Page 329 of 2893

ACURA CSX 2006 Service Repair Manual ØÚÓ

Î
How to Troubleshoot Circuits at the ECM/
PCM Connectors
11-6 Fuel and Emissions Systems
General Troubleshooting Information (cont’d)
A
D E
B
A
C A
B D
C
A
NOTE: The

Page 330 of 2893

ACURA CSX 2006 Service Repair Manual ØÚÓ

Substituting the ECM/PCM
Special Tools Required
11-7
AA
D
9.8 N·m
(1.0 kgf·m,
7.2 lbf·ft)
A
B
C
E
Honda diagnostic system (HDS) tablet tester
Honda interface module (HI

Page 331 of 2893

ACURA CSX 2006 Service Repair Manual OBD Status
11-8Fuel and Emissions Systems
General Troubleshooting Information (cont’d)
13. Do the battery installation procedure (see page
22-69).
14. Turn the ignition switch to ON (II). NOTE: DTC

Page 332 of 2893

ACURA CSX 2006 Service Repair Manual •••Ó
Ó
•••
•••
•••
••• Ó
•••
••• Ó
•••
•••
•••
••• Ó
Ó
Ó
Ó
•••
•••

•••Ó
Ó
•••
•••
•••
••• Ó
•••
••• Ó
•••
•••
•••
••• Ó
Ó
Ó
Ó
•••
••• Ó
••• ÓÓ
••• Ó
Ó
•••
••• Ó
Ó
Ó
Ó
Ó
(#')
DTC
(MIL indication ) Two Drive Cycle
Detection Detection Item MIL Note
11-9
DTC Troubleshooting Index
P0010 (56)
Variable Valve Timing Control (VTC) Oil Control Solenoid Valve
Malfunction ON (see page 11-274)
P0011 (56) Variable Valve Timing Control (VTC) System Malfunction ON (see page 11-276)
P0101 (50) Mass Air Flow (MAF) Sensor Circuit Range/Performance Problem ON (see page 11-74)
P0102 (50) Mass Air Flow (MAF) Sensor Circuit Low Voltage ON (see page 11-75)
P0103 (50) Mass Air Flow (MAF) Sensor Circuit High Voltage ON (see page 11-78)
P0107 (3) Manifold Absolute Pressure (MAP) Sensor Circuit Low Voltage ON (see page 11-80)
P0108 (3) Manifold Absolute Pressure (MAP) Sensor Circuit High Voltage ON (see page 11-82)
P0111 (10) Intake Air Temperature (IAT) Sensor Circuit Range/Performance
Problem ON (see page 11-85)
P0112 (10) Intake Air Temperature (IAT) Sensor Circuit Low Voltage ON (see page 11-86)
P0113 (10) Intake Air Temperature (IAT) Sensor Circuit High Voltage ON (see page 11-87)
P0116 (86) Engine Coolant Temperature (ECT) Sensor 1 Circuit Range/
Performance Problem ON (see page 11-90)
P0117 (6) Engine Coolant Temperature (ECT) Sensor 1 Circuit Low Voltage ON (see page 11-91)
P0118 (6) Engine Coolant Temperature (ECT) Sensor 1 Circuit High Voltage ON (see page 11-92)
P0122 (7) Throttle Position (TP) Sensor A Circuit Low Voltage ON (see page 11-232)
P0123 (7) Throttle Position (TP) Sensor A Circuit High Voltage ON (see page 11-234)
P0125 (86) Engine Coolant Temperature (ECT) Sensor 1 Malfunction/Slow
Responce ON (see page 11-95)
P0128 (87) Cooling System Malfunction ON (see page 11-96)
P0133 (61) Air Fuel Ratio (A/F) Sensor (Sensor 1) Malfunction/Slow Response ON (see page 11-97)
P0134 (41) Air Fuel Ratio (A/F) Sensor (Sensor 1) Heater System Malfunction ON (see page 11-98)
P0135 (41) Air Fuel Ratio (A/F) Sensor (Sensor 1) Heater Circuit Malfunction ON (see page 11-99)
P0137 (63) Secondary Heated Oxygen Sensor (Secondary HO2S (Sensor 2))
Circuit Low Voltage ON (see page 11-104)
P0138 (63) Secondary Heated Oxygen Sensor (Secondary HO2S (Sensor 2))
Circuit High Voltage ON (see page 11-106)
P0139 (63) Secondary Heated Oxygen Sensor (Secondary HO2S (Sensor 2))
Slow Response ON (see page 11-109)
P0141 (65) Secondary Heated Oxygen Sensor (Secondary HO2S (Sensor 2))
Heater Circuit Malfunction ON (see page 11-110)
P0171 (45) Fuel System Too Lean ON (see page 11-113)
P0172 (45) Fuel System Too Rich ON (see page 11-113)
P0222 (7) Throttle Position (TP) Sensor B Circuit Low Voltage ON (see page 11-236)
P0223 (7) Throttle Position (TP) Sensor B Circuit High Voltage ON (see page 11-239)
P0300 (75)
and any
combination of
the following:
P0301 (71)
P0302 (72)
P0303 (73)
P0304 (74) Random Misfire Detected
ON (see page 11-115)
P0301 (71) No. 1 Cylinder Misfire Detected ON (see page 11-118)
P0302 (72) No. 2 Cylinder Misfire Detected ON (see page 11-118)
P0303 (73) No. 3 Cylinder Misfire Detected ON (see page 11-118)
P0304 (74) No. 4 Cylinder Misfire Detected ON (see page 11-118)
NOTE: The above DTCs are indicated when the PGM-FI system is selected with the HDS.
Some automatic transmission DTCs cause the MIL to come on. If the MIL is on and no DTCs are indicated in the PGM-FI system, select the A/T system, and check for automatic transmission DTCs.
: These DTCs are indicated by a blinking MIL when the SCS line is jumped with the HDS.
4: K20Z2 engine
5: K20Z3 engine
(cont’d)
4
5 4
5
08/08/21 14:12:35 61SNR030_110_0009
ProCarManuals.com
DYNOMITE -2009-

