Page 2137 of 2893
Î
ε
µ
µ
µ
YES
NO
YES
NO
22-187
UNDER-DASH FUSE/RELAY BOX CONNECTOR S (20P)
RIGHT
(BRN)LEFT
(LT GRN)
UNDER-DASH FUSE/RELAY BOX CONNECTOR S (20P) RIGHT
(BRN)LEFT
(LT GRN)
11. Check for continuity between body ground and
under-dash fuse/relay box connector S (20P)
terminals No. 18 and No. 19 individually.
Repair a short to ground in the wire.
Go to step 12.
12. Check for continuity between under-dash fuse/relay box connector S (20P) terminals No. 18 and No. 19.
Repair a short between the wires.
Replace the combination light switch.
Wire side of female terminals
Wire side of female terminals
Is there continuity?
Is there continuity?
08/08/21 14:27:43 61SNR030_220_0189
ProCarManuals.com
DYNOMITE -2009-
Page 2138 of 2893
(#'
)
22-188Turn Signal/Hazard Warning Lights
MICU Input Test
UNDER-DASH FUSE/RELAY BOX CONNECTOR E (42P)
BLK
BRN BLU UNDER-DASH FUSE/RELAY BOX CONNECTOR F (34P)
UNDER-DASH FUSE/RELAY BOX CONNECTOR G (21P)
YEL BLK
BLK BLU
GRN GRN
1. Before troubleshooting the turn signal/hazard warning lights system, troubleshoot the system using B-CAN
System Diagnosis Test Mode A (see page 22-93).
2. Check the No. 10 (7.5 A) fuse in the under-dash fuse/relay box. If the fuse is blown, replace it and go to step 3.
3. Disconnect under-dash fuse/relay box connectors E, F, G, M, P, Q, R, S, and T. NOTE: All connector views are shown from wire side of female terminals.
08/08/21 14:27:44 61SNR030_220_0190
ProCarManuals.com
DYNOMITE -2009-
Page 2139 of 2893
Î
22-189
UNDER-DASH FUSE/RELAY BOX
CONNECTOR M (10P)UNDER-DASH FUSE/RELAY BOX
CONNECTOR P (10P)
UNDER-DASH FUSE/RELAY BOX
CONNECTOR Q (16P) UNDER-DASH FUSE/RELAY BOX
CONNECTOR S (20P)
UNDER-DASH FUSE/RELAY BOX
CONNECTOR R (20P) UNDER-DASH FUSE/RELAY BOX
CONNECTOR T (34P)
BLU
GRN
BLKBRNLT GRN
WHT BLU
GRN
GRN BLK
4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary and recheck the system.
IftheterminalslookOK,gotostep5.
(cont’d)
08/08/21 14:27:44 61SNR030_220_0191
ProCarManuals.com
DYNOMITE -2009-
Page 2140 of 2893

Cavity Wire Test conditionTest: Desired result Possible cause if result desired is
not obtained
22-190Turn Signal/Hazard Warning Lights
MICU Input Test (cont’d)
5. With the connectors still disconnected, do these input tests at the following connectors.
If any test indicates a problem, find and correct the cause, then recheck the system.
If all the input tests prove OK, go to step 6.
E39 BRN Under all conditions Connect terminals G2 and E39
with a jumper wire:
The right rear turn signal light
should come on.Poor ground (G701)
Blown bulb
An open in the wire
E40 BLU Under all conditions Connect terminals G2 and E40 with a jumper wire:
The left rear turn signal light
should come on.Poor ground (G701)
Blown bulb
An open in the wire
F1 BRN Under all conditions Connect terminals G2 and F1 with a jumper wire:
The right front turn signal light
should come on.Poor ground (G201)
Blown bulb
An open in the wire
G1 BLU Under all conditions Connect terminals G2 and G1 with a jumper wire:
The left front turn signal light
should come on.Poor ground (G301)
Blown bulb
An open in the wire
M1 BLU Under all conditions Connect terminals G2 and M1 with a jumper wire:
The left side turn signal light
should come on.Poor ground (G503)
Blown LED
An open in the wire
M2 GRN Under all conditions Connect terminals G2 and M2 with a jumper wire:
The right side turn signal light
should come on.Poor ground (G502)
Blown LED
An open in the wire
P1 GRN Under all conditions Connect terminals G2 and P1 with a jumper wire:
The right turn signal indicator
should come on.Poor ground (G504)
Faulty gauge control module
(speedo)
An open in the wire
P6 BLU Under all conditions Connect terminals G2 and P6 with a jumper wire:
The left turn signal indicator
should come on.Poor ground (G504)
Faulty gauge control module
(speedo)
An open in the wire
08/08/21 14:27:44 61SNR030_220_0192
ProCarManuals.com
DYNOMITE -2009-
Page 2141 of 2893

