PGM-FI System
DLC Circuit Troubleshooting (cont’d)
DATA LINK CONNECTOR (DLC)
K-LINE (LT BLU)
JUMPER WIRE
DATA LINK CONNECTOR (DLC)B(WHT)
23. Connect DLC terminal No. 7 to body ground with ajumper wire.
24. Check for continuity between body ground and these connector terminals:
SRS unit A (28P) No. 24 (LT BLU)
ABS modulator-control unit
25P (with ABS) No. 10
(LT BLU)
VSA modulator-control unit
37P (with VSA system) No. 26
(LTBLU)
EPS control unit D (28P) No. 17 (LT BLU)
Immobilizer-keyless control
unit 7P No. 5 (LT BLU)
TPMS control unit 20P No. 7 (LT BLU)
Audio unit 17P No. 6 (LT BLU)
Under-dash fuse/relay box Q
(16P) No. 8 (LT BLU)
Replace the part which cannot communicate
with the HDS.
Repair open in the wire between the DLC (K-
line) and the appropriate connector. 25. Do the gauge self-diagnostic function (see page
22-241).
26. Check for B-CAN system DTCs without the HDS (see page 22-74).
Go to step 39.
Go to step 27.
27. Turn the ignition switch to LOCK (0).
28. Disconnect the HDS from the DLC.
29. Measure the voltage between DLC terminal No. 16 and body ground.
Go to step 30.
Repair open in the wire between DLC terminal
No.16andtheNo.23BACKUP(10A)fuseinthe
under-hood fuse/relay box.
Terminal side of female terminals
Terminal side of female terminals
Is t her e cont i nui t y bet w een t he bod y gr ound andeach of t he t er mi nal s i n t he char t ? I s DT C B1168, B1169, and / or B117 8 i nd i cat ed ?
Is there battery voltage?
