Page 4497 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001 Page 4 of 7 CONDITIONPOSSIBLE CAUSECOMMON REPAIR Guide pin mis±adjustedRe±adjust guide pin Mechanism unlatchedRe±adjust guide pin Damaged dr

Page 4498 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001 Page 5 of 7 �The recommended sliding roof removal and disassembly procedure is provided in the 2001 Camry Repair Manual, pages BO±62 through B

Page 4499 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001 Page 6 of 7 Rear Drain Cap Installation The Repair Manual recommends applying Seal Packing P/N 08826±00090 for installation of the drain cap.

Page 4500 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SLIDING ROOF DIAGNOSTIC TIPS ± BO020-01 August 17, 2001 Page 7 of 7 Glass Panel Adjustment 1. Glass Panel Closed, Skewed in the Opening Tilt the glass panel From the outside of the vehicle, loosen

Page 4501 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 3 BO020±99 Title: SEAT COVER LOOSENESS Models: 99 Camry & Sienna Technical Service BULLETIN December 17, 1999 On some 1999 Camry front seats and Sienna

Page 4502 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SEAT COVER LOOSENESS ± BO020±99 December 17, 1999 Page 2 of 3 1. For easier repair remove the complete seat assembly. 2. If necessary, remove the manual seat adjuster handle. 3. Bend the locking tab

Page 4503 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SEAT COVER LOOSENESS ± BO020±99 December 17, 1999 Page 3 of 3 6. Reassemble the seat cushion. 7. Bend the locking tabs over the cushion. 8. After reinstallation of the seat and manual seat adjuste

Page 4504 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Toyota Supports ASE CertificationPage 1 of 2 BO021±99 Title: SUNROOF OPERATION Models: 97 ± 99 TMMK Camry Technical Service BULLETIN December 17, 1999 Some 1997 ± 1999 TMMK Camry vehicles may
