Under-dash Fuse/Relay Box
Fuse
Number Amps
Component(s) or Circuit(s) Protected
22-62Power Distribution
Fuse to Components Index (cont’d)
1 7.5 A Power mirror switch light
2 15 A ECM/PCM, Fuel pump (via PGM-FI main relay 2), Immobilizer-keyless control unit
3 10 A Alternator, CMP sensor A, ECM/PCM (via brake pedal position switch), ELD, EVAP canister purge valve, MAF
sensor/IAT sensor, Reverse lockout solenoid , Secondary HO2S (sensor 2)
4 7.5 A ABS modulator-control unit , EPS control unit, VSA modulator-control unit , Yaw rate-lateral acceleration sensor
5 15 A Seat heaters (via seat heater relays)
6 20 A Fog light relay, Fog lights (via fog light relay)
7 Not used
8 Not used
9 7.5 A ODS unit, Passenger’s airbag cutoff indicator, SRS unit
10 7.5 A Back-up light (M/T), Gauge control module (speedo), Gauge control module (tach), MICU, Shift lock solenoid (A/T), TPMS control unit
11 10 A SRS unit
12 10 A Right headlight (high beam)
13 10 A Left headlight (high beam)
14 7.5 A Audio unit light , Climate control unit light, Dash lights brightness controller and odometer select/reset switch light, Driver’s footwell light , Driver’s seat heater switch light, Glove box light, Hazard warning switch light,
Moonroof switch light, Navigation unit , Park pin switch light (A/T), Passenger’s airbag cutoff indicator light,
Passenger’s footwell light , Passenger’s seat heater switch light, Steering wheel switches light (via cable reel),
VSA OFF switch light
15 7.5 A Parking lights, Taillights, License plate lights, Side marker lights
16 10 A Right headlight (low beam) 15 A Right HID unit
17 10 A Left headlight (low beam) 15 A Left HID unit
18 20 A MICU ( B H/L HI)
19 15 A MICU ( B SMALL LT)
20 Not used
1: ’06-07 Touring and Premium models
2: ’07 TYPE S and ’08-09 models
3: ’08-09 models
4: TYPE S model
5: With HID
6: Without HID
7: TYPE S and ’08 Premium and ’09 models
8: Without navigation system
9: With navigation system
4
1 2
2
7
3
8 49
4
6
5
6
5
08/08/21 14:24:03 61SNR030_220_0064
ProCarManuals.com
DYNOMITE -2009-

