CAMRY
CAMRY ± OUTLINE OF NEW FEATURES 26
OUTLINE OF NEW FEATURES
The CAMRY is a high-quality family sedan with advanced technology and sporty performance. The following
changes are made for the 2000 model year.
1. Model Line-Up
The 5S-FNE CNG (Compressed Natural Gas) engine model has been added.
2. Exterior
Four new exterior colors have been added, for a total of 10 colors.
The design of the front and rear bumpers has been changed.
The bumper and the radiator grille have been made separate, and the radiator grille is chrome-plated.
The side protection molding has been increased in size. On the XLE grade model, chrome stripes have been
adopted for the side protection molding.
The 4-light multi-reflector type headlights are adopted with new styling.
The design and styling of the rear combination light has been changed.
The 16º aluminum alloy wheel and wheel cap has been added.
The styling of the 15º full wheel cover has been changed.
3. Interior
Wood-grain panels have been adopted in the interior of the XLE grade model.
CRS tether anchor brackets have been provided on the package tray trim. (except 5S-FNE engine Model)
A clock with an outside temperature gauge has been provided on the models with manual air conditioning.
4. 5S-FE Engine
The intake system from the inlet duct to the throttle body has been improved to increase torque and reduce
noise.
The direction of the rotation of the radiator cooling fan has been reversed.
A 2-way exhaust control system has been adopted on the TMMK made model.
Along with the discontinuance of the air assist system, the fuel injectors and the IAC valve have been
changed for the California specification model, in order to meet ULEV (Ultra-Low Emission Vehicle) re-
quirement.
The system for detecting evaporative emission leaks has been changed. For details, see the General 2000
Features section.
5. 5S-FNE Engine
Based on the 5S-FE gasoline engine, the 5S-FNE engine uses compressed natural gas. The fuel lines have
been designed exclusively for compressed natural gas application.
6. 1MZ-FE Engine
The system for detecting evaporative emission leaks has been changed. For details, see the General 2000
Features section.
A diagnostic trouble code (DTC) has been added for indicating a thermostat malfunction.
7. Automatic Transaxle
The overdrive switch has been changed to the momentary type. For details, see the General 2000 Features
section.
The differential gear ratio of the A140E automatic transaxle has been changed for the 5S-FNE engine mod-
el to accommodate the performance of the 5S-FNE engine.

23
INTERIOR
 WIRELESS DOOR LOCK REMOTE CONTROL SYSTEM
A wireless door lock remote control system is available as an option on the LE grade model and is standard
equipment on the XLE grade model. With the wireless door lock remote control system, all the doors can be locked
and unlocked by signals emitted by the transmitter.
A 2±step unlock function is provided. When the unlock switch of the transmitter is pressed once, only the driver's
door is unlocked. When it is pressed twice, all the doors are unlocked.
A panic switch is provided in the transmitter to force the theft system by operating the horn, headlight and taillight.
A wireless door lock ECU with EEPROM (Electrical Erasable Programmable ROM) is used so that the transmitter
recognition code can be easily reprogrammed.
 THEFT DETERRENT SYSTEM
A theft deterrent system is used to prevent vehicle theft. When the system is set, the horn and headlights operate
if the door, hood or trunk is forcibly opened.
The audio system also has an anti±theft system whereby the radio and cassette deck is disabled if the radio body
is stolen from the vehicle.

24
INTERIOR
 KEY REMINDER SYSTEM
All vehicles have a key reminder system as standard equipment. When the ignition key is left inserted in the ignition
key cylinder at ACC or LOCK positioon and the driver's door is opened, this system sounds a warning tone to remind
the driver to remove the ignition key.
 SRS AIRBAG
For all models, the new Camry has as standard equipment a driver's airbag in the steering wheel pad and a front
passenger airbag located in the instrument panel above the glove box.
 CRUISE CONTROL SYSTEM
The cruise control system is standard equipment on the LE and XLE grade model and an option on the CE grade
models. The main switch and control switch are on the a single lever, which is installed on the steering wheel and
can be operated easily.
 ILLUMINATED ENTRY SYSTEM
An illuminated entry system is standard equipment on the LE and XLE models. This system makes it easy to let
the Camry in and out at night, etc.
On the LE grade model, the ignition key cylinder illumination is turned on automatically when the door is opened.
When the door is closed, the ignition key cylinder illumination remains on for approximately 5 seconds, then goes
off automatically.
On the XLE grade model, the illuminated entry system turns on the dome light and ignition key cylinder
illumination for approximately 15 seconds after either door is closed when passengers are entering or leaving the
vehicle. While these lights are on for 15 seconds, if the ignition switch is turned to the ACC or ON position, or if
all doors are locked, the dome light and ignition key cylinder illuminatioons go off immediately.

'99camry U
79
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1±4
Lights, Wipers and
Defogger

Headlights and turn signals

Emergency flashers

Instrument panel light control

Interior light

Ignition switch light

Personal light

Windshield wipers and washer

Rear window and outside
rear view mirror defoggers
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1ÐParking, tail, license plate,
side marker and instrument panel lights
Position 2ÐHeadlights and all of the
above
The lights automatically turn off when the
driver 's door is opened with the ignition
turned off. To turn them on again, turn the
key to the ºONº position or actuate the
headlight switch. If you are going to park
for over one week, make sure the head-
light switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the ºOFFº position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.
The headlights automatically turn to full
intensity in the twilight even with the light
switch in the ºOFFº position.

'99camry U
231
Replacing light bulbsÐ
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if scratched
or dropped. Hold a bulb only by its
plastic or metal case. Do not touch
the glass part of a bulb with bare
hands.
NOTICE
Only use a bulb of the listed type.
Light bulbsBulb
No.WTy p e
HeadlightsHB260/55A
Parking, front side
marker and front
turn signal lights
Ð27/8B
Rear side marker
lights1943.8C
Rear turn signal
lights315627C
Stop and tail lights315727/8C
Tail light9049.3C
Back±up lights92118C
License plate lightsÐ5C
High mounted
stoplight21CP18C
Personal lightÐ10B
Interior lightÐ10D
Vanity lightsÐ3D
Glove box lightÐ1.2C
Trunk lightÐ3.8C
A: HB2 halogen bulbs
B: Single end bulbs
C: Wedge base bulbs
D: Double end bulbs

'99camry U
245
Engine compartment (type B)
14. DOME 7.5 A: Theft deterrent system,
daytime running light system, clock,
locking with wireless remote control
system, ignition switch light, personal
light, trunk light, electric moon roof
lamp, interior light, vanity mirror light,
door courtesy light, power door lock
system
15. ECU±B 10 A: Cruise control system,
anti±lock brake system, SRS airbag
system, seat belt pretensioners
16. DRL NO.2 5 A: Daytime running light
system
Instrument panel
17. H±LP LH(LWR) 10 A: Left±hand head-
light
18. H±LP RH(LWR) 10 A: Right±hand
headlight
19. A/F HTR 25 A: A/F sensor
20. SEAT±HEATER 20 A: No circuit
21. HEATER 10 A: Air conditioning system,
rear window defogger, starting system22. GAUGE 10 A: Gauges and meters,
back±up lights, cruise control system,
charging system, traction control sys-
tem, daytime running light system,
power windows, service reminder indi-
cators and warning buzzers
23. WIPER 25 A: Windshield wipers and
washer
24. MIRROR±HEATER 10 A: Outside rear
view mirror defogger
25. ECU±IG 15 A: Cruise control system,
anti±lock brake system, power antenna,
SRS airbag system, seat belt preten-
sioners, theft deterrent system, shift
lock control system, traction control
system, daytime running light system,
locking with wireless remote control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
26. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/sequential multiport fuel injec-
tion system