Page 333 of 2893

ACURA CSX 2006 Service Repair Manual •••
•••
•••
•••
•••
•••
•••
•••Ó
Ó
••• Ó
•••
Ó
••• Ó
••• ÓÓ
Ó
Ó
••�

•••
•••
•••
•••
•••
•••
•••
•••Ó
Ó
••• Ó
•••
Ó
••• Ó
••• ÓÓ
Ó
Ó
•••
•••
•••
••• Ó
Ó
Ó
•••
•••
Ó
Ó
Ó
Ó
•••
•••
•••
•••
•••
•••
DTC
(MIL indication ) Two Drive Cycle
Detection Detection Item MIL Note
11-10Fuel and Emissions Systems
DTC Troubleshooting Index (cont’d)
P0325 (23)
Knock Sensor Circuit Malfunction ON (see page 11-126)
P0335 (4) Crankshaft Position (CKP) Sensor No Signal ON (see page 11-128)
P0339 (4) Crankshaft Position (CKP) Sensor Circuit Intermittent Interruption ON (see page 11-131)
P0340 (57) Camshaft Position (CMP) Sensor A No Signal ON (see page 11-278)
P0341 (57) Camshaft Position (CMP) Sensor A and Crankshaft Position (CKP)
Sensor Incorrect Phase Detected ON (see page 11-281)
P0344 (57) Camshaft Position (CMP) Sensor A Circuit Intermittent Interruption ON (see page 11-282)
P0365 (8) Camshaft Position (CMP) Sensor B No Signal ON (see page 11-132)
P0369 (8) Camshaft Position (CMP) Sensor B Circuit Intermittent Interruption ON (see page 11-134)
P0401 (80) Exhaust Gas Recirculation (EGR) Insufficient Flow ON (see page 11-357)
P0404 (12) Exhaust Gas Recirculation (EGR) Valve Circuit Range/Performance
Problem ON (see page 11-358)
P0406 (12) Exhaust Gas Recirculation (EGR) Valve Position Sensor Circuit High
Voltage ON (see page 11-361)
P0420 (67) Catalyst System Efficiency Below Threshold ON (see page 11-353)
P0443 (92) Evaporative Emission (EVAP) Canister Purge Valve Circuit
Malfunction ON (see page 11-375)
P0451 (91) Fuel Tank Pressure (FTP) Sensor Circuit Range/Performance Problem ON (see page 11-379)
P0452 (91) Fuel Tank Pressure (FTP) Sensor Circuit Low Voltage ON (see page 11-380)
P0453 (91) Fuel Tank Pressure (FTP) Sensor Circuit High Voltage ON (see page 11-383)
P0455 (90) Evaporative Emission (EVAP) System Large Leak Detected ON (see page 11-386)
P0456 (90) Evaporative Emission (EVAP) System Very Small Leak Detected ON (see page 11-386)
P0457 (90) Evaporative Emission (EVAP) System Leak Detected/Fuel Fill Cap
Loose or Missing ON (see page 11-390)
P0457 (90) Evaporative Emission (EVAP) System Leak Detected/Fuel Fill Cap
Loose or Missing OFF (see page 11-390)
P0461 (121) Fuel Level Sensor (Fuel Gauge Sending Unit) Circuit Range/
