Maintenance Log.
. SUVs & Tacoma
SCHEDULED MAINTENANCE LOGS53
105,000 Miles or 84 Months
❑Replace engine oil and oil filter
❑Rotate tires
❑Lubricate propeller shaft and re-torque bolts (all 4WD except RAV4)
❑Re-torque drive shaft flange bolts (all 4WD except Land Cruiser)
❑Inspect the following:__
Automatic transmission fluid__
Differential oil
__
Ball joints and dust covers__
Drive shaft boots
__
Brake lines and hoses__
Exhaust pipes and mountings
__
Brake linings/drums and brake pads/discs__
Steering gear box
__
Limited-slip differential oil__
Steering linkage
(Land Cruiser, 4WD RAV4)
1
Additional Maintenance Items for Special Operating Conditions:*
❑Inspect engine air filter
❑Inspect nuts and bolts on chassis and body
❑Replace automatic transmission fluid
❑Replace differential oil (including limited-slip)
Date: __________________
Mileage: _______________
105,000 Miles or 84 Months
105,000 Miles or 84 Months
DEALER SERVICE VERIFICATION
Page 1146 of 4770

Maintenance Log.
. SUVs & Tacoma
SCHEDULED MAINTENANCE LOGS54
110,000 Miles or 88 Months
❑Replace engine oil and oil filter
Additional Maintenance Items for Special Operating Conditions:*
❑Inspect the following:__
Ball joints and dust covers__
Engine air filter
__
Brake linings/drums and brake pads/discs__
Nuts and bolts on chassis and body
__
Drive shaft boots__
Steering linkage
❑Rotate tires❑Lubricate propeller shaft and re-torque bolts (all 4WD except RAV4)❑Re-torque drive shaft flange bolts (all 4WD except Land Cruiser)
Date:
Mileage:
115,000 Miles or 92 Months
❑Replace engine oil and oil filter
Additional Maintenance Items for Special Operating Conditions:*
❑Inspect the following:__
Ball joints and dust covers__
Engine air filter
__
Brake linings/drums and brake pads/discs__
Nuts and bolts on chassis and body
__
Drive shaft boots__
Steering linkage
❑Rotate tires❑Lubricate propeller shaft and re-torque bolts (all 4WD except RAV4)❑Re-torque drive shaft flange bolts (all 4WD except Land Cruiser)
Date:
Mileage:
❑Replace engine oil and oil filter
❑Rotate tiresDate:
Mileage:
112,500 Miles or 90 Months*
DEALER SERVICE VERIFICATIONDEALER SERVICE VERIFICATION
DEALER SERVICE VERIFICATION
5,000-Mile Maintenance Intervals
7,500-Mile Maintenance Intervals
To determine the appropriate
maintenance interval for your vehicle,
see page 17.
* Specific services apply to specific operating conditions. See pages 18–19 for details.
Page 1147 of 4770

