Page 3753 of 4770

TOYOTA CAMRY 2000 Service Repair Manual ± MAINTENANCEINSIDE VEHICLE
MA±3
46 Author: Date:
13. ACCELERATOR PEDAL
Check the pedal for smooth operation and uneven pedal effort or catching.
14. CLUTCH PEDAL (See page CL±2)
(a) Check the pe

Page 3754 of 4770

TOYOTA CAMRY 2000 Service Repair Manual MA003±09
MA±4
± MAINTENANCEUNDER HOOD
47 Author: Date:
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owners manual supplement in

MA003±09
MA±4
± MAINTENANCEUNDER HOOD
47 Author: Date:
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performed.
Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).
Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.
Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the ºFULLº and ºLOWº lines on the see±through reservoir.
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL
Check that the electrolyte level of all battery cells is between the upper and lower level lines on the case.
6. BRAKE AND CLUTCH FLUID LEVELS
(a) Check that the brake and clutch fluid levels are near the upper level line on the see±through reservoirs.
(b) Check that the clutch fluid level is with is ± 5 mm (0.20 in.). of the reservoir hem.
7. ENGINE DRIVE BELTS
Check drive belt for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL
Check the level.
The level should be in the ºHOTº or ºCOLDº range depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
(a) Park the vehicle on a level surface.
(b) With the engine idling and the parking brake applied, shift the selector into all positions from ºPº to ºLº,
and then shift into ºPº position.
(c) Pull out the dipstick and wipe off the fluid with a clean rag. Re±insert the dipstick and check that the
fluid level is in the HOT range.
(d) Do this check with the fluid at normal driving temperature (70 ± 80°C, 158 ± 176°F).
HINT:
Wait until the engine cools down (approx. 30 min.) before checking the fluid level after extended driving at
high speeds, in hot weather, in heavy traffic or pulling a trailer.
11. EXHAUST SYSTEM
If any change in the sound of the exhaust or smell of the exhaust fumes is noticed, have the cause located
and corrected.

Page 3755 of 4770

TOYOTA CAMRY 2000 Service Repair Manual MA00L±01
P00495
Outside
Inside
± MAINTENANCEENGINE
MA±5
48 Author: Date:
ENGINE
INSPECTION
1. REPLACE TIMING BELT
5S±FE: (See page EM±17)
1MZ±FE: (See page EM±15)
2. INSPECT DRIVE BELTS
5S±F

Page 3756 of 4770

TOYOTA CAMRY 2000 Service Repair Manual MA0055
MA00M±01
MA±6
± MAINTENANCEBRAKE
49 Author: Date:
BRAKE
INSPECTION
1. INSPECT BRAKE LINE PIPES AND HOSES
HINT:
Check in a well lighted area. Check the entire circumference
and length of th

Page 3757 of 4770

TOYOTA CAMRY 2000 Service Repair Manual MA00N±01
N01022
± MAINTENANCECHASSIS
MA±7
50 Author: Date:
CHASSIS
INSPECTION
1. INSPECT STEERING LINKAGE
(a) Check the steering wheel freeplay. (See page SR±8)
(b) Check the steering linkage fo

Page 3758 of 4770

TOYOTA CAMRY 2000 Service Repair Manual MA0676B00995
MA00O±01
N21126
N21125
MA±8
± MAINTENANCEBODY
51 Author: Date:
BODY
INSPECTION
1. TIGHTEN BOLTS AND NUTS ON CHASSIS AND
BODY
Tighten these parts:
Front seat mount bolts
Torque: 37 N

Page 3759 of 4770

TOYOTA CAMRY 2000 Service Repair Manual ± MAINTENANCEBODY
MA±9
52 Author: Date:
Check that the brakes work properly and do not
drag.
Do setting of the parking brake shoes and drum.
(c) Be sure to deliver a clean car. Especially check

Page 3760 of 4770

TOYOTA CAMRY 2000 Service Repair Manual MX04A±01
± MANUAL TRANSAXLE (S51)MANUAL TRANSAXLE SYSTEM
MX±1
1851 Author: Date:
MANUAL TRANSAXLE SYSTEM
PRECAUTION
When working with FIPG material, you must observe the following items.
Using a
