PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the DTC check but the trouble still occurs, check the circuits for each
symptom in the order given in the charts on the following pages and proceed to the page given for trouble-
shooting.
The Matrix Chart is divided into 3 chapters.
Chapter 1: Electronic Circuit Matrix Chart
Chapter 2: On±vehicle Repair Matrix Chart
Chapter 3: Off±vehicle repair Matrix Chart
If the instruction ºProceed to next circuit inspection shown on matrix chartº is given in the flow
chart for each circuit, proceed to the circuit with the next highest number in the table to continue
the check.
If the trouble still occurs even though there are no abnormalities in any of the other circuits, then
check and replace the ECM.
1. Chapter 1: Electronic Circuit Matrix Chart
SymptomSuspect AreaSee page
No up±shift
(A particular gear, from 1st to 3rd gear, is not up±shifted)1. ECMIN±31
No up±shift (3rd " O/D)
1. O/D main switch & O/D OFF indicator light circuit
2. O/D cancel signal circuit
3. ECMDI±431
DI±428
IN±31
No down±shift (O/D " 3rd)1. ECMIN±31
No down±shift
(A particular gear, from 3rd to 1st gear, is not down±shifted)1. ECMIN±31
No lock±up or No lock±up off1. Stop light switch circuit
2. ECMDI±423
IN±31
Shift point too high or too low1. ECMIN±31
Up±shift to O/D from 3rd while O/D main switch is OFF1. O/D main switch & O/D OFF indicator light circuit
2. ECMDI±431
IN±31
Up±shift to O/D from 3rd while engine is cold1. ECMIN±31
Poor acceleration1. ECMIN±31
No kick±down1. ECMIN±31
Engine stalls when starting off or stopping1. ECMIN±31
Page 2826 of 4770

DI±406
± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
641 Author: Date:
2. Chapter 2: On±Vehicle Repair
(: A140E AUTOMATIC TRANSAXLE Repair Manual Pub. No. RM385U)
SymptomSuspect AreaSee page
Vehicle does not move in any forward positions and reverse posi-
tion
1. Manual valve
2. Throttle valve
3. Primary regulator valve
4. Off±vehicle repair matrix chart
±
Vehicle does not move in R position1. Off±vehicle repair matrix chart±
No up±shift (1st " 2nd)1. 1±2 shift valve
2. Off±vehicle repair matrix chart
±
No up±shift (2nd " 3rd)1. 2±3 shift valve
2. Off±vehicle repair matrix chart
±
No up±shift (3rd " O/D)1. 3±4 shift valve
2. Off±vehicle repair matrix chart
±
No down±shift (O/D " 3rd)1. 3±4 shift valve
No down±shift (3rd " 2nd)1. 2±3 shift valve
No down±shift (2nd " 1st)1. 1±2 shift valve
No lock±up or No lock±up off1. Lock±up relay valve
2. Off±vehicle repair matrix chart
±
Harsh engagement (N " D)1. C1 accumulator
2. Off±vehicle repair matrix chart
±
Harsh engagement (N " R)1. C2 accumulator
2. Off±vehicle repair matrix chart
±
Harsh engagement (N " L)1. Low coast modulator valve
Harsh engagement (Lock±up)1. Lock±up relay valve
2. Off±vehicle repair matrix chart
±
Harsh engagement (1st " 2nd " 3rd " O/D)
1. Throttle modulator valve
2. Cut back valve
3. Throttle valve
Harsh engagement (2nd " 3rd)1. C2 accumulator
Harsh engagement (3rd " O/D)1. B0 accumulator
Harsh engagement (O/D " 3rd)1. C0 accumulator
2. B
0 accumulator
Slip or shudder (Forward and reverse)
1. Throttle valve
2. Oil strainer
3. Off±vehicle repair matrix chart
±
No engine braking (1st: L position)1. Low coast modulator valve
2. Off±vehicle repair matrix chart
±
No engine braking (2nd: 2 position)1. 2nd coast modulator valve
2. Off±vehicle repair matrix chart
±
No kick±down
1. 1±2 shift valve
2. 2±3 shift valve
3. 3±4 shift valve
Page 2827 of 4770

± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
DI±407
642 Author: Date:
3. Chapter 3: Off±Vehicle Repair
(: A140E AUTOMATIC TRANSAXLE Repair Manual Pub. No. RM385U)
SymptomSuspect AreaSee page
Vehicle does not move in any forward positions and reverse posi-
tion
1. Front and rear planetary gear
2. O/D planetary gear
3. O/D one±way clutch (F
0)
4. O/D direct clutch (C
0)
5. O/D brake (B
0)
6. Forward clutch (C
1)
Vehicle does not move in R position
1. Front and rear planetary gear unit
2. Direct clutch (C
2)
3. O/D direct clutch (C
0)
4. 1st & reverse brake (B
3)
No up±shift (1st " 2nd)1. No. 1 one±way clutch (F1)
2. 2nd brake (B
2)
No up±shift (2nd " 3rd)1. Direct clutch (C2)
No up±shift (3rd " O/D)1. O/D brake (B0)
No lock±up or No lock±up off1. Torque converter clutchAX±26
Harsh engagement (N " D)
1. Forward clutch (C1)
2. O/D one±way clutch (F
0)
3. No. 2 one±way clutch (F
2)
Harsh engagement (N " R)1. Direct clutch (C2)
2. 1st & reverse brake (B
3)
Harsh engagement (Lock±up)1. Torque converter clutchAX±26
Slip or shudder (Forward position: After warm±up)
1. Torque converter clutch
2. O/D direct clutch (C
0)
3. Forward clutch (C
1)
4. O/D one±way clutch (F
0)
AX±26
Slip or shudder (R position)
1. Direct clutch (C2)
2. 1st & reverse brake (B
3)
3. O/D direct clutch (C
0)
Slip or shudder (1st)1. No. 2 one±way clutch (F2)
Slip or shudder (2nd)1. No. 1 one±way clutch (F1)
2. 2nd brake (B
2)
Slip or shudder (3rd)1. Direct clutch (C2)
Slip or shudder (O/D)1. O/D brake (B0)
No engine braking (1st ~ 3rd: D position)1. 2nd brake (B2)
No engine braking (1st: L position)1. 1st & reverse brake (B3)
No engine braking (2nd: 2 position)1. 2nd coast brake (B1)
Poor acceleration (All positions)1. Torque converter clutch
2. O/D planetary gearAX±26
Poor acceleration (O/D)1. O/D direct clutch (C0)
2. O/D planetary gear
Large shift shock or engine stalls when starting off or stopping1. Torque converter clutchAX±26
Page 2828 of 4770

