Page 2449 of 2893

ACURA CSX 2006 Service Repair Manual Î
Contents Audio output
Left front CH Right front CH Right rear CH Left rear CH Subwoofer CH
USB Adapter
GA-Net Bus Configuration
23-165
Navigation unit
or audio unit
Accessory
(CD changer etc.)

Page 2450 of 2893

ACURA CSX 2006 Service Repair Manual ÎWith navigation
23-166Audio System
System Description (cont’d)
Reverse signal
GPS antenna
AM/FM antenna Speakers
Navigation unit
Navi DVD
Navigation/Audio Display Screen
CLOCK
(Set by GPS)Col

Page 2451 of 2893

ACURA CSX 2006 Service Repair Manual µ
Audio Glossary
Item Definition
23-167
NOTE: All items may not apply to this vehicle. See the owner’s manual for more information.
Active noise cancellation The active noise cancellation system c

µ
Audio Glossary
Item Definition
23-167
NOTE: All items may not apply to this vehicle. See the owner’s manual for more information.
Active noise cancellation The active noise cancellation system cancels some of the vehicle noise. This occurs in the 1,500 2,400 rpm range. Microphones detect the low frequency
sound, and the system outputs a canceling sound from the audio speaker.
AM (Amplitude Modulation)
Amplifier A device that increases the level of a signal by increasing the current or voltage.
Antenna A device used to send or receive electromagnetic waves thr ough the air.
ATA (PC Card) A type of card that has been tested for use in playing WMA, and MP3 music files in the PC Card slot. Sizes of up to 1 GB have been tested.
Audio remote switch The switches on the steering wheel that control the audio system.
Auxiliary jack Allows the customer to use a portable audio device to i nput audio recordings.
Balance A control that changes the relative volume of the left and right channels.
Band A range of frequencies between two definite limits. Bands are assigned by the Federal Communications Commission for specific uses.
Bass An adjustment for the low frequency sounds of around 160 Hz and below.
Byte A unit of storage for computer files and memory. A CD holds approximately 700 million bytes.
Cassette Audio or video magnetic tape container having two reels. Customers can insert it for play back
Compactflash Astandardforsmall-size(3x4cm),memorycardsusedinmobilecomputers, PDAs, digital cameras. Compact flash memory cards are available in size of
32 MB up to 4 GB or more and can be played in the audio PC slot. Sizes above
1 GB have not been tested.
CD (Compact Disc) A 4.5-inch plastic disc containing digital audio recording that is played optically on a laser equipped player. Never use discs with a paper label. In a hot vehicle,
labels can curl up and jam the unit.
CD (audio disc) changer CD player that can store and play more than one CD. Two types are available. Some units accept CDs fed into the changer one at a time, and others accept a
magazine (with CDs stacked in a container).
CD player A com ponent designed to play compact disc recordings using a laser optical
pickup. The signal from a CD player usually requires amplification.
Decibels (db)
Distortion Inexact repr oduction of an audio signal caused by playing music at levels the
audio system cannot handle.
Dolby (noise reduction) A processing system developed by Dolby Laboratories that reduces the background noise on recording media. The result is a cleaner playback from the
audio system.
DUET A serial data communication line used for sub display.
DVD (Digital Versatile Disc) A 4.5-inch CD-like format used for storing movies with digital audio and video features. The DVD-A format is a DVD format designed for DVD audio systems.
Some vehicles can play DVD and DVD-A formats.
Equalizer A device that changes the relative volume of individual frequency bands to suit personal tastes of the listener.
Fader The control that adjusts the relative volume levels of front and rear speakers in a four-speaker system.
Format To prepare a PC Card to receive files this function is done on a PC. Always choose either FAT or FAT32, as the NTFS format is not accepted by the system.
Pick the default sectors for the format method selected.
FM (Frequency Modulation) The form of modulation used for radio and television sound transmission in most of the world. Less prone to interference than AM. The FM broadcast band
in North America covers roughly 87.7 to 107.9 MHz.
(cont’d)
The type of transmission used in the standard radio broadcast band from 530 to 1710 kHz.
A method of measuring sound or radio signal strength received by the audio unit antenna.
08/08/21 14:08:46 61SNR030_230_0170
ProCarManuals.com
DYNOMITE -2009-

