Page 2497 of 4770

± DIAGNOSTICSENGINE (5S±FE)
DI±77
312 Author: Date:
DTC P0136 Heated Oxygen Sensor Circuit Malfunction
(Bank 1 Sensor 2)
CIRCUIT DESCRIPTION
Refer to DTC P0125 (Insufficient Coolant Temp. for Closed Loop Fuel Control (Except California Spec.)) on
page DI±55.
DTC No.DTC Detecting ConditionTrouble Area
P0136
Voltage output of heated oxygen sensor remains at
0.45*
1/0.40*2 V or more, or 0.60*1/0.50*2 V or less when ve-
hicle is driven at 40 km/h (25 mph) or more after engine is
warmed up
*
1: for California Spec.
*
2: except California Spec.
(2 trip detection logic).
Heated oxygen sensor
HINT:
Sensor 2 refers to the sensor farther away from the engine body.
WIRING DIAGRAM
Refer to DTC P0125 (Insufficient Coolant Temp. for Closed Loop Fuel Control (Except California Spec.)) on
page DI±55.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected, when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the engine warmed up or not, the air±fuel ratio lean or rich, etc.
at the time of the malfunction.
1 Are there any other codes (besides DTC P0136) being output?
YES Go to relevant DTC chart.
NO
DI00Y±08
Page 2498 of 4770
DI±78
± DIAGNOSTICSENGINE (5S±FE)
313 Author: Date:
2 Check for open and short in harness and connector between ECM and heated
oxygen sensor (See page IN±31).
NG Repair or replace harness or connector.
OK
3 Check output voltage of heated oxygen sensor.
PREPARATION:
(a) Connect the OBD II scan tool or TOYOTA hand±held tester to the DLC3.
(b) Warm up the engine to normal operating temp.
CHECK:
Read voltage output of the heated oxygen sensor when the engine suddenly raced.
HINT:
Perform quick racing to 4,000 rpm 3 min. using the accelerator pedal.
OK:
Heated oxygen sensor output voltage:
Alternates from 0.45*
1/0.40*2 V or less to 0.60*1/0.50*2 V or more.
*1: for California Spec.
*
2: except California Spec.
OK Check that each connector is properly
connected.
NG
Replace heated oxygen sensor.
Page 2499 of 4770

± DIAGNOSTICSENGINE (5S±FE)
DI±79
314 Author: Date:
DTC P0171 System too Lean (Fuel Trim)
(Only for California Spec.)
DTC P0172 System too Rich (Fuel Trim)
(Only for California Spec.)
CIRCUIT DESCRIPTION
Fuel trim refers to the feedback compensation value compared against the basic injection time. Fuel trim
includes short±term fuel trim and long±term fuel trim.
Short±term fuel trim is the short±term fuel compensation used to maintain the air±fuel ratio at its ideal
theoretical value.
The signal from the A/F sensor is approximately proportional to the existing air±fuel ratio, and ECM compar-
ing it with the ideal theoretical value, the ECM reduces fuel volume immediately if the air±fuel ratio is rich
and increases fuel volume if it is lean.
Long±term fuel trim compensates the deviation from the central value of the short±term fuel trim stored up
by each engine tolerance, and the deviation from the central value due to the passage of time and changes
of using environment.
If both the short±term fuel trim and long±term fuel trim exceed a certain value, it is detected as a malfunction
and the MIL lights up.
DTC No.DTC Detecting ConditionTrouble Area
P0171
When air±fuel ratio feedback is stable after engine warming up,
fuel trim is considerably in error on rich side
(2 trip detection logic)
Gas leakage on exhaust system
Air intake (loose hoses)
Fuel line pressure
Injector blockage
Manifold absolute pressure sensor
Engine coolant temp. sensor
A/F sensor
P0172
When air±fuel ratio feedback is stable after engine warming up,
fuel trim is considerably in error on lean side
(2 trip detection logic)
Gas leakage on exhaust system
Fuel line pressure
Injector leak, blockage
Manifold absolute pressure sensor
Engine coolant temp. sensor
A/F sensor
HINT:
When the DTC P0171 is recorded, the actual air±fuel ratio is on the lean side. When DTC P0172 is
recorded, the actual air±fuel ratio is on the rich side.
If the vehicle runs out of fuel, the air±fuel ratio is lean and DTC P0171 is recorded. The MIL then comes
on.
If the total of the short±term fuel trim value and long±term fuel trim value is within + 38 %, the system
is functioning normally.
The A/F sensor output voltage and the short±term fuel trim value can be read using the OBD II scan
tool or TOYOTA hand±held tester.
The ECM controls the voltage of AF and AF terminals of ECM to the fixed voltage. Therefore, it
is impossible to confirm the A/F sensor output voltage without OBD II scan tool or TOYOTA hand±held
tester.
DI1JW±03
Page 2500 of 4770
DI±80
± DIAGNOSTICSENGINE (5S±FE)
315 Author: Date:
OBD II scan tool (excluding TOYOTA hand±held tester) displays the one fifth of the A/F sensor output
voltage which is displayed on the TOYOTA hand±held tester.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected, when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the engine warmed up or not, the airÅfuel ratio lean or rich, etc.
at the time of the malfunction.
1 Check air induction system (See page SF±1).
NG Repair or replace.
OK
2 Check injector injection (See page SF±23).
NG Replace injector.
OK
3 Check manifold absolute pressure sensor and engine coolant temp. sensor
(See pages SF±53 and SF±49).
NG Repair or replace.
OK
4 Check for spark and ignition (See page IG±1).
NG Repair or replace.
OK
Page 2501 of 4770
± DIAGNOSTICSENGINE (5S±FE)
DI±81
316 Author: Date:
5 Check fuel pressure (See page SF±6).
NG Check and repair fuel pump, pressure regulator,
fuel pipe line and filter.
OK
6 Check gas leakage on exhaust system.
NG Repair or replace.
OK
Check and replace ECM (See page IN±31).
Page 2502 of 4770

