Page 3665 of 4770
IG02I±03
S04720
± IGNITION (1MZ±FE)IGNITION COIL
IG±7
1701 Author: Date:
IGNITION COIL
REMOVAL
1. DISCONNECT HIGH±TENSION CORDS FROM
IGNITION COILS (See page IG±1)
2. REMOVE IGNITION COILS
(a) Disconnect the 3 connectors from the ignition coil.
(b) Remove the 3 bolts and 3 ignition coils from the LH cylin-
der head.
Torque: 8 N´m (80 kgf´cm, 69 in.´lbf)
HINT:
Arrange the ignition coils in correct order.
Page 3666 of 4770
IG02J±01
IG±8
± IGNITION (1MZ±FE)IGNITION COIL
1702 Author: Date:
INSTALLATION
Installation is in the reverse order of removal. (See page IG±7)
Page 3667 of 4770
S04589
IG02K±03
± IGNITION (1MZ±FE)CAMSHAFT POSITION SENSOR
IG±9
1703 Author: Date:
CAMSHAFT POSITION SENSOR
REMOVAL
REMOVE CAMSHAFT POSITION SENSOR
(a) Disconnect the camshaft position sensor connector.
(b) Remove the 2 bolts and camshaft position sensor.
Torque: 8 N´m (80 kgf´cm, 69 in.´lbf)
Page 3668 of 4770
IG02L±01
IG±10
± IGNITION (1MZ±FE)CAMSHAFT POSITION SENSOR
1704 Author: Date:
INSTALLATION
Installation is in the reverse order of removal. (See page IG±9)
Page 3669 of 4770
IG02M±03
P20105
± IGNITION (1MZ±FE)CRANKSHAFT POSITION SENSOR
IG±11
1705 Author: Date:
CRANKSHAFT POSITION SENSOR
REMOVAL
1. REMOVE RH FENDER APRON SEAL
2. REMOVE CRANKSHAFT POSITION SENSOR
(a) Remove the bolt and disconnect the crankshaft position
sensor.
Torque: 8 N´m (80 kgf´cm, 69 in.´lbf)
(b) Disconnect the crankshaft position sensor connecter.
Page 3670 of 4770
IG02N±03
P14244
Ohmmeter IG±12
± IGNITION (1MZ±FE)CRANKSHAFT POSITION SENSOR
1706 Author: Date:
INSPECTION
NOTICE:
ºColdº and ºHotº in these sentences express the tempera-
ture of the sensor itself. ºColdº is from ±10°C (14°F) to 50°C
(122°F) and ºHotº is from 50°C (122°F) to 100°C (212°F).
INSPECT CRANKSHAFT POSITION SENSOR RESISTANCE
Using an ohmmeter, measure the resistance between termi-
nals.
Resistance:
Cold1,630 ± 2,740 W
Hot2,065 ± 3,225 W
If the resistance is not as specified, replace the crankshaft posi-
tion sensor.
Page 3671 of 4770
IG02O±01
± IGNITION (1MZ±FE)CRANKSHAFT POSITION SENSOR
IG±13
1707 Author: Date:
INSTALLATION
Installation is in the reverse order of removal. (See page IG±11)
Page 3672 of 4770

IN00U±22
N17080
Filler Cap
Float
Reservoir Tank
Grommet
Clip
Slotted Spring Pin
: Specified torque
Non±reusable partCylinder
Piston
Push Rod
Washer
Snap Ring
Boot
Gasket
Lock Nut
Clevis Pin
Clevis
N´m (kgf´cm, ft´lbf)
12 (120, 9)
15 (155, 11)
± INTRODUCTIONHOW TO USE THIS MANUAL
IN±1
1 Author: Date:
HOW TO USE THIS MANUAL
GENERAL INFORMATION
1. INDEX
An INDEX is provided on the first page of each section to guide you to the item to be repaired. To assist you
in finding your way through the manual, the Section Title and major heading are given at the top of every
page.
2. GENERAL DESCRIPTION
At the beginning of each section, a General Description is given that pertains to all repair operations con-
tained in that section.
Read these precautions before starting any repair task.
3. TROUBLESHOOTING
TROUBLESHOOTING tables are included for each system to help you diagnose the problem and find the
cause. The fundamentals of how to proceed with troubleshooting are described on page IN±21.
Be sure to read this before performing troubleshooting.
4. PREPARATION
Preparation lists the SST (Special Service Tools), recommended tools, equipment, lubricant and SSM (Spe-
cial Service Materials) which should be prepared before beginning the operation and explains the purpose
of each one.
5. REPAIR PROCEDURES
Most repair operations begin with an overview illustration. It identifies the components and shows how the
parts fit together.
Example:
