Toyota Supports ASE CertificationPage 1 of 2
PG008-02Title:
REPLACEMENT CERTIFICATION LABELS
Models:
All Models
Technical Service
BULLETIN
January 18, 2002
TSB UPDATE NOTICE:
The information contained in this TSB updates PG006±01 dated May 4, 2001.
Revised text is red
and underlined. The changes will take place February 1, 2002.
Replacement Certification Labels (vinyl label affixed to driver's door or door post)
may be available from Toyota providing the request meets one of the criteria
listed below.
Certification Label Location
MFD.BY: TOYOTA MOTOR MANUFACTURING
CANADA INC. 10/01
GVWR 3935LB GAWR FR 1970LB RR 1985LB
THIS VEHICLE CONFORMS TO ALL APPLICABLE
FEDERAL MOTOR VEHICLE SAFETY, BUMPER, AND
THEFT PREVENTION STANDARDS IN EFFECT ON
THE DATE OF MANUFACTURE SHOWN ABOVE.
XT0XX00X0X000000 PASS.CAR
C/TR:3L5/FB14 MODEL:ZZE134L ± DHPNKA
A/TM:±04A/U341F MADE IN CANADA
S26 AA01904759
All Toyota vehicles.
1. The vehicle is in an accident and the label is damaged or is attached to a part that will
be replaced during the repair.
NOTE:
Processing a new label
will be delayed significantly if the original certification label
is not available.
A replacement label MAY NOT be available if the vehicle is more than 5 years old
and the old label does not accompany this request.
2. The label is stolen.
To request a replacement label, complete a copy of the form on the back of this bulletin.
Your dealer parts account will be billed $25.00
for each replacement of a damaged or
stolen label.
NOTE:
All replacement labels for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Certification
Label Criteria
Procurement
Procedure
Warranty
Information
Page 4650 of 4770
DEALER CODE:
DEALER NAME:
ADDRESS:STREET
ADDRESS
CITY,
STATE,
ZIP
CODE
TELEPHONE:AREA
CODE,
TELEPHONE
NUMBER
CONTACT:FIRST
NAME,
LAST
NAME
REASON FOR REPLACEMENT
ACCIDENT DAMAGE
STOLEN
OTHER
REASON/EXPLANATION
PLEASE PROVIDE CORRECT VIN
APPLICATION FOR REPLACEMENT CERTIFICATION LABEL
ATTACH ORIGINAL LABEL HERE
DEALER INFORMATION
NOTE:
Original label MUST accompany this application or order will be significantly delayed.
MAIL (DO NOT FA X) THE COMPLETED REQUEST FORM WITH THE OLD LABEL TO:
TOYOTA MOTOR SALES, U.S.A. INC.
TECHNICAL COMPLIANCE DEPARTMENT, S207
19001 S. WESTERN AVENUE
TORRANCE, CA 90509±2991
( )
MFD.BY: TOYOTA MOTOR MANUFACTURING
CANADA INC. 10/01
GVWR 3935LB GAWR FR 1970LB RR 1985LB
THIS VEHICLE CONFORMS TO ALL APPLICABLE
FEDERAL MOTOR VEHICLE SAFETY, BUMPER, AND
THEFT PREVENTION STANDARDS IN EFFECT ON
THE DATE OF MANUFACTURE SHOWN ABOVE.
XT0XX00X0X000000 PASS.CAR
C/TR:3L5/FB14 MODEL:ZZE134L ± DHPNKA
A/TM:±04A/U341F MADE IN CANADA
S26 AA01904759
Page 4651 of 4770

Toyota Supports ASE CertificationPage 1 of 2
PG009-02Title:
REPLACEMENT VIN PLATES
Models:
All Models
Technical Service
BULLETIN
January 18, 2002
TSB UPDATE NOTICE:
The information contained in this TSB updates PG007±01 dated May 4, 2001.
Revised text is red
and underlined. The changes will take place February 1, 2002.
Replacement VIN plates (metal plates riveted to dashboard) may be available from
Toyota providing the request meets the criteria listed below.
VIN Plate Location
All Toyota vehicles.
The vehicle is in an accident and the plate is damaged.
NOTE:
The original plate to be replaced MUST accompany the request.
NOTE:
If a plate is stolen, be sure to contact the State Police or your State's Department of
Motor Vehicles (DMV). In most cases the State DMV will issue a unique number so that
the original number can be included on stolen vehicle listings. If this is the case, a
replacement plate is NOT available from Toyota. However, the original VIN, NOT the
state issued VIN, must be used on all warranty claims.
To request a replacement plate, complete a copy of the form on the back of this page.
Note that the damaged VIN plate MUST accompany the request form. Your dealer parts
account will be billed $25.00
for each replacement of a damaged plate.
NOTE:
All replacement plates for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Replacement
VIN Plate
Criteria
Procurement
Procedure
Warranty
Information
Page 4652 of 4770
DEALER CODE:
DEALER NAME:
ADDRESS:STREET
ADDRESS
CITY,
STATE,
ZIP
CODE
TELEPHONE:AREA
CODE,
TELEPHONE
NUMBER
CONTACT:FIRST
NAME,
LAST
NAME
REASON FOR REPLACEMENT
ACCIDENT DAMAGE
OTHER
REASON/EXPLANATION
PLEASE PROVIDE CORRECT VIN
APPLICATION FOR REPLACEMENT VIN PLATE
DEALER INFORMATION
MAIL (DO NOT FA X) THE COMPLETED REQUEST FORM WITH THE OLD PLATE TO:
TOYOTA MOTOR SALES, U.S.A. INC.
TECHNICAL COMPLIANCE DEPARTMENT, S207
19001 S. WESTERN AVENUE
TORRANCE, CA. 90509±2991
( )
ATTACH DAMAGED PLATE HERE
Page 4653 of 4770

