REMOVAL
1. DRAIN ENGINE COOLANT
2. REMOVE AIR CLEANER CAP ASSEMBLY AND AIR
FILTER
3. REMOVE ENGINE RH FENDER APRON SEAL
4. REMOVE FRONT EXHAUST PIPE (See page EM±71)
5. REMOVE RH ENGINE MOUNTING STAY
6. REMOVE V±BANK COVER
(a) Using a 5 mm hexagon wrench, remove the 2 nuts.
(b) Disconnect the 2 clips, and remove the cover.
7. REMOVE HIGH±TENSION CORD SET
(See page IG±7)
8. REMOVE AIR INTAKE CHAMBER ASSEMBLY
(a) Disconnect the accelerator cable.
(b) Disconnect the A/T throttle cable.
(c) Disconnect the throttle position sensor connector.
(d) Disconnect the IAC valve connector.
(e) Disconnect the EGR gas temperature sensor connector.
(f) Disconnect the EGR valve position sensor connector.
(g) Disconnect the VSV connector for the ACIS.
(h) Disconnect the VSV connector for the EVAP.
(i) Disconnect the VSV connector for the EGR.
(j) Disconnect the DLC1 from the bracket on the intake air
control valve.
(k) Remove the 2 nuts, and disconnect the PS pressure tube
from the No.1 engine hanger.
(l) Disconnect the PCV hose from the PCV valve on the RH
cylinder head.
(m) Disconnect the ground strap and cable from the intake air
control valve for the ACIS.
(n) Disconnect the ground cable from the air intake chamber.
(o) Disconnect the brake booster vacuum hose from the air
intake chamber.
(p) Disconnect the 2 water bypass hoses from the throttle
body.
(q) Disconnect the air assist hose from the throttle body.
(r) Disconnect the purge hose from the pipe on emission
control valve set.
(s) Disconnect the 2 vacuum hoses from the vacuum tank for
the ACIS.
Page 3539 of 4770

S04790
Chamber Stay
Engine
HangerEGR
Pipe
S04791
8 mm Hexagon
Wrench
A01807
(b)
(c)
A01808
± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD
EM±33
1319 Author: Date:
(t) Disconnect the engine wire clamp from the emission con-
trol valve set.
(u) Remove the 2 bolts and No.1 engine hanger.
(v) Remove the 2 bolts and air intake chamber stay.
(w) Remove the 4 nuts, No.2 EGR pipe and 2 gaskets.
(x) Using an 8 mm hexagon wrench, remove the 2 bolts, 2
nuts, the air intake chamber assembly and gasket.
9. REMOVE INTAKE MANIFOLD ASSEMBLY
(a) Disconnect the 6 injector connectors.
(b) Disconnect the fuel inlet hose from the fuel filter.
CAUTION:
Perform connecting operations of the fuel tube connector
(quick type) after observing the precautions.
(See page SF±1)
(c) Disconnect the heater hose from the intake manifold.
(d) Remove the 9 bolts, 2 nuts, 2 plate washers, the intake
manifold, delivery pipes and injectors assembly.
NOTICE:
Be careful not to drop the injectors when removing
the delivery pipes.
Pay attention to put any hung load on the injector to
and from the side direction.
Page 3540 of 4770

