Page 4225 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS±50 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMC Made) 2195 Author: Date: (f) Slide the seat to the rearmost position to install the bolts on the front side. Torque: 37 N´m (375 kgf

Page 4226 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS05M±03 H08246 Seatback AssemblyHeadrest Headrest Support Side Airbag Assembly Seat Truck Cover Front Seat Cushion Shield Release Handle Power adjuster type: Front Seat Cushion Shield Front Seat C

Page 4227 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS0EW±01 H02270 H02259 RS±52 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMMK Made) 2197 Author: Date: REMOVAL NOTICE: If the wiring connector of the SRS is disconnected and the ignitio

Page 4228 of 4770

TOYOTA CAMRY 2000 Service Repair Manual H01871 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMMK Made) RS±53 2198 Author: Date: (d) Remove the side airbag sub wire harness after removing clips. (e) Remove the seatback assembly.

Page 4229 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS05O±03 H01608 Cross Section H08275 RS±54 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMMK Made) 2199 Author: Date: INSPECTION 1. VEHICLES NOT INVOLVED IN COLLISION (a) Do a diagnostic

Page 4230 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS05P±02 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMMK Made) RS±55 2200 Author: Date: DISPOSAL (See page RS±42)

Page 4231 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS05Q±03 RS±56 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMMK Made) 2201 Author: Date: REPLACEMENT REPLACEMENT REQUIREMENTS In the following cases, replace the seatback assembly or sea

Page 4232 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RS0EX±01 H01871 ± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMMK Made) RS±57 2202 Author: Date: INSTALLATION NOTICE: Never use airbag parts from another vehicle. When replac- ing parts,