DI1J0±01
A00414
Vehicle Speed Sensor4±Pulse 4±Pulse
Combination Meter
ECM
Transaxle
Vehicle Speed Sensor
DI±408
± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
643 Author: Date:
CIRCUIT INSPECTION
DTC P0500 Vehicle Speed Sensor Malfunction
CIRCUIT DESCRIPTION
The vehicle speed sensor outputs a 4±pulse signal for every revolution of the rotor shaft, which is rotated
by the transmission output shaft via the driven gear. After this signal is converted into a more precise rectan-
gular wave form by the wave form shaping circuit inside the combination meter, it is then transmitted to the
ECM. The ECM determines the vehicle speed based on the frequency of these pluse signals.
DTC No.DTC Detecting ConditionTrouble Area
P0500
During vehicle is being driven, no vehicle speed sensor signal
to ECM
(2 trip detection logic)Combination meter
Open or short in vehicle speed sensor circuit
Vehicle speed sensor
ECM Clutch or brake slips or gear is brokenECM
Automatic transaxle (clutch, brake or gear etc.)
WIRING DIAGRAM
See page DI±145.
Page 2829 of 4770

A03021D02238
SPD
SPD
ON
(±) w/ Engine Immobiliser System
w/o Engine Immobiliser System(+)
(±)
(+)
AT7809
4.5 ~ 5.5 V
0
Turn the wheel
± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
DI±409
644 Author: Date:
INSPECTION PROCEDURE
1 Check operation of speedometer.
CHECK:
Drive the vehicle and check if the operation of the speedmeter in the combination meter is normal.
HINT:
The vehicle speed sensor is operating normally if the speedometer display is normal.
NG Check speedometer circuit. See combination
meter troubleshooting (See page BE±47).
OK
2 Check voltage between terminal SPD of ECM connector and body ground.
PREPARATION:
(a) Remove glove compartment (See page BO±75).
(b) Shift the shift lever to neutral.
(c) Jack up one of the front wheels.
(d) Turn ignition switch ON.
CHECK:
Measure voltage between terminal SPD of ECM connector and
body ground when the wheel is turned slowly.
OK:
Voltage is generated intermittently.
NG Check and repair harness and connector
between combination meter and ECM
(See page IN±31).
OK
Page 2830 of 4770
DI±410
± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
645 Author: Date:
3 Check the ECM (See page IN±31).
NG Replace the ECM.
OK
Check and repair the transaxle (clutch, brake
or gear etc.).
Page 2831 of 4770

Q07741
± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
DI±411
646 Author: Date:
DTC P0750, P0755 Shift Solenoid A/B Malfunction
(Shift Solenoid Valve No.1/No.2)
SYSTEM DESCRIPTION
The ECM uses signals from the vehicle speed sensor and crankshaft position sensor to detect the actual
gear position (1st, 2nd, 3rd or O/D gear).
Then the ECM compares the actual gear with the shift schedule in the ECM memory to detect mechanical
trouble of the shift solenoid valves, valve body or automatic transaxle (clutch, brake or gear etc.).
DTC No.DTC Detecting ConditionTrouble Area
P0750
P0755During normal driving, the gear required by the ECM does not
match the actual gear
(2 trip detection logic)Shift solenoid valve No.1/No.2 is stuck open or closed
Valve body is blocked up or stuck
Automatic transaxle (clutch, brake or gear etc.)
Check the shift solenoid valve No.1 when DTC P0750 is output and check the shift solenoid valve No.2 when
DTC P0755 is output.
INSPECTION PROCEDURE
1 Check shift solenoid valve No.1 or No.2 operation.
PREPARATION:
(a) Remove the oil pan.
(b) Remove the shift solenoid valve No.1 or No.2.
CHECK:
(a) By applying 490 kPa (5 kgf/cm2, 71 psi) of compressed
air, check that the solenoid valve does not leak air.
(b) When battery positive voltage is supplied to the shift sole-
noid valve, check that the valve opens.
OK:
(a) Solenoid valve does not leak air.
(b) Solenoid valve opens.
NG Replace the shift solenoid valve No.1 or No.2.
OK
DI032±02
Page 2832 of 4770
DI±412
± DIAGNOSTICSAUTOMATIC TRANSAXLE (A140E)
647 Author: Date:
2 Check the valve body (See page DI±405).
NG Repair or replace the valve body.
OK
Repair or replace the transaxle.
