Page 4449 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Page 7 of 7
PLEASE COPY THIS ORIGINAL WORKSHEET FOR EACH EXTENDER NEEDED
CAUTIONS:
�To minimize the chance and/or severity of injury in an accident, the Seat Belt Extender must only be used:
1 By the

Page 7 of 7
PLEASE COPY THIS ORIGINAL WORKSHEET FOR EACH EXTENDER NEEDED
CAUTIONS:
To minimize the chance and/or severity of injury in an accident, the Seat Belt Extender must only be used:
1 By the person for whom it was provided.
2 In the seat position for which it was provided.
The Seat Belt Extender must never be used with any child safety seats.
When the Seat Belt Extender is provided for rear seat positions (with automatic locking retractor),
make sure the retractor is locked when extender belt is in use.
DEALER
SEAT BELT EXTENDER APPLICATIONAPPLICANT
DEALER
CODEDEALER
NAMEAPPLICANT
NAME
ADDRESSADDRESS
CITY
&
STATEZIPCITY
&
STATEZIPPHONE
EMPLOYEE
NAMEMODEL
YEARBODY
TYPESEATING
POSITIONVEHICLE
IDENTIFICATION
NUMBER
DIRECTIONS FOR DETERMINING PROPER EXTENDER LENGTH
1. Place the seat in the position the applicant normally uses.
2. With the applicant in the seat, wearing the thickest coat expected to be worn, pull belt all the way out
and try to buckle belt.
If belt latches into buckle and feels comfortable against upper chest area, an extender is not needed.
If belt does not buckle, continue with Step 3.
If buckle latches but belt has no slack remaining, continue with Step 3.
3. Measure distance between applicant's navel and seat belt buckle (Dimension A) and enter on Worksheet.
4. With belt all the way out, measure distance between latch tip and buckle tip (Dimension B) and enter
on Worksheet.
NOTE: If belt latches but there is no slack enter zero as Dimension B.
5. Subtract Dimension B from Dimension A and record number in Check Number box on Worksheet.
6. Seat Belt Extender length is Dimension B rounded up to next extender length (without exceeding
Check Number).
NOTE: If extender length exceeds Check Number, an extender cannot
be provided to the customer.
Dimension A:
NAVEL TO BUCKLEDimension B:
LATCH TO BUCKLE
BuckleNavel
ABuckle
Latch
B
SEAT BELT EXTENDER CALCULATION
DIMENSION
A:DIMENSION
B:CHECK
NUMBER:
SEAT BELT EXTENDER AUTHORIZATION
The same Seat Belt Extender can be used for right and left seating applications. Each Seat Belt
Extender will have a label identifying the owner, VIN and seating position. Seat Belt Extenders are
available only in black.
Applicant's Signature:
Date:
(Actual user of seat belt extender)

Page 4450 of 4770

TOYOTA CAMRY 2000 Service Repair Manual TSB
IntroductionA kit containing special foam sponge material has been developed. This kit, when used
in conjunction with procedures outlined in the Wind Noise Service Information book
(P/N 00401

Page 4451 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1
BO005±99
Title:
CAMRY CENTER CONSOLE LATCH
IMPROVEMENTS
Models:
97±99 Camry
Technical Service
BULLETIN
March 26, 1999

The center console compartment

Page 4452 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1
BO007±99
Title:
TMMK CAMRY/SIENNA HEADLIGHT
ALIGNMENT
Models:
97±99 Camry, 98±99 Sienna
Technical Service
BULLETIN
April 16, 1999

To enhance head

Page 4453 of 4770

TOYOTA CAMRY 2000 Service Repair Manual On some Toyota models, when Rapgard is removed from the vehicle, a stain is left on the paint
surface. This stain can be seen under the clear coat and is not a defect of the clear coat. The
stain co

Page 4454 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1
BO009±00
Title:
LOOSE CENTER HVAC VENT
ADJUSTMENT
Models:
98 ± 99 CBU Camry
Technical Service
BULLETIN
April 28, 2000

TSB Revision Notice:
The infor

Page 4455 of 4770

TOYOTA CAMRY 2000 Service Repair Manual The following procedures explain in detail how to install the 1997 Camry Door Mirrors.
CAUTION:Should the door mirror be installed incorrectly, a wind noise (air leakage noise)
might be generated.

Page 4456 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 1997 CAMRY DOOR MIRROR INSTALLATIONPage 2 of 2
INSTALLATION PROCEDURES (Contd):
4. Tighten the three mirror mounting nuts A , B
and C for vehicles without a tweeter.
Torque: 5.5 N.m (56 kgf.cm, 49 in