DI±82
± DIAGNOSTICSENGINE (5S±FE)
317 Author: Date:
7 Check output voltage of A/F sensor.
PREPARATION:
(a) Connect the OBD II scan tool or TOYOTA hand±held tester to the DLC3.
(b) Warm up the A/F sensor with the engine at 2,500 rpm for approx. 90 sec.
CHECK:
Read voltage value of A/F sensor on the screen of OBD II scan tool or TOYOTA hand±held tester when you
perform all the following conditions.
HINT:
The voltage of AF terminal of ECM is 3.3 V fixed and AF terminal is 3.0 V fixed. Therefore, it is impossible
to check the A/F sensor output voltage at the terminals (AF/AF) of ECM.
OK:
ConditionA/F Sensor Voltage value
Engine idling
Engine racingNot remains at 3.30 V (* 0.660 V)
Not remains at38V(*0 76 V) or moreDriving at engine speed 1,500 rpm or more and vehicle
speed 40 km/h (25 mph) or more, and operate throttle valve
open and closeNot remains at 3.8 V (* 0.76 V) or more
Not remains at 2.8 V (* 0.56 V) or less
*: When you use OBD II scan tool (excluding TOYOTA hand±held tester)
HINT:
During fuel enrichment, there is a case that the output voltage of A/F sensor is below 2.8 V (* 0.56 V),
it is normal.
During fuel cut, there is a case that the output voltage of A/F sensor is above 3.8 V (* 0.76 V), it is nor-
mally.
If output voltage of A/F sensor remains at 3.30 V (* 0.660 V) even after performing all the above condi-
tions, A/F sensor circuit may be open.
If output voltage of A/F sensor remains at 3.8 V (* 0.76 V) or more, or 2.8 V (* 0.56 V) or less even after
performing all the above conditions, A/F sensor circuit may be short.
*: When you use the OBD II scan tool (excluding TOYOTA hand±held tester).
OK Go to step 9.
NG
Page 2503 of 4770
± DIAGNOSTICSENGINE (5S±FE)
DI±83
318 Author: Date:
8 Check for open and short in harness and connector between ECM and oxygen
sensor (See page IN±31).
NG Repair or replace harness or connector.
OK
Replace A/F sensor.
9 Perform confirmation driving pattern (See page DI±152).
Go
10 Is there DTC P0171 or P0172 being output again?
YES Check and replace ECM.
NO
11 Did vehicle runs out of fuel in the past?
NO Check for intermittent problems.
YES
DTC P0171 or P0172 is caused by running out of fuel.
Page 2504 of 4770

DI±84
± DIAGNOSTICSENGINE (5S±FE)
319 Author: Date:
DTC P0171 System too Lean (Fuel Trim)
(Except California Spec.)
DTC P0172 System too Rich (Fuel Trim)
(Except California Spec.)
CIRCUIT DESCRIPTION
Fuel trim refers to the feedback compensation value compared against the basic injection time. Fuel trim
includes short±term fuel trim and long±term fuel trim.
Short±term fuel trim is the short±term fuel compensation used to maintain the air±fuel ratio at its ideal
theoretical value. The signal from the heated oxygen sensor indicates whether the air±fuel ratio is RICH or
LEAN compared to the ideal theoretical value, triggering a reduction in fuel volume if the air±fuel ratio is rich,
and an increase in fuel volume if it is lean.
Long±term fuel trim is overall fuel compensation carried out long±term to compensate for continual deviation
of the short±term fuel trim from the central value due to individual engine differences, wear over time and
changes in the usage environment.
If both the short±term fuel trim and long±term fuel trim are LEAN or RICH beyond a certain value, it is
detected as a malfunction and the MIL lights up.
DTC No.DTC Detecting ConditionTrouble Area
P0171
When air±fuel ratio feedback is stable after engine warming up,
fuel trim is considerably in error on RICH side
(2 trip detection logic)
Gas leakage on exhaust system
Air intake (hose loose)
Fuel line pressure
Injector blockage
Heated oxygen sensor (bank 1 sensor 1)
Manifold absolute pressure sensor
Engine coolant temp. sensor
P0172
When air±fuel ratio feedback is stable after engine warming up,
fuel trim is considerably in error on LEAN side
(2 trip detection logic)
Gas leakage on exhaust system
Fuel line pressure
Injector leak, blockage
Heated oxygen sensor (bank 1 sensor 1)
Manifold absolute pressure sensor
Engine coolant temp. sensor
HINT:
When the DTC P0171 is recorded, the actual air±fuel ratio is on the LEAN side. When DTC P0172 is
recorded, the actual air±fuel ratio is on the RICH side.
If the vehicle runs out of fuel, the air±fuel ratio is LEAN and DTC P0171 is recorded. The MIL then
comes on.
If the total of the short±term fuel trim value and long±term fuel trim value is within + 38 %, the system
is functioning normally.
The heated oxygen sensor (bank 1 sensor 1) output voltage and the short±term fuel trim value can
be read using the OBD II scan tool or TOYOTA hand±held tester.
DI4NG±01