Performance Problem OFF (see page 11-313)
P0462 (121) Fuel Level Sensor (Fuel Gauge Sending Unit) Circuit Low Voltage OFF (see page 11-313)
P0463 (121) Fuel Level Sensor (Fuel Gauge Sending Unit) Circuit High Voltage OFF (see page 11-315)
P0496 (92) Evaporative Emission (EVAP) System High Purge Flow Detected ON (see page 11-391)
P0497 (90) Evaporative Emission (EVAP) System Low Purge Flow Detected ON (see page 11-392)
P0497 (90) Evaporative Emission (EVAP) System Low Purge Flow Detected ON (see page 11-395)
P0498 (117) Evaporative Emission (EVAP) Canister Vent Shut Valve Circuit Low
Voltage ON (see page 11-398)
P0499 (117) Evaporative Emission (EVAP) Canister Vent Shut Valve Circuit High
Voltage ON (see page 11-401)
P0506 (14) Idle Control System RPM Lower Than Expected ON (see page 11-298)
P0507 (14) Idle Control System RPM Higher Than Expected ON (see page 11-300)
P050A (167) Cold Start Idle Air Control System Performance Problem ON (see page 11-135)
P050B (167) Cold Start Ignition Timing Control System Performance Problem ON (see page 11-137)
P0532 (191) A/C Pressure Sensor Circuit Low Voltage OFF (see page 11-301)
P0533 (191) A/C Pressure Sensor Circuit High Voltage OFF (see page 11-303)
P0562 (34) Charging System Low Voltage OFF (see page 11-140)
P0563 (34) Engine Control Module (ECM)/Powertrain Control Module (PCM)
Power Source Circuit Unexpected Voltage OFF (see page 11-141)
P0602 (196) Engine Control Module (ECM)/Powertrain Control Module (PCM)
Programming Error ON (see page 11-144)
P0603 (131) Engine Control Module (ECM)/Powertrain Control Module (PCM)
Internal Control Module Keep Alive Memory (KAM) Error ON (see page 11-144)
NOTE: The above DTCs are indicated when the PGM-FI system is selected with the HDS.
Some automatic transmission DTCs cause the MIL to come on. If the MIL is on and no DTCs are indicated in the PGM-FI system, select the A/T system, and check for automatic transmission DTCs.
: These DTCs are indicated by a blinking MIL when the SCS line is jumped with the HDS.
4: K20Z2 engine
5: K20Z3 engine
6: ’06 model
7: ’07-09 models
8: ’06-08 models
4
4
4
6
7 6
7
4
5
4
5
8
08/08/21 14:12:35 61SNR030_110_0010
ProCarManuals.com
DYNOMITE -2009-

Page 334 of 2893

ACURA CSX 2006 Service Repair Manual •••
•••
•••
•••Ó
•••
•••
•••
••• Ó
Ó
Ó
•••
••• Ó
•••
••• Ó
Ó
•••
•

