2000 TOYOTA CAMRY Service Repair Manual

ground clearance height adjustment roof cabin filter radiator cap stop start

Load previous 8 pages

Page 1009 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
243
Tires
Normal driving
kPa (kgf/cm2 or bar, psi)
Tire size
For all loads including full rated loadsFor reduced loads (1 to 4 passengers)
Wheel sizeTire sizeFrontRearFrontRearWheel size
P1

Page 1010 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
244
Fuses
Engine compartment
Engine compartment
Fuses (type A)
1. A/C 10 A: Air conditioning system
2. SPARE 10 A: Spare fuse
3. SPARE 15 A: Spare fuse
4. SPARE 30 A: Spare fuse
5. ALT±S 5

Page 1011 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
245
Engine compartment (type B)
14. DOME 7.5 A: Theft deterrent system,
daytime running light system, clock,
locking with wireless remote control
system, ignition switch light, personal
lig

Page 1012 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
246
27. STOP 15 A: Stop lights, cruise control
system, high±mounted stoplight, anti±
lock brake system, shift lock control
system, multiport fuel injection system/
sequential multiport fu

Page 1013 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
247
Part 9
REPORTING SAFETY
DEFECTS FOR U.S.
OWNERS AND
UNIFORM TIRE
QUALITY GRADING
Reporting safety defects for U.S.
owners
Uniform tire quality grading
If you believe that your vehicl

Page 1014 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
248
Uniform tire quality grading
This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department o

'99camry U
248
Uniform tire quality grading
This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality gradesÐAll passenger ve-
hicle tires must conform to Federal
Safety Requirements in addition to
these grades. These quality grades are
molded on the sidewall.
TreadwearÐThe treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1±1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.Traction AA, A, B, CÐThe traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire's
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.
Temperature A, B, CÐThe temperature
grades are A (the highest), B, and C,
representing the tire's resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.

Page 1015 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
249
Part 10
INDEX

Page 1016 of 4770

TOYOTA CAMRY 2000 Service Repair Manual GENERAL 1999 FEATURES
GENERAL 1999 FEATURES
2
DESCRIPTION
The table below provides an outline of the system that is indicated in the General 1999 Features and the names
of the 99 models that have ado
