Page 4185 of 4770
H01584
Slider
Disconnection is completed Slider
RS±10
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
2155 Author: Date:
14. DISCONNECTION OF SIDE AIRBAG CONNECTOR
(a) Place a finger on the slider.
(b) Slide the slider to release lock.
(c) Disconnect the connector.
Page 4186 of 4770
H01585
SliderSlider
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
RS±11
2156 Author: Date:
15. CONNECTION OF SIDE AIRBAG CONNECTOR
(a) Align a lock part of male connector and a slider of female
connector in the same direction as shown in the illustra-
tion, fit in them without rubbing.
(b) Make sure to insert until they are locked. After fitting in pull
them slightly to check that they are locked. (When locked,
make sure that the outer returns to its original position and
sound at the time of fitting in can be heard.)
HINT:
As the slider slides, do not touch it.
Be careful not to deform the release board. If the release
board is deformed, replace it with a new one.
Page 4187 of 4770
H01586
Slider
Disconnection is completed Slider
RS±12
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
2157 Author: Date:
16. DISCONNECTION OF CONNECTORS FOR FRONT
PASSENGER AIRBAG ASSEMBLY
(a) Place a finger on the slider.
(b) Slide the slider to release lock.
(c) Disconnect the connector.
Page 4188 of 4770
H01587
Slider
Slider
± SUPPLEMENTAL RESTRAINT SYSTEMSRS AIRBAG
RS±13
2158 Author: Date:
17. CONNECTION OF CONNECTORS FOR FRONT PAS-
SENGER AIRBAG ASSEMBLY
(a) Align a lock part of male connector and a slider of female
connector in the same direction as shown in the illustra-
tion, fit in them without rubbing.
(b) Make sure to insert until they are locked. After fitting in pull
them slightly to check that they are locked. (When locked,
make sure that the outer returns to its original position and
sound at the time of fitting in can be heard.)
HINT:
As the slider slides, do not touch it.
Be careful not to deform the release board. If the release
board is deformed, replace it with a new one.
Page 4189 of 4770
RS00Y±20
H03294
Column Upper Cover
Spiral CableSteering Wheel
Steering Wheel Pad
Column Lower Cover
N´m (kgf´cm, ft´lbf) : Specified torque
7.1 (72, 63 in.´lbf)
35 (360, 26)
Steering Wheel Lower
No.2 Cover
Steering Wheel Lower
No.2 Cover
Torx Screw
RS±14
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2159 Author: Date:
STEERING WHEEL PAD AND SPIRAL CABLE
COMPONENTS
Page 4190 of 4770
RS00Z±14
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±15
2160 Author: Date:
REMOVAL
HINT:
For step 1 to 4, refer to page SR±11.
1. REMOVE STEERING WHEEL PAD
2. REMOVE STEERING WHEEL
3. REMOVE UPPER AND LOWER COLUMN COVERS
4. REMOVE SPIRAL CABLE
Page 4191 of 4770

RS010±19
W03512
W03513
W03521
Horn Button
Contact Plate
RS±16
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2161 Author: Date:
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
(a) Do a diagnostic system check.
(See page DI±626)
(b) Do a visual check which includes the following items with
the steering wheel pad (with airbag) installed in the ve-
hicle.
Check cuts, minute cracks or marked discoloration on the
steering wheel pad top surface and in the grooved por-
tion.
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
NOT DEPLOYED
(a) Do a diagnostic system check.
(See page DI±626)
(b) Do a visual check which includes the following items with
the steering wheel pad (with airbag) removed from the ve-
hicle.
Check cuts, minute cracks or marked discoloration
on the steering wheel pad top surface and in the
grooved portion.
Check cuts and cracks in wire harnesses, and chip-
ping in connectors.
Check the deformation of the horn button contact
plate on the steering wheel.
HINT:
If the horn button contact plate of the steering wheel is de-
formed, never repair it. Always replace the steering wheel
assembly with a new one.
Page 4192 of 4770

W03651
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±17
2162 Author: Date:
There should be no interference between the steering
wheel pad and steering wheel, and the clearance should
be uniform all the way around when the new steering
wheel pad is installed on the steering wheel.
CAUTION:
For removal and installation of the steering wheel pad, see
page SR±11 and SR±16, and be sure to follow the correct
procedure.
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
DEPLOYED
(a) Do a diagnostic system check.
(See page DI±626)
(b) Do a visual check which includes the following items with
the steering wheel pad (with airbag) removed from the ve-
hicle.
Check the deformation on the horn button contact
plate of the steering wheel.
Check the damage on the spiral cable connector
and wire harness.
HINT:
If the horn button contact plate of the steering wheel is de-
formed, never repair it. Always replace the steering wheel
assembly with a new one.
There should be no interference between the steering
wheel pad and steering wheel, and the clearance should
be uniform all the way around when the new steering
wheel pad is installed on the steering wheel.
