Page 4641 of 4770

CA/50 STATE CERTIFIED EMISSION CONTROL UNDERHOOD LABEL ORDERING ± PG006±00 March 31, 2000
Page 6 of 6
MODELENGINE NAMETRANSMISSIONEMISSIONS*PART NUMBERS
ECHO1NZ±FEAllUSA11298±21010
Corolla1ZZ±FEAllUSA11298±22032
Celica
1ZZ±FEAllUSA11298±22080
Celica
2ZZ±GEAllUSA11298±22050
5S±FEAllUSA11298±7A590
Camry1MZ±FEM/TMUSA11298±20320
1MZ±FEA/TMCA11298±20310
5S±FEAllUSA11298±7A590
Camry Solara1MZ±FEM/TMUSA11298±20320
1MZ±FEA/TMCA11298±20310
Camry Solara5S±FEA/TMUSA11298±7A590Camry Solara
Convertible1MZ±FEA/TMCA11298±20310
Camry (CNG)5S±FNEA/TMUSA11298±7A640
Avalon1MZ±FEA/TMUSA11298±20290
Sienna1MZ±FEA/TMUSA11298±20340
RAV43S±FE (2WD/4WD)AllUSA11298±7A620
3RZ±FE (2WD)AllUSA11298±75550
4Runner3RZ±FE (4WD)M/TMUSA11298±75550
5VZ±FE (2WD/4WD)AllUSA11298±62690
2RZ±FE (2WD)AllUSA11298±75510
3RZ±FE (2WD/4WD)A/TMUSA11298±75530
3RZ±FE
(4WD XtraCab)M/TMUSA11298±75530
Tacoma
3RZ±FE
(4WD XtraCab)A/TMUSA11298±75550
3RZ±FE
(PreRunner)A/TMUSA11298±75530
5VZ±FE
(2WD XtraCab)AllUSA11298±62670
5VZ±FE
(4WD & PreRunner)AllUSA11298±62690
T ndra
5VZ±FEAllCA11298±62640
Tundra
2UZ±FEA/TMUSA11298±50241
Land Cruiser2UZ±FEA/TMUSA11298±50182
* CA = California Emission Specification, USA = 50 State Emission Specification
2000 MY CA/50
State Certified
Emission
Control Labels
Page 4642 of 4770

Toyota Supports ASE CertificationPage 1 of 2
PG006-01Title:
REPLACEMENT CERTIFICATION LABELS
Models:
All Models
Technical Service
BULLETIN
May 4, 2001
Replacement Certification Labels (vinyl label affixed to driver's door or door post)
may be available from Toyota providing the request meets one of the criteria
listed below.
Certification Label Location
All Toyota vehicles.
1. The vehicle is in an accident and the label is damaged or is attached to a part that will
be replaced during the repair.
NOTE:
Processing a new label
will be delayed significantly if the old certification label is
not available.
A replacement label MAY NOT be available if the vehicle is more than 5 years old
and the old label does not accompany this request.
2. The label is stolen.
To request a replacement label, complete a copy of the form on the back of this bulletin.
Your dealer parts account will be billed $10.00 for each replacement of a damaged or
stolen label.
NOTE:
All replacement labels for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Certification
Label Criteria
Procurement
Procedure
Warranty
Information
Page 4643 of 4770
DEALER CODE:
DEALER NAME:
ADDRESS:STREET
ADDRESS
CITY,
STATE,
ZIP
CODE
TELEPHONE:AREA
CODE,
TELEPHONE
NUMBER
CONTACT:FIRST
NAME,
LAST
NAME
REASON FOR REPLACEMENT
ACCIDENT DAMAGE
STOLEN
OTHER
REASON/EXPLANATION
PLEASE PROVIDE CORRECT VIN
APPLICATION FOR REPLACEMENT CERTIFICATION LABEL
ATTACH ORIGINAL LABEL HERE
DEALER INFORMATION
NOTE:
Original label MUST accompany this application or order will be significantly delayed.
MAIL (DO NOT FA X) THE COMPLETED REQUEST FORM WITH THE OLD LABEL TO:
TOYOTA MOTOR SALES, U.S.A. INC.
TECHNICAL COMPLIANCE DEPARTMENT, S207
19001 S. WESTERN AVENUE
TORRANCE, CA 90509±2991
( )
Page 4644 of 4770