•••
•••
•••
•••Ó
•••
•••
•••
••• Ó
Ó
Ó
•••
••• Ó
•••
••• Ó
Ó
•••
•••
•••
•••
•••
•••
•••
•••
•••
•••
•••
•••
•••
•••
•••
••• Ó
•••
•••
••• Ó
DTC
(MIL indication ) Two Drive Cycle
Detection Detection Item MIL Note
11-11
P0606 (0)
Engine Control Module (ECM)/Powertrain Control Module (PCM)
Processor Malfunction ON (see page 11-145)
P060A (131) Powertrain Control Module (PCM) (A/T System) Internal Control
Module Malfunction ON (see page 11-145)
P062F (131) Engine Control Module (ECM)/Powertrain Control Module (PCM)
Internal Control Module Keep Alive Memory (KAM) Error ON (see page 11-144)
P0630 (139) VIN Not Programmed or Mismatch ON (see page 11-146)
P0685 (135) Engine Control Module (ECM)/Powertrain Control Module (PCM)
Power Control Circuit/Internal Circuit Malfunction ON (see page 11-147)
P0720 (122) Output Shaft (Countershaft) Speed Sensor Circuit Malfunction ON (see page 11-148)
P0720 (122) Output Shaft (Countershaft) Speed Sensor Circuit Malfunction ON (see page 11-149)
P1009 (56) Variable Valve Timing Control (VTC) Advance Malfunction ON (see page 11-283)
P1109 (13) Barometric Pressure (BARO) Sensor Circuit Out of Range High ON (see page 11-152)
P1116 (86) Engine Coolant Temperature (ECT) Sensor 1 Circuit Range/
Performance Problem ON (see page 11-153)
P1128 (5) Manifold Absolute Pressure (MAP) Sensor Signal Lower Than
Expected ON (see page 11-155)
P1129 (5) Manifold Absolute Pressure (MAP) Sensor Signal Higher Than
Expected ON (see page 11-156)
P1157 (48) Air Fuel Ratio (A/F) Sensor (Sensor 1) AFS Circuit High Voltage ON (see page 11-157)
P1172 (61) Air Fuel Ratio (A/F) Sensor (Sensor 1) Circuit Out of Range High ON (see page 11-159)
P1297 (20) Electrical Load Detector (ELD) Circuit Low Voltage OFF (see page 11-160)
P1298 (20) Electrical Load Detector (ELD) Circuit High Voltage OFF (see page 11-162)
P1454 (91) Fuel Tank Pressure (FTP) Sensor Circuit Range/Performance Problem ON (see page 11-402)
P145C (90) Evaporative Emission (EVAP) System Purge Flow Malfunction ON (see page 11-404)
P1549 (34) Charging System High Voltage OFF (see page 11-164)
P1658 (40) Electronic Throttle Control System (ETCS) Control Relay ON
Malfunction ON (see page 11-241)
P1659 (40) Electronic Throttle Control System (ETCS) Control Relay OFF
Malfunction ON (see page 11-243)
P1683 (40) Throttle Valve Default Position Spring Performance Problem ON (see page 11-247)
P1684 (40) Throttle Valve Return Spring Performance Problem ON (see page 11-248)
P16BB (116) Alternator B Terminal Circuit Low Voltage OFF (see page 11-165)
P16BC (116) Alternator FR Terminal Circuit/IGP Circuit Low Voltage OFF (see page 11-166)
P2101 (40) Electronic Throttle Control System (ETCS) Malfunction ON (see page 11-249)
P2118 (40) Throttle Actuator Current Range/Performance Problem ON (see page 11-251)
P2122 (37) Accelerator Pedal Position (APP) Sensor A (Throttle Position (TP)
Sensor D) Circuit Low Voltage ON (see page 11-253)
P2123 (37) Accelerator Pedal Position (APP) Sensor A (Throttle Position (TP)
Sensor D) Circuit High Voltage ON (see page 11-256)
P2127 (37) Accelerator Pedal Position (APP) Sensor B (Throttle Position (TP)
Sensor E) Circuit Low Voltage ON (see page 11-257)
P2128 (37) Accelerator Pedal Position (APP) Sensor B (Throttle Position (TP)
Sensor E) Circuit High Voltage ON (see page 11-260)
P2135 (7) Throttle Position (TP) Sensor A/B Incorrect Voltage Correlation ON (see page 11-262)
P2138 (37) Accelerator Pedal Position (APP) Sensor A/B (Throttle Position (TP)
Sensor D/E) Incorrect Voltage Correlation ON (see page 11-264)
P2176 (40) Throttle Actuator Control System Idle Position Not Learned ON (see page 11-266)
P2183 (192) Engine Coolant Temperature (ECT) Sensor 2 Circuit Range/
Performance Problem ON (see page 11-168)
P2184 (192) Engine Coolant Temperature (ECT) Sensor 2 Circuit Low Voltage ON (see page 11-170)
P2185 (192) Engine Coolant Temperature (ECT) Sensor 2 Circuit High Voltage ON (see page 11-172)
P2195 (48) Air Fuel Ratio (A/F) Sensor (Sensor 1) Signal Stuck Lean ON (see page 11-174)
NOTE: The above DTCs are indicated when the PGM-FI system is selected with the HDS.
Some automatic transmission DTCs cause the MIL to come on. If the MIL is on and no DTCs are indicated in the PGM-FI system, select the A/T system, and check for automatic transmission DTCs.
: These DTCs are indicated by a blinking MIL when the SCS line is jumped with the HDS.
1: A/T
2: The D indicator and the MIL may come on at the same time (A/T).
3: M/T
4: K20Z2 engine
5: K20Z3 engine
9: ’09 model
(cont’d)
1
9
1, 2
3
4
5
5
3
1
08/08/21 14:12:36 61SNR030_110_0011
ProCarManuals.com
DYNOMITE -2009-