Toyota Supports ASE CertificationPage 1 of 8
PG027-02Title:
SUSPENSION BALL JOINT INSPECTION
Models:
See Applicable Models
Technical Service
BULLETIN
December 4, 2002
This bulletin describes the inspection method and free play specification figures for
suspension ball joints. The on±vehicle inspection methods have been standardized.
1989 ± 1992 model year Cressida vehicles.
1989 ± 1998 model year Supra vehicles.
2001 ± 2003 model year Highlander vehicles.
1995 ± 2003 model year Avalon vehicles.
1989 ± 2003 model year Camry / Camry Solara vehicles.
1985 ± 2003 model year MR2 vehicles.
1990 ± 2003 model year Celica vehicles.
2001 ± 2003 model year Prius vehicles.
1988 ± 2003 model year Corolla / Corolla Matrix vehicles.
2000 ± 2003 model year ECHO vehicles.
1991± 1999 model year Tercel vehicles.
1991 ± 1999 model year Paseo vehicles.
1990 ± 1997 model year Previa vehicles.
1998 ± 2003 model year Sienna vehicles.
1996 ± 2003 model year RAV4 / RAV4 EV vehicles.
1999 ± 2003 model year Land Cruiser vehicles.
2001 ± 2003 model year Sequoia vehicles.
1989 ± 2003 model year 4Runner vehicles.
2000 ± 2003 model year Tundra vehicles.
1995 ± 2003 model year Tacoma vehicles.
1989 ± 1995 model year Truck vehicles.
1993 ± 1998 model year T±100 vehicles.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Warranty
Information
Page 4654 of 4770

SUSPENSION BALL JOINT INSPECTION ± PG027-02December 4, 2002
Page 2 of 8
MODELLOCATION
LOWER BALL JOINT OR SUSPENSION
BALL JOINTUPPER BALL JOINT
MODELLOCATION INSP.
METHODMAX. PLAYTURNING
TORQUEINSP.
METHODMAX. PLAYTURNING
TORQUE
Cressida
(MX8#)
Front1±(C)No Play
Felt40 in. lbf
(4.5 N m)
or Less
N/AN/AN/A
(MX8#)
1989 ± 1992
Rear3No Play
Felt31 in. lbf
(3.5 N m)
or Less
2±(A)No Play
Felt31 in. lbf
(3.5 N m)
or Less
Supra (MA70)
Front1±(A)0.4 mm
4 in. lbf
(0.5 Nm)
or Less
2 (A)No Play31 in. lbf
(3 5 N m)Su ra (MA70)
1989 ± 1994
Rear3No Play
Felt31 in. lbf
(3.5 N m)
or Less2±(A)No Play
Felt(3.5 N m)
or Less
Supra
(JZA80)
Front1±(A)0.4 mm
27 in. lbf
(3.0 N m)
or Less
2 (A)No Play31 in. lbf
(3 5 N m)(JZA80)
1994 ± 1998Rear1±(A)No Play
Felt31 in. lbf
(3.5 N m)
or Less2±(A)No Play
Felt(3.5 N m)
or Less
Highlander
(ACU2#,
MCU2#)
2001 ± 2003
Front1±(C)No Play
Felt31 in. lbf
(3.5 N m)
or Less
N/AN/AN/A
Avalon
(MCX10, 20)
1995 ± 2003
Front1±(C)No Play
Felt31 in. lbf
(3.5 N m)
or Less
N/AN/AN/A
Camry,
Camry Solara
(SV2#,
VZV21,
VCV10,
MCV10, 20,
30
ACV 20, 30
SVX 10, 20)
1989 ± 2003
Front1±(C)No Play
Felt31 in. lbf
(3.5 N m)
or Less
N/AN/AN/A
Inspection
Information
Page 4655 of 4770