J
5
678
25 CAMRY (
Cont' d)
11
B
7
C
13
C
6
B
3
B
5
C
2
A
1
A R
R±L
Y±R
G±W
BR
BR
IJ13
IJ16
IJ12
IJ178
C
6
C
15
B Y±G
P
LR
R±L
Y± R
G±W
BR
BR
Y±G
B±O
P
L
4
A4
C2
C 11
C2
B4
B3
A7
B
IG317
IK23
2 1
EBLeft radiat or
side support IGInstrument
panel br ace
LH 2 1IG23
IG16
7IG16
A
11
A
7
A
8
A 10
A
9
A
9
C
5
A
3
C
10
B
12
A
13
B 12
B 10
C9
B8
B5
B 16
B 13
A1
C1
B 14
B 12
C L
2
D
N
R
P
SLI P
TRAC OFF
DOOR
O/D OFF See Illuminat ion
System< 10±4>
A
R±W R± W
W± B R±WW± B
R±W
R±W R±W
B±O
P± L P±L P± LB±O(
*4) R± W (
*6)
(
*7)J 2
JUNCTI ON
CONNE CT OR
Fro m Da yti me
Running Light
Re la y(
Main)
< 7±2>
B
BB
(
*6)
J11
JUNCTION
CONNECTOR
B 2
BRAKE FLUID LEVEL
WARNING SWP 3
PARKING BRAKE SW W 1
WASHER L EVEL
WARNING SW
From Day time Running
Light Relay(
Main)
< 7±2>
Fr om Park /Neutral
Pos it ion SW(
A/T)
or
Clutch Start SW(
M/T)
<1±2>GR(
*3)
See Key Reminder and Seat Belt
Warning System< 21±3> See ABS(
TMC Made)
System< 19±2>
See ABS(
TMMK Made)
System< 20±2>
See ABS and Tr act ion
Control System< 18±1>See Engine Cont rol and
Immobiliser System< 2±3> < 3±2>See Charging
System< 1±4> See Taillight
System< 11±4>
SRS CRUISE HIGH BEAMOIL
SEAT BELTABS MA LF UNCT I ON I NDI CA TOR
LAMPWASHER LEVELBULB
CHE CK
RE L AY REAR LIGHTSBRAKE
CHARGETURN RHTURN LH ILLUMINATION
TRIP METER
ODOMETER
(
*5) TACHOMETERWATER
TEMP. FUEL
FUEL
SECURI TYSee Electronically Controlled
Transmission and A/T
Indicator System
<4±4><5±4>
See ABS and
Tr act ion Contr ol
Sy st em< 18±1>
See Tur n Signal and
Hazard Warning Light
Sy st em< 8±2> < 8±3>
See Headlight
Sy st em< 6±3> < 7±3>
Se e SRS Sy st e m
< 28±4> See Theft Deterrent
System< 15±3>
See Interior Light
System< 9±4>
See Electronically Controlled
Transmiss ion and A/T Indicator
System< 4±3> < 5±3>
See Illumination Sy st em
< 10±4>
IG33
V± W V± W
V±W V±WB B
B J15
JUNCTION
CONNE CT ORFrom Cruise Control
ECU< 17±4> From Engine Contr ol
Module
< 2±7> < 3±9> < 4±3> < 5±3>
IJ15
1
See Cruise Control
System< 17±2> Y±B Y±B
IF Left kick
panel
O 1
OIL PRESSURE SWJ 5
JUNCTI ON
CONNE CTOR
W± B W± B
A A See Char ging Sys tem
< 1±4> A
B
C
D
E
F
G
H
I* 4 : TMMK Made, TMC Made USA w/ Traction Control
* 5 : Speedometer * 3 : Except * 4
W± B IG36
1
Combination M eter
B±O From Engine
Control Module
< 2±12> < 3±9>
C 8 C 9,
COMBINATION METERABC10, C* 6 : w/ Daytime Running Light
* 7 : w/o Day time Running Light
Fr om A/C Contr ol
Assembly< 29±5>V±W
