicle accident, increasing the chance of personal injury.
Never use the Seat Belt Extender if you can COMFORTABLY fasten the seat belt
without it.
The Seat Belt Extender must never be used with any child safety seats.
Remember that the extender provided for you may not be safe when used on a
different vehicle, or for another person or at a different seating position than the
one originally intended for.
To connect the extender to the seat
belt, insert the tab into the seat belt
buckle so that the ªPRESSº signs on
the buckle-release buttons of the
extender and the seat belt are both
facing outward as shown.
You will hear a click when the tab locks
into the buckle.
When releasing the seat belt, press on
the buckle-release button on the
extender, not
on the seat belt. This helps
prevent damage to the vehicle interior
and extender itself.
When not in use, remove the extender
and store in the vehicle for future use.
Owner
Instructions
Seat Belt ExtenderSeat Belt Release
