TOYOTA CAMRY 2000 Service Repair Manual PROGRAMMING OEM WIRELESS DOOR LOCK REMOTE TRANSMITTERS ± EL008±98 December 4, 1998
Page 2 of 2
The PRG (Program) circuit of the
Wireless Door Lock ECU is grounded to
perform programming. This can b

Page 4594 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 6
EL008-02Title:
WIRELESS TRANSMITTER &
PROGRAMMING GUIDE
Models:
All Applicable
Technical Service
BULLETIN
December 20, 2002

TSB REVISION NOTICE:
�Februa

Toyota Supports ASE CertificationPage 1 of 6
EL008-02Title:
WIRELESS TRANSMITTER &
PROGRAMMING GUIDE
Models:
All Applicable
Technical Service
BULLETIN
December 20, 2002

TSB REVISION NOTICE:
February 28, 2003: In Wireless Transmitter Identification section (pages 5 and 6),
Figures 5, 9, 10, 12, and 13 updated to include 2003 model year; Figure 11 updated
to include 1999 and 2003 model year.
January 17, 2003: 2003 model year added to Solara in the Application Chart on
page 3.
The information contained in this TSB supercedes TSB EL010±01, dated October 26,
2001. The previous TSB, EL010±01, should be discarded.
Difficulties during Remote Keyless Entry Transmitter Programming can arise due to
confusion between Toyota Factory Wireless systems and Toyota Port/Dealer installed
systems. This bulletin will assist in identifying the system/correct remote transmitters for
each vehicle, and provide the location of the most accurate programming procedure for
each system.
All applicable Toyota vehicles.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
The following table contains all of the necessary information to correctly identify the type
of system installed, and where to go to get programming procedures for each vehicle.
NOTE:
Should a vehicle having both VIP and Factory systems available (as identified in the
following table) be brought in without any remotes (or one non±working remote), use
the following tips to help determine which type of wireless system (O.E. or PIO/DIO)
the vehicle has.
Look at the Trim Level of the vehicle. Higher±grade vehicles will tend to have O.E.
systems, while entry±grade vehicles will tend to have VIP. For example, the 2001
Camry XLE has Factory RKE, but the LE and CE grades have VIP.
Look for a ªStatus Monitorº with a glass breakage sensor and an LED externally
installed into the dashboard or on the center console. Most VIP systems will have
this.
Locate the ECU (refer to the applicable vehicle VIP Manual installation instructions
for location). Once located, refer to the part label.
Attempt to perform the factory wireless programming procedure to get a response
from the vehicle. Select the ªconfirmation modeº and see if any ªLock/Unlockº
response is received, if so, the vehicle has a factory system.
ELECTRICAL
Introduction
Applicable
Vehicles
Warranty
Information
System
Identification

Page 4595 of 4770

TOYOTA CAMRY 2000 Service Repair Manual WIRELESS TRANSMITTER & PROGRAMMING GUIDE ± EL008-02 RevisedDecember 20, 2002
Page 2 of 6
APPLICATIONDEALER/PORT INSTALLEDFACTORY INSTALLED
VEHICLEYEARSYSTEM/REMOTEPROGRAMMINGFACTORY
REMOTEPROGRAMMING