Page 2452 of 2893

ACURA CSX 2006 Service Repair Manual Audio GlossaryItem Definition
23-168Audio System
System Description (cont’d)
GA-Net
The GA-Net allows the audio unit to communicate with all the audio and
navigation components in a vehicle. If ther

Audio GlossaryItem Definition
23-168Audio System
System Description (cont’d)
GA-Net
The GA-Net allows the audio unit to communicate with all the audio and
navigation components in a vehicle. If there is an open in the GA-Net, or
components, components or the entire audio and navigation system may
appear inoperative.
GB (Gigabyte) A unit of memory or disk storage equal to billion bytes (1000 million bytes).
HDD Abbreviation for hard disc drive. They are sensitive to heat and it is not
recommended that they be used in the PC card slot for playing audio files.
Hertz (Hz) The unit of frequency equal to one cycle per second (cps). One kilohertz (kHz)
equals 1,000 cps; one megahertz (MHz) equals 1 million cps.
Integrated amplifier A component that combines a pre amp and a power amp into a single unit. A
receiver combines an integrated amp and a tuner into a single unit.
Jewel case The hard plastic case that contains a compact disc or DVD. Always use a jewel
case to prevent scratches on the underside of a CD or DVD.
LCD (Liquid Crystal Display) A type of digital display that changes reflectance or transmittance when an electrical field is applied to it.
Memory Circuitry or devices that hold information in electrical or magnetic form, such
as the AM/FM radio presets.
MB (Megabyte) One million bytes. Written as 1 MB. Megabytes are used as a measure of digital
storage space. For example, a CD can hold 650 MB.
Mic An abbreviation for microphone. For vehicles with navigation, the microphone
accepts navigation voice commands to control audio and navigation functions.
MP3 music files MP3 is an audio coding format. MP3 is a popular audio compression format on
the Internet and computers. CDs and PC Cards with these files can be played on
some vehicle’s audio system.
Mute When the navigation gives guidance, the front speakers are muted (no music).
When you use the voice control system, all of the speakers are muted.
Noise Unwanted random sounds like buzzing, hiss, pops, static, whine, etc.
PC card The slot used for playing MP3 and WMA music files. The PC Card is usually a
combination of a small flash card in a PCMCIA adaptor that slides into the slot.
The ATA, SD, and compact flash types of cards have been tested up to 1 GB.
PCMCIA A computer standard for the slot that the PC card slides into. Another term for
the PC card slot.
Processor The part of an audio device that performs tasks/calculations. In the audio unit
the processor handles muting to allow the navi to speak voice commands, and
the decoding/playback of the sound files etc.
Radio A head unit that combines a tuner, a preamplifier, and often a power-amplifier.
Route guidance (RG) Spoken voice used for turn-by-turn navigation from the audio speakers.
SCF (Cold Start Fix) screens These screens are displayed if the system requires a GPS initialization. The vehicle should be moved outside into an open area away from buildings/power
lines.
Stereo A recording of at least two channels where you can hear sound or music from
the left or right side.
SD (Secure Digital) card This compact type of memory card allows for fast data transfer and has built-in security functions. SD cards have a small write-protection switch on the side.
Shield A metallic foil or braided wire layer surr ounding conductors which are
designed to prevent electrostatic or electromagnetic interference (noise) from
external sources such as buzzing, or popping sounds heard on the speakers.
Speaker (Loudspeaker) A device that converts electrical energy into acoustical energy (sound).
Speed-sensitive volume
compensation (SVC) The SVC increases the audio volume to compensate for increased interior noise
when the vehicle drivers at freeway speeds.
Subwoofer A loudspeaker made to reproduce the lowest audio frequencies, about 25 Hz to
125 Hz.
08/08/21 14:08:47 61SNR030_230_0171
ProCarManuals.com
DYNOMITE -2009-

Page 2453 of 2893

ACURA CSX 2006 Service Repair Manual Audio GlossaryItem Definition
23-169
Track A sound recording on a CD, tape, or PC Card.
Treble An adjustment to control the volume of the high frequency sounds.
Tuner A component (or part of a compone