Page 335 of 2893

ACURA CSX 2006 Service Repair Manual Ó
•••
•••
••• ´
••• µ Ó
Ó
Ó
Ó
•••
•••
•••
•••
••• Ó
•••
•••
•••
•••

Ó
•••
•••
••• ´
••• µ Ó
Ó
Ó
Ó
•••
•••
•••
•••
••• Ó
•••
•••
•••
•••
•••
DTC
(MIL indication ) Two Drive Cycle
Detection Detection Item MIL Note
11-12Fuel and Emissions Systems
DTC Troubleshooting Index (cont’d)
P2227 (13)
Barometric Pressure (BARO) Sensor Circuit Range/Performance
Problem ON (see page 11-176)
P2228 (13) Barometric Pressure (BARO) Sensor Circuit Low Voltage ON (see page 11-177)
P2229 (13) Barometric Pressure (BARO) Sensor Circuit High Voltage ON (see page 11-177)
P2238 (48) Air Fuel Ratio (A/F) Sensor (Sensor 1) AFS Circuit Low Voltage ON (see page 11-178)
P2252 (48) Air Fuel Ratio (A/F) Sensor (Sensor 1) AFS Circuit Low Voltage ON (see page 11-179)
P2270 (63) Secondary Heated Oxygen Sensor (Secondary HO2S (Sensor 2))
Circuit Signal Stuck Lean ON (see page 11-181)
P2271 (63) Secondary Heated Oxygen Sensor (Secondary HO2S (Sensor 2))
Circuit Signal Stuck Rich ON (see page 11-181)
P2413 (12) Exhaust Gas Recirculation (EGR) System Malfunction ON (see page 11-363)
P2422 (117) Evaporative Emission (EVAP) Canister Vent Shut Valve Stuck Closed
Malfunction ON (see page 11-402)
P2610 (132) Engine Control Module (ECM)/Powertrain Control Module (PCM)
Ignition Off Internal Timer Malfunction ON (see page 11-182)
P2646 (22) Rocker Arm Oil Pressure Switch Circuit Low Voltage ON (see page 11-284)
P2647 (22) Rocker Arm Oil Pressure Switch Circuit High Voltage ON (see page 11-287)
P2648 (21) Rocker Arm Oil Control Solenoid Circuit Low Voltage ON (see page 11-289)
P2649 (21) Rocker Arm Oil Control Solenoid Circuit High Voltage ON (see page 11-291)
P2A00 (61) Air Fuel Ratio (A/F) Sensor (Sensor 1) Circuit Range/Performance
Problem ON (see page 11-182)
U0028 (126) F-CAN Malfunction (BUS-OFF (Engine Control Module (ECM)/
Powertrain Control Module (PCM))) ON (see page 11-183)
U0122 (126) F-CAN Malfunction (Engine Control Module (ECM)/Powertrain
Control Module (PCM)-Vehicle Stability Assist (VSA) Modulator-
Control Unit) OFF (see page 11-184)
U0131 (126) F-CAN Malfunction (Engine Control Module (ECM)/Powertrain
Control Module (PCM)-Electrical Power Steering (EPS) Control Unit) OFF (see page 11-186)
U0155 (126) F-CAN Malfunction (Engine Control Module (ECM)/Powertrain
Control Module (PCM)-Gauge Control Module) ON (see page 11-188)
U0300 (131) PGM-FI System and A/T System Program Version Mismatch ON (see page 11-190)
NOTE: The above DTCs are indicated when the PGM-FI system is selected with the HDS.
Some automatic transmission DTCs cause the MIL to come on. If the MIL is on and no DTCs are indicated in the PGM-FI system, select the A/T system, and check for automatic transmission DTCs.
: These DTCs are indicated by a blinking MIL when the SCS line is jumped with the HDS.
1: A/T
4: K20Z2 engine
6: with VSA
4
6
1
08/08/21 14:12:36 61SNR030_110_0012
ProCarManuals.com
DYNOMITE -2009-