SUSPENSION BALL JOINT INSPECTION ± PG027-02December 4, 2002
Page 3 of 8
MODELLOCATION
LOWER BALL JOINT OR SUSPENSION
BALL JOINTUPPER BALL JOINT
MODELLOCATIONINSP.
METHODMAX. PLAYTURNING
TORQUEINSP.
METHODMAX. PLAYTURNING
TORQUE
Front1±(C)No Play
Felt27 in. lbf
(3.0 N m)
or Less
MR2
(AW1#)
1985 ± 1989
Rear1±(C)*1
3*2No Play
Felt
27 in. lbf
(3.0 N m)
or Less*
1
31 in. lbf
(3.5 N m)
or Less*
2
N/AN/AN/A
MR2
(SW2#)
Front
1 (C)No Play
22 in. lbf
(2.5 N m)
or Less
N/AN/AN/A(SW2#)
1990 ± 1996Rear
1±(C)No Play
Felt27 in. lbf
(3.0 N m)
or LessN/AN/AN/A
MR2
(ZZW30)
Front1±(C)
No Play
22 in. lbf
(2.5 N m)
or Less
N/AN/AN/A(ZZW30)
2000 ± 2003Rear3
No Play
Felt9 in. lbf
(1.0 N m)
or LessN/AN/AN/A
Celica
(AT180,
ST18#)
1990 ± 1993
Front1±(C)No Play
Felt35 in. lbf
(4.0 N m)
or Less
N/AN/AN/A
Celica
(AT200,
ST20#,
ZZT23#)
1994 ± 2003
Front1±(C)No Play
Felt44 in. lbf
(5.0 N m)
or Less
N/AN/AN/A
Prius
(NHW11)
2001 ± 2003
Front1±(C)No Play
Felt44 in. lbf
(5.0 N m)
or Less
N/AN/AN/A
Corolla
(AE9#, 10#)
1988 ± 2003
Front1±(C)No Play
Felt27 in. lbf
(3.0 N m)
or Less
N/AN/AN/A
Corolla/
Corolla Matrix
(AE10#,
ZZE11#, 13#)
1988 ± 2003
Front1±(C)No Play
Felt44 in. lbf
(5.0 N m)
or Less
N/AN/AN/A
ECHO
(NCP1#)
2000 ± 2003
Front1±(C)No Play
Felt31 in. lbf
(3.5 N m)
or Less
N/AN/AN/A
Tercel, Paseo
(EL4#, 5#)
1991 ± 1999
Front1±(C)No Play
Felt27 in. lbf
(3.0 N m)
or Less
N/AN/AN/A
Inspection
Information
(Continued)
Page 4656 of 4770

SUSPENSION BALL JOINT INSPECTION ± PG027-02December 4, 2002
Page 4 of 8
MODELLOCATION
LOWER BALL JOINT OR SUSPENSION
BALL JOINTUPPER BALL JOINT
MODELLOCATIONINSP.
METHODMAX. PLAYTURNING
TORQUEINSP.
METHODMAX. PLAYTURNING
TORQUE
Previa
(TCR1#, 2#)
1990 ± 1997
Front1±(C)No Play
Felt35 in. lbf
(4.0 N m)
or Less
N/AN/AN/A
Sienna
(MCL10)
1998 ± 2003
Front1±(C)No Play
Felt31 in. lbf
(3.5 N m)
or Less
N/AN/AN/A
RAV4/
RAV4 EV
(SXA1#
Front1±(C)No Play
Felt40 in. lbf
(4.5 N m)
or Less
N/AN/AN/A(SXA1#,
BEA11)
1996 ± 2000
Rear3No Play
Felt31 in. lbf
(3.5 N m)
or LessN/AN/AN/A
RAV4
(ACA2#)
2001 ± 2003
Front1±(C)No Play
Felt44 in. lbf
(5.0 N m)
or Less
N/AN/AN/A
Land Cruiser
100
(UZJ100)
1999 ± 2003
Front1±(A)No Play
Felt27 in. lbf
(3.0 N m)
or Less
2±(A)No Play
Felt40 in. lbf
(4.5 N m)
or Less
Sequoia
(UCK35, 45)
2001 ± 2003
Front1±(A)0.5 mm
22 in. lbf
(2.5 N m)
or Less
2±(A)No Play
Felt40 in. lbf
(4.5 N m)
or Less
4Runner
(VZN120,
13#, RN13#,
12#)
1989 ± 1995
Front1±(C)2.3 mm
53 in. lbf
(6.0 N m)
or Less
2±(B)No Play
FeltTurns
Smoothly
4Runner
(RZN18#,
VZN18#)
1996 ± 2003
Front1±(A)0.5 mm
22 in. lbf
(2.5 N m)
or Less
2±(A)No Play
Felt40 in. lbf
(4.5 N m)
or Less
Tundra
(VCK30, 40,
UCK30, 40)
2000 ± 2003
Front1±(A)0.5 mm
22 in. lbf
(2.5 N m)
or Less
2±(A)No Play
Felt40 in. lbf
(4.5 N m)
or Less
Inspection
Information
(Continued)
