A/T Gear Position Indicator Panel Light Harness/Park Pin Switch
Replacement
A
B B
C
D
E F
G
A
NOTE: The A/T gear position indicator light and the park
pin switch are not available separately. Replace the A/T
gear position indicator light and the park pin switch as a
set. 1. Remove the shift lever assembly (see page 14-254).
2. Loosen the A/T gear position indicator panel (see page 14-256).
3. Remove the park pin switch (A) while pressing the park pin switch lock (B). 4. Remove the A/T gear position indicator panel light
bulb (A) and the socket (B) from the indicator panel
(C), and remove the light bulb from the socket.
5. Remove the harness clamp (D), and remove the park pin switch/A/T gear position indicator panel
light connector (E) from the shift l ever assembly/
bracket base (F).
6. Install a new park pin switch (G) on the shift lever.
7. Install the A/T gear position indicator panel light bulb in a new socket, and install it in the indicator
panel.
8. Clamp the harnesses together with the harness clamp, then install the harness clamp on the shift
lever bracket base.
9. Route the harnesses along the harness guides, and install a new connector in the bracket base.
10. Install the A/T gear position indicator panel (see page 14-256).
11. Install the shift lever assembly (see page 14-255).
12. Install the center console (see page 20-92).
08/08/21 14:49:58 61SNR030_140_0271
ProCarManuals.com
DYNOMITE -2009-
Page 1186 of 2893

Î
(#'
)
14-269
A/T Gear Position Indicator Panel Light Harness/Park Pin Switch
Replacement
A
B B
C
D
E F
G
A
NOTE: The A/T gear position indicator light and the park
pin switch are not available separately. Replace the A/T
gear position indicator light and the park pin switch as a
set. 1. Remove the shift lever assembly (see page 14-254).
2. Loosen the A/T gear position indicator panel (see page 14-256).
3. Remove the park pin switch (A) while pressing the park pin switch lock (B). 4. Remove the A/T gear position indicator panel light
bulb (A) and the socket (B) from the indicator panel
(C), and remove the light bulb from the socket.
5. Remove the harness clamp (D), and remove the park pin switch/A/T gear position indicator panel
light connector (E) from the shift l ever assembly/
bracket base (F).
6. Install a new park pin switch (G) on the shift lever.
7. Install the A/T gear position indicator panel light bulb in a new socket, and install it in the indicator
panel.
8. Clamp the harnesses together with the harness clamp, then install the harness clamp on the shift
lever bracket base.
9. Route the harnesses along the harness guides, and install a new connector in the bracket base.
10. Install the A/T gear position indicator panel (see page 14-256).
11. Install the shift lever assembly (see page 14-255).
12. Install the center console (see page 20-92).
08/08/21 14:49:58 61SNR030_140_0271
ProCarManuals.com
DYNOMITE -2009-
Page 1187 of 2893

´´
´ ´
´
Î
(#'
)
´
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
14-270A/T Gear Position Indicator
Paddle Shifter + (Upshift Switch) Circuit Troubleshooting
CABLE REEL SUBHARNESS 20P CONNECTOR
GND (LT GRN)
SUPP (GRN/ORN) PADDLE SHIFTER
(UPSHIFT SWITCH) CONNECTOR
GND (BLK)
CABLE REEL 20P CONNECTOR
SRS components are located in this area. Review the
SRS component locations (see page 24-11) and the
precautions and procedures (see page 24-13) before
doing repair or service.
1. Remove the steering wheel (see page 17-6).
2. Check for continuity between cable reel subharness 20P connector terminals No. 7 and No. 16 when
pressing the paddle shifter (upshift switch) and
when the switch is released.
Go to step 5.
Go to step 3.
3. Disconnect the paddle shifter (upshift switch) connector. 4. Check for continuity between the paddle shifter
(upshift switch) connector terminals when pressing
the switch and when the switch is released.
Replace the steering switch harness
(see page 17-7).
Replace the paddle shifter (upshift switch)
(see page 14-276).
5. Remove the cable reel (see page 24-200).
6. Check for continuity between cable reel 20P connector terminal No. 6 and body ground.
Go to step 7.
Repair open in the wire between cable reel
20P connector terminal No. 6 and body ground
(G504), or repair poor body ground (G504).
Wire side of female terminals Terminal side of male terminals
Wire side of female terminals
Is t her e cont i nui t y w hen pr essi ng t he pad d l eshi f t er ( upshi f t sw i t ch) and no cont i nui t y w henthe switch released? Is there continuity when pressing the switch and
no continuity when the switch released?
Is there continuity?
08/08/21 14:49:59 61SNR030_140_0272
ProCarManuals.com
DYNOMITE -2009-
Page 1188 of 2893
´
µ
µµ µ
YES
NO YES
NO
14-271
SUPP (BLU)
CABLE REEL 20P CONNECTOR
SUPP (BLU)
CABLE REEL 20P CONNECTOR
GND (BLK)
7. Check for continuity between cable reel 20Pconnector terminal No. 16 and body ground.
Repair short to body ground in the wire
between cable reel 20P connector terminal No. 16
and PCM connector terminal B16.
Go to step 8. 8. Turn the ignition switch to ON (II), and shift to S.
9. Measure the voltage between cable reel 20P
connector terminals No. 6 and No. 16.
Replace the cable reel (see page 24-200).
Go to step 10.
(cont’d)
Wire side of female terminals Wire side of female terminals
Is there continuity?Is t her e about bat t er y v ol t age i n neut r al posi t i onand no v ol t age w hen pr essi ng t he pad d l e shi f t er(upshift switch)?
08/08/21 14:49:59 61SNR030_140_0273
ProCarManuals.com
DYNOMITE -2009-
Page 1189 of 2893