Toyota Supports ASE CertificationPage 1 of 3
PG006±03
Title:
WARRANTY PARTS
MARKING PROCEDURE
Models:
All Models
Technical Service
BULLETIN
September 26, 2003
Effective September 1, 2003, all warranty parts (as indicated on the next page) must be
marked in the area or location of the failure. The technician should complete this
procedure after the failed part has been removed from the vehicle and before the part is
placed in the 10±bin storage. (Exchanged parts and remanufactured parts are not
included in this procedure.)
Failed parts marking will be beneficial in detecting and resolving product and parts quality
issues. This will also offer additional opportunities to make future enhancements to our
parts and products.
Parts are subject to random inspection in the dealership by field representatives to
ensure compliance with this new policy.
Failure to comply with this policy may result in a debit of the corresponding
warranty claim(s).
All models.
All technicians must follow these procedures to ensure proper parts marking:
Wipe the part clean (no excess fluid should be present).
Indicate area of defect or failure by marking the specific part(s) with a water
resistant permanent marker. Use a color that can be easily seen against the
background of the part being marked. For dark surfaces the color yellow is highly
recommended as well as the color black for light surfaces.
Mark the area of failure or defect by drawing a circle, a square, pointing an arrow
or adhering tape with an indication of the failed or defect location.
Attach a completed Warranty Parts Tag (M/N 00404±PRETN±TAGS) to the
marked part.
All other parts recovery/shipping policies and procedures apply
.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Parts
Marking
Procedure
Warranty
Information
Page 4645 of 4770

WARRANTY PARTS MARKING PROCEDURE ± PG006-03September 26, 2003
Page 2 of 3
Dealers are requested to mark the location of the failure of all warranty parts that are
listed below.
This list is not inclusive. There may be other components that can be
marked in the area of failure. All other parts that can be marked should be marked.
assist grip assy headlamps
audio (blemish) headliner
back door garnish hoses
bumper covers instrument panel safety pad sub±assy
cargo cover (retractable) Interior light assemblies and covers
carpet knobs, levers, handles
clutch disc l/pulley pump assy
clutch flywheel mirrors (side and rearview)
combination meter glass navigation or VES screens
console and components pillar garnish
cowl assy rack and pinion/power steering gear assy
cowl side trim sub±assy radiator
cupholders room partition board
cylinder head cover sub±assy rotors (mark where min. runout is exceeded or warped)
dash panel insulator assy seat covers/cushions
dashboard and trim seat tracks
disc wheel soft trim
display panels spare tire cover
door handle assy steering column cover
door moulding steering wheel
door trim panel & molding tail lamps and covers
emblems transmission oil pan
engine oil pan visor
exhaust manifold washer jar
floor and cargo mats wheel cap
gear shift knob wheels
grills
Parts
Marking
Requirement
Parts
Marking
List
Page 4646 of 4770
WARRANTY PARTS MARKING PROCEDURE ± PG006-03September 26, 2003
Page 3 of 3
NOTE:
The following parts do not have to be marked unless the technician can determine
failure and location.
air induction/ejection systems fuel injection systems
all computers fuel injectors
alternators fuel pump
audio (internal) ignition system
batteries internal engine components
bearings internal transmission components
belts oil cooler
catalytic converter power door lock switches
crankshaft remanufactured parts
cruise control starters
distributors suspension components
EGR systems valve covers
engine control systems window regulators
exchange parts wiper motors
exhaust systems
Parts
Marking
List
(Continued)
Page 4647 of 4770

Toyota Supports ASE CertificationPage 1 of 2
PG007-01Title:
REPLACEMENT VIN PLATES
Models:
All Models
Technical Service
BULLETIN
May 4, 2001
Replacement VIN plates (metal plates riveted to dashboard) may be available from
Toyota providing the request meets the criteria listed below.
VIN Plate Location
All Toyota vehicles.
The vehicle is in an accident and the plate is damaged.
NOTE:
The original plate to be replaced MUST accompany the request.
NOTE:
If a plate is stolen, be sure to contact the State Police or your State's Department of
Motor Vehicles (DMV). In most cases the State DMV will issue a unique number so that
the original number can be included on stolen vehicle listings. If this is the case, a
replacement plate is NOT available from Toyota. However, the original VIN, NOT the
state issued VIN, must be used on all warranty claims.
To request a replacement plate, complete a copy of the form on the back of this page.
Note that the damaged VIN plate MUST accompany the request form. Your dealer parts
account will be billed $10.00 for each replacement of a damaged plate.
NOTE:
All replacement plates for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Replacement
VIN Plate
Criteria
Procurement
Procedure
Warranty
Information
Page 4648 of 4770
DEALER CODE:
DEALER NAME:
ADDRESS:STREET
ADDRESS
CITY,
STATE,
ZIP
CODE
TELEPHONE:AREA
CODE,
TELEPHONE
NUMBER
CONTACT:FIRST
NAME,
LAST
NAME
REASON FOR REPLACEMENT
ACCIDENT DAMAGE
OTHER
REASON/EXPLANATION
PLEASE PROVIDE CORRECT VIN
APPLICATION FOR REPLACEMENT VIN PLATE
DEALER INFORMATION
MAIL (DO NOT FA X) THE COMPLETED REQUEST FORM WITH THE OLD PLATE TO:
TOYOTA MOTOR SALES, U.S.A. INC.
TECHNICAL COMPLIANCE DEPARTMENT, S207
19001 S. WESTERN AVENUE
TORRANCE, CA. 90509±2991
( )
ATTACH DAMAGED PLATE HERE
