7 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Connect the TOYOTA hand±held tester to the DLC3.
(c) Turn the ignition switch ON and push the TOYOTA hand±
held tester main switch ON.
(d) Use ACTIVE TEST mode to operate the fuel pump.
(e) If you have no TOYOTA hand±held tester, connect the
positive (+) and negative (±) leads from the battery to the
fuel pump connector (See page SF±6).
CHECK:
Check that the pulsation damper screw rises up when the fuel
pump operates.
NG Proceed to page SF±6 and continue to
troubleshoot.
OK
Page 2626 of 4770
P23917
DI±206
± DIAGNOSTICSENGINE (1MZ±FE)
441 Author: Date:
8 Check for spark.
PREPARATION:
(a) Remove the ignition coil or disconnect the high±tension
cord from the spark plug.
(b) Remove the spark plug.
(c) Install the spark plug to the ignition coil or high±tension
cord.
(d) Disconnect the injector connector.
(e) Hold the end about 12.5 mm (0.5 in.) from the ground.
CHECK:
Check if spark occurs while engine is being cranked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, don't crank the engine for more than 5 ~ 10
seconds at a time.
OK:
Spark jumps across electrode gap.
NG Proceed to page IG±1 and continue to
troubleshoot.
OK
Proceed to problem symptoms table on page
DI±221.
Page 2627 of 4770

± DIAGNOSTICSENGINE (1MZ±FE)
DI±207
442 Author: Date:
7. ENGINE OPERATING CONDITION
NOTICE:
The values given below for ºNormal Conditionº are representative values, so a vehicle may still be
normal even if its value varies from those listed here. So do not decide whether a part is faulty or
not solely according to the ºNormal Conditionº here.
(a) CARB mandated signals.
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*
FUEL SYS #1
Fuel System Bank 1
OPEN: Air±fuel ratio feedback stopped
CLOSED: Air±fuel ratio feedback operating
Idling after warming up: CLOSED
FUEL SYS #2
Fuel System Bank 2
OPEN: Air±fuel ratio feedback stopped
CLOSED: Air±fuel ratio feedback operating
Idling after warming up: CLOSED
CALC LOAD
Calculator Load:
Current intake air volume as a proportion of max.
intake air volumeIdling: 13.1 ~ 18.7%
Racing without load (2,500rpm): 11.7 ~ 17.3%
COOLANT TEMP.Engine Coolant Temp. Sensor ValueAfter warming up: 80 ~ 95°C (176 ~ 203°F)
SHORT FT #1Short±term Fuel Trim Bank 10 ± 20%
LONG FT #1Long±term Fuel Trim Bank 10 ± 20%
SHORT FT #2Short±term Fuel Trim Bank 20 ± 20%
LONG FT #2Long±term Fuel Trim Bank 20 ± 20%
ENGINE SPDEngine SpeedIdling: 650 ~ 750 rpm
VEHICLE SPDVehicle SpeedVehicle stopped: 0 km/h (0 mph)
IGN ADVANCEIgnition Advance:
Ignition Timing of Cylinder No. 1Idling: BTDC 10 ~ 25.0°
INTAKE AIRIntake Air Temp. Sensor ValueEquivalent to Ambient Temp.
MAFAir Flow Rate Through Mass Air Flow Meter
Idling: 3.3 ~ 4.7 gm/sec.
Racing without load (2,500 rpm):
10.4 ~ 15.4 gm/sec.
THROTTLE POS
Voltage Output of Throttle Position Sensor
Calculated as a percentage:
0 V "0%, 5 V "100%Throttle valve fully closed: 7 ~ 11 %
Throttle valve fully open: 65 ~ 75%
*: If no conditions are specifically stated for ºldlingº, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.
Page 2628 of 4770

DI±208
± DIAGNOSTICSENGINE (1MZ±FE)
443 Author: Date:
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*1
O2S B1, S1Voltage Output of Oxygen Sensor
Bank 1 Sensor 1Idling: 0.1 ~ 0.9 V (0.56 ~ 0.76 V*2)
O2FT B1, S1Oxygen Sensor Fuel Trim Bank 1 Sensor 1
(Same as SHORT FT #1)0 ± 20%
O2S B1, S2Voltage Output of Oxygen Sensor
Bank 1 Sensor 2Driving 50 km/h (31 mph): 0.1 ~ 0.9 V
O2S B2, S1Voltage Output of Oxygen Sensor
Bank 2 Sensor 1Idling: 0.1 ~ 0.9 V (0.56 ~ 0.76 V*2)
O2FT B2, S1Oxygen Sensor Fuel Trim Bank 2 Sensor 1
(Same as SHORT FT #2)
0 ± 20%
A/FS B1, S1 *3Voltage Output of A/F Sensor Bank 1 Sensor 1Idling: 2.8 ~ 3.8 V
A/FS B2, S1 *3Voltage Output of A/F Sensor Bank 2 Sensor 1Idling: 2.8 ~ 3.8 V
A/FFT B1, S1 *3A/F Sensor Fuel Trim Bank 1 Sensor 1
(Same as SHORT FT #1)O ± 20%
A/FFT B2, S1 *3A/F Sensor Fuel Trim Bank 2 Sensor 1
(Same as SHORT FT #1)O ± 20%
*1: If no conditions are specifically stated for ºIdlingº, it means the shift lever is shift lever is at N or P position,
the A/C switch is OFF and all accessory switches are OFF.
*2: Only for California Specification vehicles, when you use the OBD II scan tool (excluding TOYOTA hand±
held tester).
*3: Only for California Specification vehicles, when you use the TOYOTA hand±held tester.
Page 2629 of 4770