Maintenance Log.
. SUVs & Tacoma
SCHEDULED MAINTENANCE LOGS55
120,000 Miles or 96 Months
❑Replace engine air filter❑Replace engine coolant❑Replace engine oil and oil filter❑Rotate tires❑Replace limited-slip differential oil (Land Cruiser, RAV4 4WD)1
❑Replace platinum spark plugs (RAV4)2
❑Replace non-platinum spark plugs (Tacoma, 4Runner)2
❑Repack front wheel bearings (Tacoma 2WD)❑Lubricate propeller shaft and re-torque bolts (all 4WD except RAV4)❑Lubricate drive shaft bushings (4WD Tacoma without ADD)❑Re-torque drive shaft flange bolts (all 4WD except Land Cruiser)❑Inspect the following:__
Ball joints and dust covers__
Engine valves
__
Brake lines and hoses__
Exhaust pipes and mountings
__
Brake linings/drums and brake pads/discs__
Fuel tank cap gasket
__
Charcoal canister
3__
Steering gear box
__
Differential oil__
Steering linkage
__
Drive belts__
Transfer case oil (4WD models)
__
Drive shaft boots__
Transmission fluid or oil
__
Fuel lines and connections, fuel tank band
and fuel tank vapor vent system hoses
Additional Maintenance Items for Special Operating Conditions:*❑Inspect nuts and bolts on body and chassis❑Replace differential oil❑Replace transfer case oil (4WD models)❑Replace transmission fluid or oil
Date: __________________
Mileage: _______________
120,000 Miles or 96 Months
120,000 Miles or 96 Months
120 Months
DEALER SERVICE VERIFICATION
120 Months
❑Inspect SRS Air Bag
Date: __________________
Mileage: _______________
DEALER SERVICE VERIFICATION
1If vehicle is equipped with limited-slip differential.2Required under the terms of the Emission Control Warranty.
3Inspect at 120,000 miles or 144 months, whichever comes first.
Required only for vehicles in California, Massachusetts and New York.
Page 1148 of 4770
Vehicle Identification
SCHEDULED MAINTENANCE LOGS56
Model
Body style
Model year
In-service dateMileage at delivery
Key number
Selling dealership
Selling dealership phone number
Vehicle identification number
Page 1149 of 4770
00400-01999-SMG1Printed in U.S.A.
6/98
www.toyota.com
Page 1150 of 4770
NOTICE
When handling supplemental restraint system components (removal,
installation or inspection, etc.), always follow the direction given in the repair
manuals listed above to prevent accidents and supplemental restraint
system malfunction.
FOREWORD
This wiring diagram manual has been prepared to provide
information on the electrical system of the 1999 CAMRY.
Applicable models: MCV20 Series
SXV20 Series
For service specifications and repair procedures of the above
models other than those listed in this manual, refer to the
following manuals;
Manual Name
Pub. No.
1999 CAMRY Repair Manual
Volume 1
Volume 2
1999 TOYOTA New Car Features
RM654U1
RM654U2
NCF160U
All information in this manual is based on the latest product
information at the time of publication. However, specifications
and procedures are subject to change without notice.
Page 1151 of 4770

A INTRODUCTION
This manual consists of the following 12 sections:
No.
SectionDescription
A
INDEXIndex of the contents of this manual.
A
INTRODUCTIONBrief explanation of each section.
BHOW TO USE THIS
MANUALInstructions on how to use this manual.
CTROUBLE±
SHOOTINGDescribes the basic inspection procedures for electrical circuits.
DABBREVIATIONSDefines the abbreviations used in this manual.
E
GLOSSARY OF
TERMS AND
SYMBOLS
Defines the symbols and functions of major parts.
FRELAY LOCATIONSShows position of the Electronic Control Unit, Relays, Relay Block, etc.
This section is closely related to the system circuit.
GELECTRICAL
WIRING ROUTINGDescribes position of Parts Connectors, Splice points, Ground points, etc.
This section is closely related to the system circuit.
INDEXIndex of the system circuits.
H
SYSTEM CIRCUITS
Electrical circuits of each system are shown from the power supply through ground
points. Wiring connections and their positions are shown and classified by code
according to the connection method. (Refer to the section, ºHow to use this manualº).
The ºSystem Outlineº and ºService Hintsº useful for troubleshooting are also contained
in this section.
IGROUND POINTSShows ground positions of all parts described in this manual.
J
OVERALL
ELECTRICAL
WIRING DIAGRAM
Provides circuit diagrams showing the circuit connections.
KPOWER SOURCE
(Current Flow Chart)Describes power distribution from the power supply to various electrical loads.
LPART NUMBER OF
CONNECTORSIndicates the part number of the connectors used in this manual.
Page 1152 of 4770

HOW TO USE THIS MANUAL B
This manual provides information on the electrical circuits installed on vehicles by
dividing them into a circuit for each system.
The actual wiring of each system circuit is shown from the point where the power
source is received from the battery as far as each ground point. (All circuit
diagrams are shown with the switches in the OFF position.)
When troubleshooting any problem, first understand the operation of the circuit
where the problem was detected (see System Circuit section), the power source
supplying power to that circuit (see Power Source section), and the ground points
(see Ground Points section). See the System Outline to understand the circuit
operation.
When the circuit operation is understood, begin troubleshooting of the problem
circuit to isolate the cause. Use Relay Location and Electrical Wiring Routing
sections to find each part, junction block and wiring harness connectors, wiring
harness and wiring harness connectors, splice points, and ground points of each
system circuit. Internal wiring for each junction block is also provided for better
understanding of connection within a junction block.
Wiring related to each system is indicated in each system circuit by arrows
(from__, to__). When overall connections are required, see the Overall Electrical
Wiring Diagram at the end of this manual.
