'99camry U
79
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1±4
Lights, Wipers and
Defogger

Headlights and turn signals

Emergency flashers

Instrument panel light control

Interior light

Ignition switch light

Personal light

Windshield wipers and washer

Rear window and outside
rear view mirror defoggers
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1ÐParking, tail, license plate,
side marker and instrument panel lights
Position 2ÐHeadlights and all of the
above
The lights automatically turn off when the
driver 's door is opened with the ignition
turned off. To turn them on again, turn the
key to the ºONº position or actuate the
headlight switch. If you are going to park
for over one week, make sure the head-
light switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the ºOFFº position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.
The headlights automatically turn to full
intensity in the twilight even with the light
switch in the ºOFFº position.

'99camry U
83
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ºONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
With interval adjuster: The ºINT TIMEº
band lets you adjust the wiping time inter-
val when the wiper lever is in the intermit-
tent position (position 1). Twist the band
upward to increase the time between
sweeps, and downward to decrease it.To squirt washer fluid, pull the lever
toward you.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see ºAdding washer fluidº in Chapter 7±3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
To defog or defrost the rear window,
push the switch.
The key must be in the ºONº position.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
On some models, heater panels in the
outside rear view mirrors will also quickly
clear the surfaces.
Push the switch once again to turn the
defogger off.
The system will automatically shut off af-
ter the defogger has operated about 15
minutes.
Windshield wipers and
washerRear window and outside
rear view mirror defoggers

'99camry U
245
Engine compartment (type B)
14. DOME 7.5 A: Theft deterrent system,
daytime running light system, clock,
locking with wireless remote control
system, ignition switch light, personal
light, trunk light, electric moon roof
lamp, interior light, vanity mirror light,
door courtesy light, power door lock
system
15. ECU±B 10 A: Cruise control system,
anti±lock brake system, SRS airbag
system, seat belt pretensioners
16. DRL NO.2 5 A: Daytime running light
system
Instrument panel
17. H±LP LH(LWR) 10 A: Left±hand head-
light
18. H±LP RH(LWR) 10 A: Right±hand
headlight
19. A/F HTR 25 A: A/F sensor
20. SEAT±HEATER 20 A: No circuit
21. HEATER 10 A: Air conditioning system,
rear window defogger, starting system22. GAUGE 10 A: Gauges and meters,
back±up lights, cruise control system,
charging system, traction control sys-
tem, daytime running light system,
power windows, service reminder indi-
cators and warning buzzers
23. WIPER 25 A: Windshield wipers and
washer
24. MIRROR±HEATER 10 A: Outside rear
view mirror defogger
25. ECU±IG 15 A: Cruise control system,
anti±lock brake system, power antenna,
SRS airbag system, seat belt preten-
sioners, theft deterrent system, shift
lock control system, traction control
system, daytime running light system,
locking with wireless remote control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
26. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/sequential multiport fuel injec-
tion system

MA002±11
MA±2
± MAINTENANCEINSIDE VEHICLE
45 Author: Date:
INSIDE VEHICLE
GENERAL MAINTENANCE
These are maintenance and inspection items which are considered to be the owner's responsibility.
They can be done by the owner or they can have them done at a service shop.
These items include those which should be checked on a daily basis, those which, in most cases, do not
require (special) tools and those which are considered to be reasonable for the owner to do.
Items and procedures for general maintenance are as follows.
1. GENERAL NOTES

Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.

Every service item in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.

Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, and other lights are all working.
(b) Check the headlight aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater or air conditioner.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and are mounted securely.
10. STEERING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that the seat adjusters operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the locks hold securely in any
latch position.
(d) For fold±down seat backs, check that the latches lock securely.
12. SEAT BELTS
(a) Check that the seat belt system such as the buckles, retractors and anchors operate properly and
smoothly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.

WINDSHIELD WIPER BLADE MAINTENANCE AND CLEANING ± BO030-01December 7, 2001
Page 2 of 2
3. Contributors to Poor Performance/Decreased Rubber Blade Life (require rubber
replacement)
Dusty areas cause the rubber edge to wear quickly.
Sand and salt used for road conditioning during winter causes the edge to wear
quickly, so areas with significant snowfall require more frequent wiper
replacement.
Heat and time cause the rubber to become excessively ªpermanent set,º so the
rubber does not turn over, resulting in streaking and/or unwiped areas on the
glass.
Rubber is easily cut or torn while using ice scrapers on the glass.
Rubber can be torn when pulling blades off a frozen windshield.
Using wipers instead of an ice scraper to remove frost and ice from the windshield
during a car warm up can dull, nick, or tear the rubber.
Banging wiper on the glass to remove ice & snow can cause the blade to bend
and rubber to come out of the blade providing the potential to scratch the glass.
Ice forms in wiper blade pin joints, which causes streaking and unwiped areas. To
remove ice from pin joints, compress the blade and rubber with your hand to
loosen the frozen joints. To prevent this condition, use winter blades with a rubber
cover.Maintenance,
Cleaning
and Use
(Continued)