± DIAGNOSTICSENGINE (1MZ±FE)
DI±209
444 Author: Date:
(b) TOYOTA Enhanced Signals.
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*
MISFIRE RPMEngine RPM for first misfire rangeMisfire 0: 0 rpm
MISFIRE LOADEngine load for first misfire rangeMisfire 0: 0 g/r
INJECTORFuel injection time for cylinder No.1Idling: 1.6 ~ 2.9 ms
IAC DUTY RATIOIntake Air Control Valve Duty Ratio
Opening ratio rotary solenoid type IAC valveIdling: 27 ~ 47 %
STARTER SIGStarter SignalCranking: ON
CTP SIGClosed Throttle Position SignalThrottle Fully Closed: ON
A/C SIGA/C Switch SignalA/C ON: ON
PNP SWPark/Neutral Position Switch SignalP or N position: ON
ELCTRCL LOAD SIGElectrical Load SignalDefogger switch ON: ON
STOP LIGHT SWStop Light Switch SignalStop light switch ON: ON
PS OIL PRESS SWPower Steering Oil Pressure Switch SignalTurn steering wheel: ON
FC IDLFuel Cut Idle: Fuel cut when throttle valve fully
closed, during decelerationFuel cut operating: ON
FC TAUFuel Cut TAU: Fuel cut during very light loadFuel cut operating: ON
CYL#1 ~ CYL#6Abnormal revolution variation for each cylinder0%
IGNITIONTotal number of ignition for every 1,000 revolu-
tions0 ~ 3,000
EGRT GASEGR Gas Temperature Sensor Value
EGR not operating:
Temperature between intake air temp. and
engine coolant temp.
INTAKE CTRL VSVIntake Air Control Valve VSV SignalVSV operating: ON
EGR SYSTEMEGR system operating conditionIdling: OFF
A/C CUT SIGA/C Cut SignalA/C S/W OFF: ON
FUEL PUMPFuel Pump SignalIdling: ON
EVAP (PURGE) VSVEVAP VSV SignalVSV operating: Above 30%
VAPOR PRESS VSVVapor Pressure VSV SignalVSV operating: ON (TANK)
*: If no conditions are specifically stated for ºldlingº, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.
Page 2630 of 4770

DI±210
± DIAGNOSTICSENGINE (1MZ±FE)
445 Author: Date:
TOYOTA hand±held tester displayMeasurement ItemNormal Condition*1
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 1Idling: 0.8 ~ 1.2
TOTAL FT B2Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 2Idling: 0.8 ~ 1.2
O2 LR B1, S1 *2
Oxygen Sensor Lean Rich Bank 2 Sensor 1 Re-
sponse time for oxygen sensor output to switch
from lean to rich
Idling after warmed up: 0 ~ 1,000 msec.
O2 LR B2, S1 *2
Oxygen Sensor Lean Rich Bank 2 Sensor 1 Re-
sponse time for oxygen sensor output to switch
from lean to rich
Idling after warmed up: 0 ~ 1,000 msec.
O2 RL B1, S1 *2
Oxygen Sensor Rich Lean Bank 1 Sensor 1 Re-
sponse time for oxygen sensor output to switch
from rich to lean
Idling after warmed up: 0 ~ 1,000 msec.
O2 RL B2, S1 *2
Oxygen Sensor Rich Lean Bank 2 Sensor 1 Re-
sponse time for oxygen sensor output to switch
from rich to lean
Idling after warmed up: 0 ~ 1,000 msec.
*1: If no conditions are specifically stated for ºIdlingº, it means the shift lever is at N or P position, the A/C
switch is OFF and all accessory switches are OFF.
*2: Except California Specification vehicles.
Page 2631 of 4770