ÎÎ
µ
µ
YES
NO
14-272 A/T Gear Position Indicator
Paddle Shifter + (Upshift Switch) Circuit Troubleshooting (cont’d)
CABLE REEL 20P CONNECTOR
SUPP (BLU)
JUMPER WIRE PCM CONNECTOR B (44P)
SUPP (BLU/YEL)
10. Turn the ignition switch to LOCK (0).
11. Jump the SCS line with the HDS.
12. Disconnect PCM connector B (44P).
13. Connect cable reel 20P connector terminal No. 16 and body ground with a jumper wire. 14. Check for continuity between PCM connector
terminal B16 and body ground.
Check for poor connections or loose
terminals between cable reel 20P connector
terminal No. 16 and PCM connector terminal B16. If
the connection is OK, update the PCM if it does not
have the latest software (see page 11-227), or
substitute a known-good PCM (see page 11-7), then
recheck. If the symptom goes away with a known-
good PCM, replace the original PCM (see page
11-228).
Repair open in the wire between PCM
connector terminal B16 and the cable reel 20P
connector.
Wire side of female terminals Terminal side of female terminals
Is there continuity?
08/08/21 14:50:00 61SNR030_140_0274
ProCarManuals.com
DYNOMITE -2009-
Page 1190 of 2893

µµ
µ µ
µ
Î
(#'
)
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
14-273
Paddle Shifter - (Downshift Switch) Circuit Troubleshooting
GND (LT GRN)
SDNP (BLK/WHT)
CABLE REEL SUBHARNESS 20P CONNECTOR
PADDLE SHIFTER
(DOWNSHIFT SWITCH) CONNECTOR
GND (BLK)
CABLE REEL 20P CONNECTOR
SRS components are located in this area. Review the
SRS component locations (see page 24-11) and the
precautions and procedures (see page 24-13) before
doing repair or service.
1. Remove the steering wheel (see page 17-6).
2. Check for continuity between cable reel subharness 20P connector terminals No. 7 and No. 17 when
pressing the paddle shifter (downshift switch)
and when the switch is released.
Go to step 5.
Go to step 3.
3. Disconnect the paddle shifter (downshift switch) connector. 4. Check for continuity between the paddle shifter
(downshift switch) connector terminals when
pressing the switch and when the switch is
released.
Replace the steering switch harness
(see page 17-7).
Replace the paddle shifter (downshift
switch) (see page 14-277).
5. Remove the cable reel (see page 24-200).
6. Check for continuity between cable reel 20P connector terminal No. 6 and body ground.
Go to step 7.
Repair open in the wire between cable reel
20P connector terminal No. 6 and body ground
(G504), or repair poor body ground (G504).
(cont’d)
Wire side of female terminals Terminal side of male terminals
Wire side of female terminals
Is t her e cont i nui t y w hen pr essi ng t he pad d l e shi f t er ( d ow nshi f t sw i t ch) and no cont i nui t yw hen t he sw i t ch r el eased ? Is there continuity when pressing the switch and
no continuity when the switch released?
Is there continuity?
08/08/21 14:50:00 61SNR030_140_0275
ProCarManuals.com
DYNOMITE -2009-
Page 1191 of 2893
µ
µ
µ µ
µ
YES
NO
YES
NO
14-274A/T Gear Position Indicator
Paddle Shifter - (Downshift Switch) Circuit Troubleshooting (cont’d)
SDNP (GRN)
CABLE REEL 20P CONNECTOR
SDNP (GRN)
CABLE REEL 20P CONNECTOR
GND (BLK)
7. Check for continuity between cable reel 20Pconnector terminal No. 17 and body ground.
Repair short to body ground in the wire
between cable reel 20P connector terminal No. 17
and PCM connector terminal D15.
Go to step 8.
8. Turn the ignition switch to ON (II), and shift to S. 9. Measure the voltage between cable reel 20P
connector terminals No. 6 and No. 17.
Replace the cable reel (see page 24-200).
Go to step 10.
Wire side of female terminals Wire side of female terminals
I s t her e cont i nui t y ?I s t her e about 5 V i n neut r al posi t i on and no
v ol t age w hen pr essi ng t he pad d l e shi f t er( d ow nshi f t sw i t ch)?
08/08/21 14:50:01 61SNR030_140_0276
ProCarManuals.com
DYNOMITE -2009-
Page 1192 of 2893

ÎÎ
µ
µ
YES
NO
14-275
CABLE REEL 20P CONNECTOR
SDNP (GRN)
JUMPER WIRE PCM CONNECTOR B (44P)
SDNP (BRN)
10. Turn the ignition switch to LOCK (0).
11. Jump the SCS line with the HDS.
12. Disconnect PCM connector B (44P).
13. Connect cable reel 20P connector terminal No. 17and body ground with a jumper wire. 14. Check for continuity between PCM connector
terminal B40 and body ground.
Check for poor connections or loose
terminals between cable reel 20P connector
terminal No. 17 and PCM connector terminal B40. If
the connection is OK, update the PCM if it does not
have the latest software (see page 11-227), or
subsitute a known-good PCM (see page 11-7), then
recheck. If the symptom goes away with a known-
good PCM, replace the original PCM (see page
11-228).
Repair open in the wire between PCM
connector terminal B40 and the cable reel 20P
connector.
Wire side of female terminals Terminal side of female terminals
Is there continuity?
08/08/21 14:50:01 61SNR030_140_0277
ProCarManuals.com
