TOYOTA CAMRY 2000 Service Repair Manual EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 10 of 14
This diagnostic process tests the EVAP System. The following diagnostic tips may be
used in conjunction with the Diagnostic

Page 4570 of 4770

TOYOTA CAMRY 2000 Service Repair Manual EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 11 of 14
Diagnostic Process Flow Chart
(Continued on following page)
PRELIMINARY CHECK
� Fuel level should be between
1/4 and 3/4
�V

EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 11 of 14
Diagnostic Process Flow Chart
(Continued on following page)
PRELIMINARY CHECK
Fuel level should be between
1/4 and 3/4
Visually inspect for presence
of Fuel/Gas Cap
DO NOT TIGHTEN OR REMOVE!
PRESSURIZE EVAP SYSTEM (System Integrity Check)
This test checks for leaks in the canister and fuel tank sides. The CCV and Air Inlet Lines will be checked
separately.
A) Clamp the air drain hose on the charcoal canister with the supplied hose pliers from the EVAP System
Pressure Test Kit.
B) Locate the vapor pressure sensor. If the vapor pressure sensor has two hoses connected to it,
disconnect the hose between the air drain hose fitting at the vapor pressure sensor and plug the hose.
C) Connect the pressure supply hose from the Pressure Test Kit to the Green EVAP System Service Port
located on the EVAP Purge VSV line in the engine compartment.
D) Using the directions on the inside of the EVAP System Pressure Test Kit lid, pressurize the EVAP
system. Once pressurized, turn off the pump and seal the system (Pressure Hold Switch to ªClosedº
and Vent Switch to ªClosed).
E) After 30 seconds, note the pump pressure gauge reading and the Scan Tool vapor pressure
sensor reading.
F) Compare the readings to one of the four conditions listed below and proceed as directed.
DO NOT PROCEED! NG
OK
SCAN TOOL SETUP
A) Connect Scan Tool to DLC3 on vehicle.
B) Go to the SETUP menu and select UNIT CONVERSION.
C) Under VAPOR PRESSURE, Select ABS for absolute pressure, and mmHg for millimeters of mercury.
This is to match the Repair Manual specifications.
D) Go back to FUNCTION SELECT menu and select ENHANCED OBD II.
E) Select NORMAL MODE. Then select CURRENT DATA and USER SELECT.
F) Using the arrow key, select VAPOR PRESS from the DATA LIST and select YES.
G) Press ENTER. You will now be able to monitor the Vapor Pressure Sensor reading.
START
If vehicle is ECHO, go directly to ªECHO Canister and Tank Leak Checkº on page 14.
If vehicle is not ECHO, follow the flow chart below.
Diagnostic
Tips for Late
Type EVAP
System
(Continued)

Page 4571 of 4770

TOYOTA CAMRY 2000 Service Repair Manual EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 12 of 14
Pump pressure
gauge and vapor
pressure above
atmospheric
pressure (above 762
mmHg). No leak in
canister or tank.Pump p

EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 12 of 14
Pump pressure
gauge and vapor
pressure above
atmospheric
pressure (above 762
mmHg). No leak in
canister or tank.Pump pressure
gauge zero, vapor
pressure above
atmospheric
pressure (above 762
mmHg). Leak is on
canister side of
system.Pump pressure
gauge is above
atmospheric
pressure (above
zero), vapor
pressure is at
762 mmHg. Leak is
on the fuel tank side
of system.Pump pressure
gauge at zero,
vapor pressure is
at 762 mmHg. The
leak(s) is/are on the
canister and tank
sides or a leak at a
point common to
both sides of system.
Remove hose pliers
from the air drain
hose on the charcoal
canister before
proceeding with
additional checks.Remove hose pliers
from the air drain
hose on the charcoal
canister before
proceeding with
additional checks.Remove hose pliers
from the air drain
hose on the charcoal
canister before
proceeding with
additional checks.
Go to CCV/Air Inlet
Line Check.Go to ªCanister Leak
Check.º Diagram on
page 13.Go to ªFuel Tank
Leak Check.º
Diagram on page 13.Go to ªFuel Tank
Leak Check.º
Diagram on page 13.
Remove hose pliers
from the air drain
hose on the charcoal
canister before
proceeding with
additional checks.
Go to ªReturn Vehicle to Serviceº on page 14.
CCV and Air Inlet Line Check. (Except ECHO)
A) Disconnect the air inlet line from the charcoal canister.
B) Using the supplied step±down brass adapter (or equivalent) connect the Pressure Supply Hose to
the air inlet line.
C) Using the Scan Tool Active Test, turn on the CCV. This will close the CCV.
D) Pressurize the line. Once pressurized, turn off the pump and seal the line (Pressure Hold Switch to
ªClosedº and Vent Switch to ªClosedº). Pressure should hold. If not, check CCV and connections.
E) Next, using the Scan Tool, turn off the CCV. This will open the CCV. The pressure should decrease.
If not, check the CCV and connections.
F) After completing the test, reconnect air inlet line to charcoal canister. Diagnostic Process Flow Chart (Continued)
(Continued from previous page)
Diagnostic
Tips for Late
Type EVAP
System
(Continued)

Page 4572 of 4770

TOYOTA CAMRY 2000 Service Repair Manual EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 13 of 14
Disconnect
EVAP Hose Here
A. Using the supplied brass step±down adapter, disconnect the EVAP hose from
the charcoal caniste

Page 4573 of 4770

TOYOTA CAMRY 2000 Service Repair Manual EVAP SYSTEM OPERATION INFORMATION ± EG005-01 April 27, 2001
Page 14 of 14
ECHO Canister and Tank Leak Check
A. Connect the Pressure Supply hose from the Pressure Test Kit to the Green EVAP
System Ser

Page 4574 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 1
EG007-02Title:
GENERAL MAINTENANCE TIP
Models:
All 93 ± 03 Models
Technical Service
BULLETIN
March 22, 2002

To help prevent unnecessary complications

Page 4575 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 5
EG013-02Title:
M.I.L. ON" P0440, P0441 & P0446
Models:
98 ± 99 Camry & Solara
Technical Service
BULLETIN
July 12, 2002

Under certain driving conditi

Page 4576 of 4770

TOYOTA CAMRY 2000 Service Repair Manual M.I.L. ªONº P0440, P0441 & P0446 ± EG013-02July 12, 2002
Page 2 of 5
Test VSV Operation Using ACTIVE TEST on the Toyota Diagnostic Tester
1. Test operation of the Vapor Pressure Sensor VSV using th