DI07B±07
± DIAGNOSTICSENGINE (1MZ±FE)
DI±211
446 Author: Date:
DIAGNOSTIC TROUBLE CODE CHART
1. SAE CONTROLLED
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to the type of instrument
or other factors.
If a malfunction code is displayed during the DTC check in check mode, check the circuit for that code listed
in the table below. For details of each code, turn to the page referred to under the ''See page '' for the respec-
tive ''DTC No.'' in the DTC chart.
DTC No.
(See Page)Detection ItemTrouble AreaMIL*1Memory
P0100
(DI±222)Mass Air Flow Circuit
MalfunctionOpen or short in mass air flow meter circuit
Mass air flow meter
ECM
P0101
(DI±227)Mass Air Flow Circuit
Range/Performance
Problem
Mass air flow meter
P0110
(DI±228)Intake Air Temp. Circuit
MalfunctionOpen or short in intake air temp. sensor circuit
Intake air temp. sensor (built into mass air flow meter)
ECM
P0115
(DI±233)Engine Coolant Temp. Circuit
MalfunctionOpen or short in engine coolant temp. sensor circuit
Engine coolant temp. sensor
ECM
P0116
(DI±237)Engine Coolant Temp. Circuit
Range/Performance ProblemEngine coolant temp. sensor
Cooling system
P0120
(DI±239)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
MalfunctionOpen or short in throttle position sensor circuit
Throttle position sensor
ECM
P0121
(DI±243)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
Range/Performance Problem
Throttle position sensor
*2
P0125
(DI±244)
Insufficient Coolant Temp. for
Closed Loop Fuel Control
(Except California Spec.)
Fuel system
Injector
Ignition system
Gas leakage on exhaust system
Open or short in heated oxygen sensor circuit
(bank 1, 2 sensor 1)
Heated oxygen sensor (bank 1, 2 sensor 1)
ECM
*3
P0125
(DI±249)
Insufficient Coolant Temp. for
Closed Loop Fuel Control
(Only for California Spec.)
Fuel system
Injector
Ignition system
Gas leakage on exhaust system
Open or short in A/F sensor circuit (bank 1, 2 sensor 1)
A/F sensor (bank 1, 2 sensor 1)
ECM
*2
P0130
(DI±255)Heated Oxygen Sensor Circuit
Malfunction (Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
*1: MIL lights up
*
2: Except California specification vehicles
*
3: Only for California specification vehicle
Page 2632 of 4770

DI±212
± DIAGNOSTICSENGINE (1MZ±FE)
447 Author: Date:
DTC No.
(See Page)Detection ItemTrouble AreaMILMemory
*2
P0133
(DI±259)
Heated Oxygen Sensor Circuit
Slow Response
(Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
*2
P0135
(DI±263)
Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 1)Open or short in heater circuit of heated oxygen sensor
Heated oxygen sensor heater
ECM
P0136
(DI±265)Heated Oxygen Sensor Circuit
Malfunction
(Bank 1 Sensor 2)
Heated oxygen sensor
P0141
(DI±263)Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 2)
Same as DTC No. P0135*1
*3
P0150
(DI±255)
Heated Oxygen Sensor
Circuit Malfunction
(Bank 2 Sensor 1)
Same as DTC No. P0130*1
*3
P0153
(DI±259)
Heated Oxygen Sensor
Circuit Slow Response
(Bank 2 Sensor 1)Same as DTC No. P0133
Fuel trim malfunction*1
*3
P0155
(DI±263)Heated Oxygen Sensor
Circuit Malfunction
(Bank 2 Sensor 1)
Same as DTC No. P0135*1
*3
P0171
(DI±272)System too Lean
(Fuel Trim)
(Except California Spec.)
Air intake (hose loose)
Fuel line pressure
Injector blockage
Heated oxygen sensor (bank 1, 2 sensor 1) malfunction
Mass air flow meter
Engine coolant temp. sensor
Gas leakage on exhaust system
*1
*3
P0172
(DI±272)System too Rich
(Fuel Trim)
(Except California Spec.)
Fuel line pressure
Injector leak, blockage
Heated oxygen sensor (bank 1, 2 sensor 1) malfunction
Mass air flow meter
Engine coolant temp. sensor
Gas leakage on exhaust system
*1
*4
P0171
(DI±267)System too Lean
(Fuel Trim)
(Only for California Spec.)
Air intake (hose loose)
Fuel line pressure
Injector blockage
Mass air flow meter
Engine coolant temp. sensor
A/F sensor (bank 1, 2 sensor 1)
Gas leakage on exhaust system
*1
*4
P0172
(DI±267)System too rich
(Fuel Trim)
(Only for California Spec.)
Fuel line pressure
Injector leak, blockage
Heated oxygen sensor malfunction
Mass air flow meter
Engine coolant temp. sensor
A/F sensor (bank 1, 2 sensor 1)
Gas leakage on exhaust system
*1
*1: MIL lights up
*2: MIL light up or blinking
*3: Except California specification vehicles
*4: Only for California specification vehicle