WIRELESS TRANSMITTER & PROGRAMMING GUIDE ± EL008-02 RevisedDecember 20, 2002
Page 2 of 6
APPLICATIONDEALER/PORT INSTALLEDFACTORY INSTALLED
VEHICLEYEARSYSTEM/REMOTEPROGRAMMINGFACTORY
REMOTEPROGRAMMING
1995TVSS / Fig. 2 *1TVSS Owner's
Guide
Fig. 8TSB EL003 99
Al
1996 ± 1997RS3000 / Fig. 3TSB AX005 99
Fig. 8TSB ± EL003±99
Avalon1998 ± 1999RS3000 / Fig. 4TSB ± AX005±99
2000 ± 2001RS3200 / Fig. 52000 VIP Manual *6Fig. 9 *2RM 02 V2, BE±99
2002 ± 2003N/AN/A
g
TSB ± EL004±01
1990 ± 1994TVSS / Fig. 1 *1TVSS Owner's
1995TVSS / Fig. 2 *1TVSS Owner s
GuideN/AN/A
1996RS3000 / Fig 3Camry1997RS3000 / Fig. 3TSB ± AX005±99Fig 7TSB EL008 98y
1998 ± 1999RS3000 / Fig. 4Fig. 7TSB ± EL008±98
2000 ± 2001RS3200 /2000 VIP Manual*6Fig. 11RM 01 V2, BE±86
2002 ± 2003
RS3200 /
Fig. 5 or 6 *72000 VIP Manual *6
Fig. 9 *2TSB ± EL004±01
1990 ± 1994TVSS / Fig. 1 *1TVSS Owner's
1995TVSS / Fig. 2 *1TVSS Owner s
Guide
N/AN/ACelica1996 ± 1997RS3000 / Fig. 3TSB AX005 99
N/AN/A
1998 ± 1999RS3000 / Fig. 4TSB ± AX005±99
2000 ± 2003RS3200 / Fig. 52000 VIP Manual *6Fig. 11TSB ± EL004±01
1990 ± 1994TVSS / Fig. 1 *1TVSS Owner's
1995TVSS / Fig. 2 *1TVSS Owner s
Guide
N/AN/ACorolla1996 ± 1997RS3000 / Fig. 3TSB AX005 99
N/AN/A
1998 ± 2002RS3000 / Fig. 4TSB ± AX005±99
2003RS3200 / Fig. 52000 VIP Manual *6Fig. 11TSB ± EL004±01
Cressida1991 ± 1992TDSE / Fig. 1 *1TVSS Owner's
GuideN/AN/A
ECHO2000 ± 2003RS3200 / Fig. 52000 VIP Manual *6Fig. 11TSB ± EL004±01
1990 ± 1994TVSS / Fig. 1 *1TVSS Owner's
1995TVSS / Fig. 2 *1TVSS Owner s
Guide
N/AN/A1996 ± 1997RS3000 / Fig. 3N/AN/A
4Runner1998RS3000 / Fig 4TSB ± AX005±99
1999RS3000 / Fig. 4
RM 02 V2 BE 982000 ± 2002RS3200 / Fig. 52000 VIP Manual *6Fig. 10 *5RM 02 V2, BE±98
2003N/AN/A
g
RM 03, 73±16
Highlander2001 ± 2003N/AN/AFig. 11TSB ± EL004±01
1991 ± 1994TVSS / Fig. 1 *1TVSS Owner's
1995TVSS / Fig. 2 *1TVSS Owner s
GuideN/AN/A
Land Cruiser1996 ± 1997RS3000 / Fig. 3TSB ± AX005±99Land Cruiser
1998 ± 2002N/AN/AFig. 13
RM 02 V1,
DI±624
2003
N/AN/AFig. 13
RM 03 V2, BE±93
Application
Chart

Page 4596 of 4770

TOYOTA CAMRY 2000 Service Repair Manual WIRELESS TRANSMITTER & PROGRAMMING GUIDE ± EL008-02 RevisedDecember 20, 2002
Page 3 of 6
APPLICATIONDEALER/PORT INSTALLEDFACTORY INSTALLED
VEHICLEYEARSYSTEM/REMOTEPROGRAMMINGFACTORY
REMOTEPROGRAMMIN

Page 4597 of 4770

TOYOTA CAMRY 2000 Service Repair Manual WIRELESS TRANSMITTER & PROGRAMMING GUIDE ± EL008-02 RevisedDecember 20, 2002
Page 4 of 6
APPLICATIONDEALER/PORT INSTALLEDFACTORY INSTALLED
VEHICLEYEARSYSTEM/REMOTEPROGRAMMINGFACTORY
REMOTEPROGRAMMIN

Page 4598 of 4770

TOYOTA CAMRY 2000 Service Repair Manual WIRELESS TRANSMITTER & PROGRAMMING GUIDE ± EL008-02 RevisedDecember 20, 2002
Page 5 of 6
DEALER or PORT INSTALLED SYSTEMS
Figure 1.
TVSS/TDSE
1990 ± 1994Figure 2.
TVSS/TDSE
1995Figure 3.
RS3000 (BL

Page 4599 of 4770

TOYOTA CAMRY 2000 Service Repair Manual WIRELESS TRANSMITTER & PROGRAMMING GUIDE ± EL008-02 RevisedDecember 20, 2002
Page 6 of 6
FACTORY INSTALLED or ªORIGINAL EQUIPMENTº SYSTEMS
Figure 7.
O.E. 3 Button
1997 ± 1999Figure 8.
O.E. 3 Butt

Page 4600 of 4770

TOYOTA CAMRY 2000 Service Repair Manual OBSOLETE
PLEASE SEE EL008±02
Toyota Supports ASE CertificationPage 1 of 5
EL010-01Title:
WIRELESS TRANSMITTER &
PROGRAMMING GUIDE
Models:
All Applicable
Technical Service
BULLETIN
October 26, 2001
