DTCDetection Item ABS
Indicator Brake
System
Indicator VSA
Indicator VSA
Activation Indicator Note
19-101
25 Yaw Rate Sensor Internal Circuit Malfunction
(Initial) OFF OFF ON ON (see page 19-126)
-12 Yaw Rate Sensor Internal Circuit Malfunction (Open, Short) OFF OFF ON ON (see page 19-126)
-13 Yaw Rate Sensor Communication Error OFF OFF ON ON (see page 19-126) Yaw Rate/Lateral Acceleration Sensor Circuit High
Voltage OFF OFF ON ON (see page 19-127)
Yaw Rate/Lateral Acceleration Sensor Circuit Low
Voltage OFF OFF ON ON (see page 19-127)
Yaw Rate/Lateral Acceleration Sensor Internal
Circuit Malfunction (Keep Alive Memory (KAM)
Error) OFF OFF ON ON (see page 19-126)
Yaw Rate/Lateral Acceleration Sensor Power
Source Voltage Malfunction OFF OFF ON ON (see page 19-127)
Yaw Rate/Lateral Acceleration Sensor Internal
Circuit Malfunction OFF OFF ON ON (see page 19-126)
Yaw Rate/Lateral Acceleration Sensor Startup Time
Malfunction OFF OFF ON ON (see page 19-127)
-21 Yaw Rate Sensor Neutral Position Malfunction OFF OFF ON ON (see page 19-126)
-22 Yaw Rate Sensor Stuck OFF OFF ON ON (see page 19-128)
-23 Yaw Rate Sensor Circuit Intermittent Interruption OFF OFF ON ON (see page 19-127)
-24 Yaw Rate Sensor Gain Low OFF OFF ON ON (see page 19-128)
-25 Yaw Rate Sensor Gain High OFF OFF ON ON (see page 19-128)
26 Lateral Acceleration Sensor Internal Circuit Malfunction (Initial) OFF OFF ON ON (see page 19-126)
-12 Lateral Acceleration Sensor Internal Circuit Malfunction (Open, Short) OFF OFF ON ON (see page 19-126)
-13 Lateral Acceleration Sensor Communication Error OFF OFF ON ON (see page 19-126)
-21 Lateral Acceleration Sensor Neutral Position Malfunction OFF OFF ON ON (see page 19-129)
-22 Lateral Acceleration Sensor Stuck OFF OFF ON ON (see page 19-129)
-23 Lateral Acceleration Sensor Circuit Intermittent Interruption OFF OFF ON ON (see page 19-129)
-24 Lateral Acceleration Sensor Gain Low OFF OFF ON ON (see page 19-128)
-25 Lateral Acceleration Sensor Gain High OFF OFF ON ON (see page 19-128)
27 -11 Steering Angle Sensor DIAG Signal Error (Initial) OFF OFF ON ON (see page 19-130) -21 Steering Angle Sensor Stuck Neutral Position OFF OFF ON ON (see page 19-132)
-22 Steering Angle Sensor Stuck Offset Position OFF OFF ON ON (see page 19-132)
-23 Steering Angle Sensor Counter Malfunction OFF OFF ON ON (see page 19-135)
-24 Steering Angle Sensor Exchange Malfunction OFF OFF ON ON (see page 19-135)
-26 Steering Angle Sensor DIAG Signal Error (Main) OFF OFF ON ON (see page 19-130)
31 -01 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Initial Pulse) ON ON ON ON (see page 19-136)
-21 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Pulse) ON ON ON ON (see page 19-136)
-22 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Speculative) ON ON ON ON (see page 19-136)
-23 ABS Right-front Inlet Solenoid Valve Malfunction (Solenoid Stuck ON) ON ON ON ON (see page 19-136)
32 -01 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Initial Pulse) ON ON ON ON (see page 19-136)
-21 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Pulse) ON ON ON ON (see page 19-136)
-22 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Speculative) ON ON ON ON (see page 19-136)
-23 ABS Right-front Outlet Solenoid Valve Malfunction (Solenoid Stuck ON) ON ON ON ON (see page 19-136)
2: ’07-08 models
3: ’09 model
(cont’d)-11
-14
-15
-16
-17
-18
-19
-112
2
2
2
3
3
3
2
