Page 3089 of 4770

AB0118
R13006AB0119H01024
H01076H01199
"u
E1Tc ACC ON
or
DTC B0108/52 DLC1Airbag
Sensor
Assembly P Squib
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±669
904 Author: Date:
4 Check P squib.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the front passenger airbag assembly connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0108/52 is not output.
HINT:
Codes other than code B0108/52 may be output at this time, but
they are not relevant to this check.
NG Replace front passenger airbag assembly.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 3090 of 4770
H01454
Side Squib (RH)Airbag Sensor Assembly
SFR+
SFR± Y±R
Y±G 1
21 2
C19
C19 DI±670
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
905 Author: Date:
DTC B0110/43 Short in Side Squib (RH) Circuit
(TMC Made)
CIRCUIT DESCRIPTION
The side squib (RH) circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0110/43 is recorded when a short is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0110/43
Short circuit between SFR+ wire harness and SFR± wire
harness of squib
Side squib (RH) malfunction
Airbag sensor assembly malfunctionSide airbag assembly (RH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
DI16G±08
Page 3091 of 4770
H01019W03859H01180
Squib (RH)Airbag
Sensor
Assembly
SFR+
(±) (+)SFR±
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±671
906 Author: Date:
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (RH) circuit.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the side airbag assembly (RH).
(See page DI±626)
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (RH) and the airbag sensor assembly,
measure the resistance between SFR+ and SFR±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween side airbag assembly (RH) and airbag
sensor assembly.
OK
Page 3092 of 4770
AB0118
R13006AB0119H01069
H01020
H07481
Squib (RH)Airbag
Sensor
Assembly
E1
TcACC
or
DTC B0110/43
ON " u
DLC1
DI±672
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
907 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0110/43 is not output.
HINT:
Codes other than code B0110/43 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 3093 of 4770

H01021AB0118AB0119R13006H01069H01179
"u
E1
Tc ACC ON
orAirbag
Sensor
Assembly Squib (RH)
DTC B0110/43 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±673
908 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to LOOK, and wait at least for 20 se-
cond.
(b) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(c) Clear DTC stored in memory.
(See page DI±626)
(d) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(e) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(f) Check DTC.
(See page DI±626)
OK:
DTC B0110/43 is not output.
HINT:
Codes other than code B0110/43 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 3094 of 4770
H04507
Side Squib (RH)Airbag Sensor Assembly
SFR+
SFR± Y±R
Y±G 1
21 2
C19
C19 Y±R
Y±G BW1
BW11
2 DI±674
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
909 Author: Date:
DTC B0110/43 Short in Side Squib (RH) Circuit
(TMMK Made)
CIRCUIT DESCRIPTION
The side squib (RH) circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0110/43 is recorded when a short is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0110/43
Short circuit between SFR+ wire harness and SFR± wire
harness of squib
Side squib (RH) malfunction
Airbag sensor assembly malfunctionSide airbag assembly (RH)
Airbag sensor assembly
Wire harness
Sub wire harness
WIRING DIAGRAM
DI1KY±02
Page 3095 of 4770
H02272W03859H02315
Squib (RH)Airbag
Sensor
Assembly
SFR+ SFR±
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±675
910 Author: Date:
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (RH) circuit.
PREPARATION:
Release airbag activation prevention mechanism of the con-
nector (on the airbag sensor assembly side) between the airbag
sensor assembly and the side airbag assembly (RH).
(See page DI±626)
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (RH) and the airbag sensor assembly,
measure the resistance between SFR+ and SFR±.
OK:
Resistance: 1 MW or Higher
NG Go to step 5.
OK
Page 3096 of 4770
AB0118
R13006AB0119H01069 W03860H08250H08249
Airbag
Sensor
Assembly
ACC
or
DTC B0110/43
ON " u
DLC1 Squib (RH)
DI±676
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
911 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0110/43 is not output.
HINT:
Codes other than code B0110/43 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
