Tube Type
ANTI±RUST TREATMENT
When replacing body panels, always apply body sealer, anti±rust agent or undercoat according to the re-
quirements of your country.
HINT: For further details, see the description given in Section AR of this manual.
BODY SEALER
Apply body sealer to the
required areas.ANTI±RUST AGENT (WAX)
Cartridge Type
Apply anti±rust agent to
following sections.

Inside of the hems of the
doors and hood.

Around the hinges of the
doors and hood.

Inside of the welded parts
with boxed cross±section.
UNDERCOAT
Apply undercoat to the underbody and
wheel housings.
Spray Gun Undercoating
(Oil base)Undercoating
(Water base)
INTRODUCTIONIN-13

Steel MetalUndercoat (ED Primer) Anti±Chipping PaintSecond Coat
Steel Metal Undercoat (ED Primer) Second Coat Top Coat
ANTI±RUST TREATMENT AFTER PAINTING PROCESS
1. ANTI±RUST AGENT (WAX) APPLICATION
To preserve impossible to paint areas from corro-
sion, always apply sufficient anti±rust agent (wax)
to the inside of the hemming areas of the doors and
hoods, and around the hinges, or the welded sur-
faces inside the boxed cross±section structure of
the side member, body pillar, etc.
ANTI±RUST AGENT (WAX) APPLICATION
REFERENCE: ANTI±RUST TREATMENT BY PAINTING
Painting prevents corrosion and protects the sheet metal from damage. In this section, anti±chipping paint
only for anti±corrosion purpose is described.
1. ANTI±CHIPPING PAINT
To prevent corrosion and protect the body from damage by flying stones, etc., apply anti±chipping paint
to the rocker panel, wheel arch areas, valance panel, etc.
HINT:
Depending on the model or the application area, there are cases where the application of anti±chipping
paint is necessary before the second coat or after the top coat.

Apply the anti±chipping paint
before the second coat.
Apply the anti±chipping paint
after the top coat.
Anti±Chipping Paint
Top Coat
ANTI±RUST TREATMENTAR-3

BODY PANEL ANTI±RUST AGENT (WAX) APPLICATION AREAS
HINT:
1. Whenever adjusting the doors and hoods, apply anti±rust agent (wax) around the hinges.
2. Even if partially repairing a part, apply anti±rust agent (wax) over the entire application area of the part.
3. Wipe off the anti±rust agent immediately with a rag soaked in a grease, wax and silicone remover, if
accidently applied to other areas.
Luggage Compartment Door
Hood Hinge
Fuel Filler Opening
Rid Hinge
Hood
Door
Front Door Hinge
Floor Door Hinge
ANTI±RUST TREATMENTAR-9

K±k
1,526
(60.08)
Vehicle Dimensions Left e Right
C±K
or
c±k
826
(35.52)1,712
(67.40)C±k
or
c±K
HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear.)
mm (in.)
(Three±Dimensional Distance)
Hole dia.
10 (0.39)
10 (0.39)
12 (0.47)
8 (0.315) nut
3R (0.12) Name
Radiator support standard hole
Radiator support standard hole
Front crossmember standard hole
Hood hinge installation nut±rear
Front Fender apron to cowl side member cut±out
portion Symbol
G, g
H, h
I, i
J, j
K, k Hole dia.
6 (0.24) nut
11 (0.43)
6 (0.24) nut
7 (0.28)
13 (0.51)
15 (0.59) Name
Front fender installation nut±front
Front spring support hole±inner
Front fender installation nut±raar
Cowl ventilator louver installation hole
Front side member standard hole
Front side member working hole Symbol
A, a
B, b
C, c
D
E, e
F, f
BODY DIMENSION DRAWINGS
ENGINE COMPARTMENT
BODY DIMENSIONSDI-3