µ
(#'
)
GroundComponent or Circuit Grounded
22-64Ground Distribution
Ground to Components Index
G1 Battery
G2 Engine
G3 Transmission housing
G101 A/T clutch pressure control solenoid valves A, B, C (A/T), CKP sensor, CMP sensor A, CMP sensor B, Data link connector (DLC), ECM/PCM (LG1), ECM/PCM (LG2), ECM/PCM (PG1), ECM/PCM (PG2), ECM/PCM (PGMETCS), EGR valve (K20Z2 engine), Ignition
coils, Immobilizer-keyless control unit, Rocker arm oil control solenoid, Rocker arm oil pressure switch, Transmission range
switch (A/T), VTC oil control solenoid valve
Shielding between the ECM/PCM and Knock sensor (KS) has wire.
Shielding between the ECM/PCM and Secondary HO2S (Sensor 2) has wire.
G201 Right fog light , Right front parking light, Right front side marker light, Right front turn signal light, Right headlight (high/low beams), Right HID unit , Windshield washer motor, Windshield wiper motor
G202 ABS modulator-control unit , VSA modulator-control unit
G301 A/C condenser fan motor, Blower motor relay, ELD, Left fog light , Left front parking light, Left front side marker light, Left front turn signal light, Left headlight (high/low beams), Left HID unit , Radiator fan motor (via fan control relay)
G401 Brake fluid level switch, Clutch interlock switch (M/T), Clutch pedal position switch (M/T), Hood switch, MICU (PG), Power transistor, Washer fluid level switch (G401 connects to G601 via under-dash fuse/relay box)
G402 EPS control unit
G403 Torque sensor
G501 Dash lights brightness controller and odometer select/reset switch, Driver’s door key cylinder switch, Driver’s door lock knob switch, HandsFreeLink control unit , MICU (SG), VSA OFF switch
G502 Data link connector (DLC), Front accessory power socket, Glove box light, Right power mirror defogger, Right side turn signal light
G503 Accessory power socket relays (front and console), Driver’s door lock switch, Gauge control module (tach), Left power mirror defogger, Left side turn signal light, Moonroof control unit/motor, Power mirror switch light, Power mirror switch, Power
window master switch (main switch), Power window master switch, Vanity mirror lights (driver’s and front passenger’s)
G504 Cable reel (steering wheel switches ground), Climate control unit, Front passenger’s door lock knob switch, Front passenger’s door lock switch, Gauge control module (speedo), Gauge control module (tach), Ignition key switch, Navigation unit , TPMS
control unit
G505 Audio unit , Navigation unit
G506 Memory erase signal (MES) connector, SRS unit (2 wires)
G601 A/T gear position console panel light/Park-pin switch (A/T), Console accessory power socket , Fuel pump, MICU (PG), Seat heater relays (driver’s and front passenger’s), Seat heater switches (driver’s and front passenger’s), Seat heaters (driver’s and
front passenger’s), Stereo amplifier (G601 connects to G401 via under-dash fuse/relay box)
Shielding between the left side impact sensor (FIRST) and rear safing sensor has wire.
Shielding between the SRS unit and left side impact sensor (FIRST) has wire.
G602 Driver’s seat belt buckle switch, Front passenger’s seat belt buckle switch, Left rear door lock knob switch, MICU (SG), MICU service check connector, ODS unit, Right rear door lock knob switch, Yaw rate-lateral acceleration sensor
Shielding between the right side impact sensor (FIRST) and right side impact sensor (SECOND) have wires.
Shielding between the SRS unit and right side impact sensor (FIRST) has wire.
G603 Noise condenser Shielding between the rear safing sensor and left side impact sensor (SECOND) has wire.
G701 High mount brake light, Left back-up light, Left inner taillight, Left rear side marker light, Left rear turn signal light, Left taillight/ brake light, License plate lights, Right back-up light, Right inner taillight, Right rear side marker light, Right rear turn signal light,
Right taillight/brake light, Trunk lid release actuator/Trunk lid latch switch
G801 Rear window defogger ( )
1: ’06-07 Touring and Premium models
2: ’07 TYPE S and ’08-09 models
3: ’08-09 models
4: TYPE S and ’08 premium and ’09 models
5: With HID
6: Without navigation system
7: With navigation system
8: ’09 model with navigation system
9: ’06-08 models, and ’09 model without navigation system
10: TYPE S model
4
512 4
5
82 3
7
3
67
9
10
2
08/08/21 14:24:03 61SNR030_220_0066
ProCarManuals.com
DYNOMITE -2009-

µ
µ
HDS Inputs and Commands
Input:System Menu Data List Data List Indication
22-88Multiplex Integrated Control System
System Description (cont’d)
Certain inputs happen so quickly that the HDS cannot update fast enough. Hold the switch that is being tested while monitoring the Data List.
This should give the HDS time to update the signal on the Data List.
Because the HDS software is updated to support the release for newer vehicles it is not uncommon to see system function tests that are not
supported.
Make sure that the most current software is loaded.
Gauges Cruise Control Main Switch OFF/ON Cruise Control Set Switch OFF/ON
Cruise Control Resume Switch OFF/ON
Washer Fluid Level Switch OFF/ON
VSA/TCS Off Switch OFF/ON
Gauge Select/Reset Switch OFF/ON
Parking Brake Switch OFF/ON
Brake Fluid Level Switch OFF/ON
Illumination Volume Plus Switch OFF/ON
Illumination Volume Minus Switch OFF/ON
Km/h mph Select Switch OFF/ON
Fuel Sending Unit Input 1 deg
Fuel Sending Unit Input 2 VOLTAGE
VSA/TCS Active Indicator OFF/ON
VSA/TCS Indicator (Warning) OFF/ON
ABS Indicator OFF/ON
Cruise Control Main Switch Indicator OFF/ON
MIL Indicator OFF/ON
Washer Fluid Level Indicator OFF/ON
DRL Indicator OFF/ON
Low Oil Pressure Indicator OFF/ON
Charging System Indicator OFF/ON
Cruise Main Switch ON Indicator OFF/ON
Maintenance Minder Indicator OFF/ON
High Beam Indicator OFF/ON
Parking Light ON Indicator OFF/ON
Low Fuel Warning Indicator OFF/ON
Security Indicator OFF/ON
Fog Light Indicator OFF/ON
Seat Belt Indicator OFF/ON
Speed Indicator (km/h) 0 249 km/h, over 250 km/h, Fail
Speed Indicator (mph) 0 154 mph, over 155 mph, Fail
Low Tire Pressure Indicator OFF/ON
TPMS Indicator OFF/ON
A/TGearPositionSwitch(R) OFF/ON
A/TGearPositionSwitch(P) OFF/ON
08/08/21 14:24:09 61SNR030_220_0090
ProCarManuals.com
DYNOMITE -2009-