P20049Gasket
A05077
Clamp
Clamp
Clamp
S04786
EM±34
± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD
1320 Author: Date:
10. REMOVE WATER OUTLET
(a) Disconnect the ECT sender gauge connector.
(b) Disconnect the ECT sensor connector.
(c) Disconnect the ground strap (connector).
(d) Disconnect the radiator hose.
(e) Disconnect the engine coolant reservoir hose.
(f) Remove the 2 bolts, 2 nuts and 2 plate washers.
(g) Disconnect the water bypass hose, and remove the water
outlet.
(h) Remove the 2 gaskets.
11. REMOVE GENERATOR DRIVE BELT
(See page CH±6)
12. REMOVE PS PUMP (See page SR±21)
13. REMOVE IGNITION COILS
14. REMOVE SPARK PLUGS
15. REMOVE TIMING BELT (See page EM±15)
16. REMOVE CAMSHAFT TIMING PULLEYS
(See page EM±15)
17. REMOVE NO.2 IDLER PULLEY (See page EM±15)
18. REMOVE NO.3 TIMING BELT COVER
(a) Disconnect the 3 engine wire clamps from the timing belt
cover.
(b) Remove the 6 bolts and timing belt cover.
19. DISCONNECT ENGINE WIRE PROTECTOR FROM
REAR SIDE
Remove the 2 nuts, and disconnect the engine wire protector
from the RH cylinder head and water inlet.
Page 3541 of 4770
S04787
A01812
S04789
Rear
Plate
Ground
Strap
Inlet Pipe
P18773
± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD
EM±35
1321 Author: Date:
20. DISCONNECT ENGINE WIRE AND PROTECTOR
FROM RH SIDE
Remove the 5 nuts, and disconnect the engine wire and protec-
tor from the RH cylinder head cover.
21. DISCONNECT ENGINE WIRE PROTECTOR FROM LH
SIDE
Remove the 2 bolts, and disconnect the engine wire protector
from the LH cylinder head cover.
22. DISCONNECT CYLINDER HEAD REAR PLATE
FROM LH CYLINDER HEAD
(a) Remove the nut, and disconnect the ground strap.
(b) Remove the bolt, and disconnect the rear plate.
23. DISCONNECT WATER INLET PIPE FROM LH
CYLINDER HEAD AND WATER INLET
(a) Remove the bolt, and disconnect the inlet pipe from the
water inlet.
(b) Remove the O±ring from the inlet pipe.
24. REMOVE NO.1 EGR PIPE
Remove the 4 nuts, EGR pipe and 2 gaskets.
Page 3542 of 4770
A06649
Manifold
Stay M/T and California A/T
Manifold
Stay
Except M/T and California A/T
P18769
A01522
Manifold
Stay California A/T
Manifold Stay
(Except M/T)Except California A/T
EM±36
± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD
1322 Author: Date:
25. REMOVE RH EXHAUST MANIFOLD
(a) California A/T:
Disconnect the A/F sensor connector.
(b) Except California A/T:
Disconnect the heated oxygen sensor (bank 1 sensor 1)
connector.
(c) Remove the bolt, nut and exhaust manifold stay.
(d) Remove the 6 nuts, exhaust manifold and gasket.
26. REMOVE PS PUMP BRACKET
Remove the 3 bolts and pump bracket.
27. REMOVE LH EXHAUST MANIFOLD
(a) California A/T:
Disconnect the A/F sensor connector.
(b) Except California A/T:
Disconnect the heated oxygen sensor (bank 2 sensor 1)
connector.
(c) Except M/T:
Remove the bolt, nut and exhaust manifold stay.
(d) Remove the 6 nuts, exhaust manifold and gasket.
28. REMOVE CAMSHAFT POSITION SENSOR
Page 3543 of 4770

P12710
O±Ring
A01816
P12811Align Intake
P12871
Main Gear
Sub±Gear
Service Bolt Intake
± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD
EM±37
1323 Author: Date:
29. REMOVE OIL DIPSTICK AND GUIDE
(a) Remove the bolt holding the dipstick guide to the LH cylin-
der head.
(b) Pull out the dipstick guide together with the dipstick from
the No.1 oil pan.
(c) Remove the O±ring from the dipstick guide.
30. REMOVE CYLINDER HEAD COVERS
Remove the 8 bolts, cylinder head cover and gasket. Remove
the 2 cylinder head covers.
31. REMOVE CAMSHAFTS OF RH CYLINDER HEAD
NOTICE:
Since the thrust clearance of the camshaft is small, the
camshaft must be held level while it is being removed. If the
camshaft is not kept level, the portion of the cylinder head
receiving the shaft thrust may crack or be damaged, caus-
ing the camshaft to seize or break. To avoid this, the follow-
ing steps should be carried out.
(a) Remove the intake camshaft.
(1) Align the timing marks (2 dot marks) of the camshaft
drive and driven gears by turning the camshaft with
a wrench.
(2) Secure the exhaust camshaft sub±gear to the main
gear with a service bolt.
Recommended service bolt:
Thread diameter6 mm
Thread pitch1.0 mm
Bolt length16 ± 20 mm (0.63 ± 0.79 in.)
Page 3544 of 4770

P12780
Intake
7 85 6
3 41 2
9 10
P12888
7
85
6
3
41
2
9
10 Exhaust
P12917
Align Intake EM±38
± ENGINE MECHANICAL (1MZ±FE)CYLINDER HEAD
1324 Author: Date:
HINT:
When removing the camshaft, mark certain that the torsional
spring force of the sub±gear has been eliminated by the above
operation.
(3) Uniformly loosen and remove the 10 bearing cap
bolts, in several passes, in the sequence shown.
(4) Remove the 5 bearing caps and intake camshaft.
(b) Remove the exhaust camshaft.
(1) Uniformly loosen and remove the 10 bearing cap
bolts, in several passes, in the sequence shown.
(2) Remove the 5 bearing caps, oil seal and exhaust
camshaft.
32. REMOVE CAMSHAFTS OF LH CYLINDER HEAD
NOTICE:
Since the thrust clearance of the camshaft is small, the
camshaft must be held level while it is being removed. If the
camshaft is not kept level, the portion of the cylinder head
receiving the shaft thrust may crack or be damaged, caus-
ing the camshaft to seize or break. To avoid this, the follow-
ing steps should be carried out.
(a) Remove the intake camshaft.
(1) Align the timing marks (1 dot mark) of the camshaft
drive and driven gears by turning the camshaft with
a wrench.