1,312
(51.65)E±eF±f
1,484
(58.43)1,494
(58.82)G±gVehicle Dimensions Left e Right
1,496
(58.90)H±h
1,134
(44.65)I±i
1,238
(48.74)J±jK±k
1,492
(58.74)E±f
or
e±F
1,577
(62.09)1, 632
(64.25)E±h
or
e±H
1,454
(57.24)E±j
or
e±J
1,856
(69.13)F±j
or
f±JF±k
or
f±K
1,695
(66.73)H±i
or
h±I
1,626
(64.02)J±k
or
j±K
1,568
(61.73)
HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear).
(Three±Dimensional Distance)
mm (in.)
Hole dia.
13 (0.51)
13 (0.51) Name
Rocker panel assembly mark
Roof side rail assembly mark
Center body pillar assembly mark
Center body pillar assembly mark
Rear door hinge installation hole ± upper
Rear door hinge installation hole ± front Symbol
H, h
I, i
J, j
K, k
L, l
M, m Hole dia.
10 (0.39) nut
10 (0.39) nut Name
Roof panel / Front body pillar assembly mark
Cowl top panel / Front body pillar assembly mark
Front door hinge installation nut±rear
Front door hinge installation nut±rear
Front body pillar assembly mark
Front body pillar assembly mark
Rocker panel assembly mark Symbol
A, a
B, b
C, c
D, d
E, e
F, f
G, g
BODY OPENING AREAS (Side View: Front)
BODY DIMENSIONSDI-4

'99camry U
152
CAUTION

To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the garage door
opener box closed while driving.

Keep the remained spacers away
from children.
The miscellaneous box and garage door
opener box (stored in the glove box)
are interchangeable.
Removing the coverÐ
Half open the cover. Pinch each hinge and
pull it out of its pivot one by one as
shown above.
Do not remove the cover forcibly.Installing the coverÐ
Align the hinges to the pivots, and press
each hinge with a thumb until you hear a
click.
Make sure that the cover opens and
closes smoothly.

BO5235
Centering Bolt Bolt with Washer
BO0L1±01
N20963
N20964
N20965
BO±10
± BODYHOOD
2358 Author: Date:
HOOD
ADJUSTMENT
HINT:
Since the centering bolt is used as the hood hinge and lock set
bolt, the hood and lock can not be adjusted with it on. Substitute
a bolt and washer for the centering bolt.
1. ADJUST HOOD IN FORWARD/REARWARD AND
LEFT/RIGHT DIRECTIONS
Adjust the hood by loosening the hood side hinge bolts.
Torque: 26 N´m (260 kgf´cm, 19 ft´lbf)
2. ADJUST FRONT EDGE OF HOOD IN VERTICAL
DIRECTIONS
Adjust the hood by turning the cushions.
3. ADJUST HOOD LOCK
(a) Replace each centering bolt with a regular bolt and wash-
er.
Torque: 8.0 N´m (80 kgf´cm, 71 in.´lbf)
HINT:
Remove the anti±theft bolt cover, then remove the lower hood
lock bolt. You may have to remove the front bumper to access
this bolt.
(b) Adjust the lock by loosening the bolts.

BO0L2±01
H01975
Door Lock
Cylinder
Outside Handle Front Door Belt Moulding
Door Glass
Door FrameFront Door Upper Moulding
Outside
Rear View
Mirror
Door Glass
Run
5.5 (55, 49 in.´lbf)
5.5 (55, 49 in.´lbf)
5.0 (50, 43 in.´lbf)

Door Lock
23 (230, 17)
Window Regulator
8.0 (80, 69 in.´lbf)
Door Hinge
X6
7.5 (75, 66 in.´lbf)
Regulator
Motor
X3
31 (310, 22)
26 (260, 19)
8.0 (80, 71 in.´lbf)
30 (300, 22)
31 (310, 22)
Door
Check
Door Hinge
26 (260, 19)
Speaker
Power Window Switch Rear Lower
FrameFront Lower
FrameFront Window Upper
Garnish
Inside Handle Bezel
3.5 (35, 31 in.´lbf)
Driver's Side:
Regulator
Motor
Ptdt
N´m (kgf´cm, ft´lbf) : Specified torqueInside Handle
Door Trim

Precoated part Door Lock StrikerService Hole Cover
± BODYFRONT DOOR
BO±11
2359 Author: Date:
FRONT DOOR
COMPONENTS
