11-118
PGM-FI System
DTC Troubleshooting (cont’d)
No. 1 Cylinder Misfire Detected
No. 2 Cylinder Misfire Detected
No. 3 Cylinder Misfire Detected
No. 4 Cylinder Misfire Detected
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine, and let it idle without load (A/T in P or N, M/T in neutral).
4. Monitor the OBD STATUS for DTC P0301, P0302, P0303, or P0304 in the DTCs MENU with the HDS.
Go to step 9.
If the screen indicates PASSED, go to step 5. If
the screen indicates EXECUTING, keep idling until
a result comes on. If the screen indicates OUT OF
CONDITION, wait for several minutes, and recheck.
5. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE in the DATA LIST
for 10 minutes with the HDS.
Go to step 9.
Go to step 6.
6. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters:
ENGINE S PEED
VSS
REL TP SENSOR
CLV (calculated load value)
APP SENSOR 7. Monitor the OBD STATUS for DTC P0301, P0302,
P0303, or P0304 in the DTCs MENU with the HDS.
Go to step 9.
If the screen indicates PASSED, go to step 8. If
the screen indicates EXECUTING, keep driving until
a result comes on. If he screen indicates OUT OF
CONDITION, go to step 6 and recheck.
8. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE in the DATA LIST
for 10 minutes with the HDS.
Go to step 9.
Intermittent failure, the system is OK at this
time. Check for the fuel and ignition system circuit
connectors for poor connections or loose
terminals.
9. Turn the ignition switch to LOCK (0).
10. Remove the engine cover; K20Z2 engine (see step 1 on page 9-3), K20Z3 engine (see step 1 on page 9-7).
11. Start the engine, and listen for a clicking sound at the injector of the problem cylinder.
Go to step 12.
Go to step 42.
Does t he scr een i nd i cat e F AILE D?
Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3M I SF I RE , and / or CY L4 M I SF I RE show mi sf i r ecounts? Does t he scr een i nd i cat e F AILE D?
Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3M I SF I RE , and / or CY L4 M I SF I RE show mi sf i r ecounts?
Does t he i nj ect or cl i ck ?