Page 2454 of 2893

ACURA CSX 2006 Service Repair Manual Î
Audio Unit Connector for Inputs and Outputs
With navigation (Navigation unit)
23-170Audio System
System Description (cont’d)
NAVIGATION UNIT
CONNECTOR G (3P)
NAVIGATION UNIT
CONNECTOR B (24P

Page 2455 of 2893

ACURA CSX 2006 Service Repair Manual µµ
´
µ
´
´
´ µ
´
µ
´
´ µ
µ
´
µ
´
´
µ
´
µ
´
´
Î
NAVIGATION UNIT CONNECTOR A (24P)
Type S model
Cavity Wire Color Connect to Except Type S model
Cavit

µµ
´
µ
´
´
´ µ
´
µ
´
´ µ
µ
´
µ
´
´
µ
´
µ
´
´
Î
NAVIGATION UNIT CONNECTOR A (24P)
Type S model
Cavity Wire Color Connect to Except Type S model
Cavity Wire Color Connect to
23-171
A1 RED Dash lights brightness
controller (ILL )
A3 LT BLU Data link connector (DLC) (K-LINE)
A4 GRN Multiplex integrated control unit (MICU) (SCTY RADIO)
A5 BRN Audio remote switch (AUDIO REMOTE GND)
A6 PUR Stereo amplifier (RR SIG )
A7 LT GRN Stereo amplifier (RR SIG )
A10 WHT Stereo amplifier (RL SIG )
A11 BLK Stereo amplifier (RL SIG )
A12 BLK Body ground to G505 (GND)
A13 GRY No. 14 (7.5 A) fuse in the under- dash fuse/relay box (ILL )
A14 PUR No. 35 (7.5 A) fuse in the under- dash fuse/relay box
(ACC RADIO)
A15 BLU ECM/PCM (VSP)
A16 PNK Audio remote switch (AUDIO REMOTE SW)
A17 LT BLU Stereo amplifier (SWD B)
A18 PNK Stereo amplifier (FR SIG )
A19 BLU Stereo amplifier (FR SIG )
A22 RED Stereo amplifier (FL SIG )
A23 BLU Stereo amplifier (FL SIG )
A24 WHT No. 23 (10 A) fuse in the under- hood fuse/relay box
( B BACK UP) A1 RED Dash lights brightness
controller (ILL )
A3 LT BLU Data link connector (DLC) (K-LINE)
A4 GRN Multiplex integrated control unit (MICU) (SCTY RADIO)
A5 BRN Audio remote switch (AUDIO REMOTE GND)
A6 ORN Right rear speaker (RR R )
A7 BLU Right rear speaker (RR R )
A10 BRN Left rear speaker (RR L )
A11 YEL Left rear speaker (RR L )
A12 BLK Body ground to G505 (GND)
A13 GRY No. 14 (7.5 A) fuse in the under- dash fuse/relay box (ILL )
A14 PUR No. 35 (10 A) fuse in the under- dash fuse/relay box
(ACC RADIO)
A15 BLU ECM/PCM (VSP)
A16 PNK Audio remote switch (AUDIO REMOTE SW)
A18 BRN Front passenger’s door speaker, right tweeter (FR R )
A19 GRY Front passenger’s door speaker, right tweeter (FR R )
A22 PNK Driver’s door speaker, left tweeter (FR L )
A23 LT GRN Driver’s door speaker, left tweeter (FR L )
A24 WHT No. 23 (10 A) fuse in the under- hood fuse/relay box
( B BACK UP)
(cont’d)
Wire side of female terminals
08/08/21 14:08:47 61SNR030_230_0174
ProCarManuals.com
DYNOMITE -2009-

Page 2456 of 2893

ACURA CSX 2006 Service Repair Manual µ
´
ÎNAVIGATION UNIT CONNECTOR B (24P)
Cavity Wire Color Connect to
23-172Audio System
System Description (cont’d)
B1 BRN Auxiliary jack assembly
(AUX S GND)
B2 GRY Shield for terminals No
