TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 20 of 43
CHART 14:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P219

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 20 of 43
CHART 14:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P2198
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.55 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Response Monitor
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$31Time to change from Lean
(30.4 V) to Rich (.0.55 V)N/ASecondBetween 0 and
0.9 seconds
Time
$32Time to change from Rich
(.0.55 V) to Lean (30.4 V)N/ASecondBetween 0 and
0.9 seconds
If the time required to change is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.5 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.5 V
Multiply 0.3906%Between 0 and 90%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 20 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

Page 4738 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 21 of 43
CHART 15:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P219

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 21 of 43
CHART 15:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P2198
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and
0.42 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.48 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Response Monitor
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$31Time to change from Lean
(30.42 V) to Rich (.0.48 V)N/ASecondBetween 0 and
0.4 seconds
Time
$32Time to change from Rich
(.0.48 V) to Lean (30.42 V)N/ASecondBetween 0 and
0.4 seconds
If the time required to change is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and
0.45 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.55 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.5 V
Multiply 0.3906%Between 0 and 80%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 10 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

Page 4739 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 22 of 43
CHART 16:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST

Page 4740 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 23 of 43
CHART 17:
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST

Page 4741 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 24 of 43
CHART 18:
Rear O2S (Bank 1 Sensor 2) Voltage Monitor
Related DTCs: P0136
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTAND

Page 4742 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 25 of 43
CHART 19:
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST

Page 4743 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 26 of 43
CHART 20:
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST

Page 4744 of 4770

TOYOTA CAMRY 2000 Service Repair Manual O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 27 of 43
CHART 21:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P219