Page 336 of 2893

ACURA CSX 2006 Service Repair Manual (#)
Symptom Diagnostic procedure Also check for
11-13
Symptom Troubleshooting Index
When the vehicle has one of these symptoms, check for a diagnostic tro

(#')
Symptom Diagnostic procedure Also check for
11-13
Symptom Troubleshooting Index
When the vehicle has one of these symptoms, check for a diagnostic trouble code (DTC) with the HDS. If there is no
DTC, do the diagnostic procedure for the symptom, in the sequence listed, until you find the cause.

Engine will not start
(MIL works OK, no DTCs set)
1.
2.
3.
4.Test the battery (see page 22-67).
Test the starter (see page 4-9).
Check the fuel pressure (see page 11-325).
Troubleshoot the fuel pump circuit (see page 11-
318).Low compression
No ignition spark
Intake air leaks
Locked up engine
Broken cam chain
Fuel contamination
Engine will not start
(MIL comes on and stays on,
no DTCs set) Troubleshoot the DLC circuit (see page 11-204).
MIL comes on and stays on,
or never comes on at all, no
DTCs set Troubleshoot the MIL circuit (see page 11-203).
Engine will not start
(MIL works OK, no DTCs set,
immobilizer indicator stays
on or flashes) Check the immobilizer system (see page 22-321).
Engine starts but stalls
immediately
(MIL works OK, no DTCs set,
immobilizer indicator stays
on or flashes) Check the immobilizer system (see page 22-323).
Engine is hard to start
(MIL works OK, no DTCs set) 1.
2.
3.Test the battery (see page 22-67).
Check the fuel pressure (see page 11-325).
Clean the throttle body (see page 11-
344).Low compression
Intake air leaks
Fuel contamination
Weak spark
Cold fast idle too low
(MIL works OK, no DTCs set) 1.
2.
3.DotheECM/PCMidlelearnprocedure(seepage
11-310).
Check the idle speed (see page 11-309).
Clean the throttle body (see page 11-
344).
Cold fast idle too high
(MIL works OK, no DTCs set) 1.
2.
3.DotheECM/PCMidlelearnprocedure(seepage
11-310).
Check the idle speed (see page 11-309).
Do the throttle position learning check (see page
11-343). Intake air leaks
Idle speed fluctuates
(MIL works OK, no DTCs set) 1.
2.
3.
4.DotheECM/PCMidlelearnprocedure(seepage
11-310).
Check the idle speed (see page 11-309).
Do the carbon accumulation check (see page 11-343).
Troubleshoot the A/C signal circuit (see page 11-306). Incorrect valve
timing or clearance
adjustment
Intake air leaks
After warming up, idle speed
is below specification without
load
(MIL works OK, no DTCs set) 1.
2.
Troubleshoot the alternator FR signal circuit
(see page 11-307).
Do the carbon accumulation check (see page 11-343). Incorrect valve
timing or clearance
adjustment
After warming up, idle speed
is above specification without
load
(MIL works OK, no DTCs set) 1.
2.
Troubleshoot the alternator FR signal circuit
(see page 11-307).
Inspect the APP sensor (see page 11-268). Intake air leaks
(cont’d)
08/08/21 14:12:36 61SNR030_110_0013
ProCarManuals.com
DYNOMITE -2009-

Load next 8 pages

Page: < prev 1-10 ... 297-304 305-312 313-320 321-328 329-336 337-344 345-352 353-360 361-368 ... 2896 next >

service indicator remote start length fuel cap TPMS battery replacement

Popular search:

air conditioning rear view mirror How to change the engine oil dimensions navigation update check oil dead battery