´µ

The Indicator Drive Circuit Check
Switch Input Check
The Beeper Drive Circuit Check
The LCD Segment Check
The Gauge Drive Circuit Check
22-242Gauges
Self-diagnostic Function (cont’d)
OFF ON
OFF ON
OFF ON
OFF ON
Gauge needles
Beeper
5sec.
Self-diagnostic
mode
SEL/RESET
SWITCH
When entering the self-diagnostic mode, the following indicators blink:
A/T gear position indicator, ABS indicator, brake system indicator, charging system indicator, cruise control indicator,
cruise main indicator, door indicator, DRL indicator, EPS indicator, fog light indicator , high beam indicator,
immobilizer indicator, lights-on indicator, low fuel indicator, low oil pressure indicator, low tire pressure indicator ,
maintenance minder indicator, malfunction indicator lamp (MIL), REV limit indicator (TYPE S model), seat belt
reminder indicator, security indicator, side airbag cutoff indicator, SRS indicator, TPMS indicator , trunk indicator,
VSA activation indicator , VSA indicator , and washer fluid level indicator.
1: ’07 TYPE S and ’08-09 models
2: ’08-09 models
3: TYPE S and ’08 Premium and ’09 models
At the initial stage of the self-diagnostic function, the beep sounds intermittently, the beeper sounds continuously
when any of the following switch inputs are switched from OFF to ON:
Cruise control main, dash lights brightness controller volume ( ), ( ) button, mph km/h switch, parking brake switch,
SEL/RESET switch, SET, RESUME, CANCEL switches, and VSA OFF switch . : ’07 TYPE S and ’08-09 models
When entering the self-diagnostic mode, the beeper sounds five times.
When entering the self-diagnostic mode, all the segments blink five times.
When entering the self-diagnostic mode, the tachometer needle sweeps from the minimum position to maximum
position, then returns to the minimum position.
NOTE:
After the beeper stops sounding and the gauge needle returns to the minimum position, pushing the SEL/RESET
switch starts the Beeper Drive Circuit Check (one beep) and the Gauge Drive Circuit Check again.
The check cannot be started again until the gauge needle returns to the minimum position.
If the needle fails to sweep, or the beeper does not sound, replace the gauge control module (tach).
3 2
2
11
The needle sweeps from the
minimum position to the
maximum position, then return
to the minimum position.
08/08/21 14:35:12 61SNR030_220_0244
ProCarManuals.com
DYNOMITE -2009-

Î
µ´µ
22-254Gauges
Circuit Diagram - Gauge Control Module (Tach) (cont’d)
GAUGE CONTROL MODULE (TACH)
D
MAIN CIRCUIT
INDICATOR DRIVE CIRCUIT
DRL
INDICATOR
(LED)
DOOR
INDICATOR
(LED)TRUNK
INDICATOR
(LED)
MAINTENANCE
MINDER
INDICATOR
(LED) *
LOW TIRE
PRESSURE
INDICATOR
(LED) TPMS
INDICATOR
(LED)
G5014
3 6
7
1
2
5
BLK
PUR
7
BLU 6