Cavity Wire Test conditionTest: Desired result Possible cause if desired result is
not obtained
22-191
6. Reconnect connectors to the under-dash fuse/relay box, and do these input tests at the following connectors.
If any test indicates a problem, find and correct the cause, then recheck the system.
If all the input tests prove OK, the MICU must be faulty; replace the under-dash fuse/relay box.
G2 ORN Under all conditions Measure the voltage between
terminal G2 and body ground:
There should be battery voltage.Blown No. 23 (10 A) fuse in the
under-hood fuse/relay box
An open in the wire
G6 YEL Under all conditions Measure the voltage between terminal G6 and body ground:
There should be battery voltage.Blown No. 10 (10 A) fuse in the
under-hood fuse/relay box
An open in the wire
E6 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G602)
An open in the wire
E33 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G601)
An open in the wire
F20 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G401)
An open in the wire
T34 BLK Under all conditions Measure the voltage to ground: There should be less than 0.5 V.Poor ground (G501)
An open in the wire
R1 WHT Under all conditions Measure the voltage to ground: There should be battery voltage.Faulty under-dash fuse/relay box
Q11 GRN Hazard warning switch ON Measure the voltage to ground:
There should be battery voltage. Blown No. 23 (10 A) fuse in the
under-hood fuse/relay box
Faulty hazard warning switch
An open in the wire
S18 ·
S5 BRN
·
BLK Turn signal switch in
right position
Measure the voltage between
terminals S18 and S5:
There should be less than 0.5 V. Faulty combination light switch
An open in the wire
Turn signal switch in
left or neutral
position Measure the voltage between
terminals S18 and S5:
There should be 5 V or more. Faulty combination light switch
A short to ground in the wire
S19 ·
S5 LT
GRN ·
BLK Turn signal switch in
left position
Measure the voltage between
terminals S19 and S5:
There should be less than 0.5 V. Faulty combination light switch
An open in the wire
Turn signal switch in
right or neutral
position Measure the voltage between
terminals S19 and S5:
There should be 5 V or more. Faulty combination light switch
A short to ground in the wire
08/08/21 14:27:44 61SNR030_220_0193
ProCarManuals.com
DYNOMITE -2009-
Page 2142 of 2893

(#'
)
(#'
)
22-19222-192 Turn Signal/Hazard Warning Lights
Hazard Warning Switch Test/
Replacement
Side Turn Signal Light Replacement
A
A
Terminal
Position 12
4
5
OFF ON A
A
B
1. Remove the center panel. With audio:– ’06-08 models (see page 23-80)
– ’09 model (see page 23-256)
With navigation: – ’06-08 models (see page 23-155)
– ’09 model (see page 23-355)
2. Remove the screws and the hazard warning switch (A).
3. Check for continuity between the terminals in each switch position according to the table.
4. If the continuity is not as specified, replace the bulb (A) or the hazard warning switch.
5. Install the hazard warning switch in the reverse order of removal. 1. Remove the mirror holder (see page 20-34).
2. Remove the four screws and the mirror visor (A).
3. Disconnect the 2P connector (A) from the side turn
signal light (B), then remove the side turn signal
light.
4. Install the side turn signal light in the reverse order of removal.
08/08/21 14:27:45 61SNR030_220_0194
ProCarManuals.com
DYNOMITE -2009-
Page 2143 of 2893
Î
(#')
22-193
Interior Lights
Component Location Index
TRUNK LIGHT
FRONT INDIVIDUAL MAP LIGHTS
AMBIENT LIGHT
INTERIOR LIGHT SWITCH*
TRUNK LID LATCH SWITCH
GLOVE BOX LIGHT
MICU
(Built into the under-
dash fuse/relay box) CEILING LIGHT
DRIVER’S DOOR
COURTESY LIGHT FRONT PASSENGER’S
DOOR COURTESY LIGHT
*1: With moonroof
*2: ’08-09 models
*3: TYPE S model FRONT PASSENGER’S FOOTWELL LIGHT*
DRIVER’S FOOTWELL
LIGHT* DRIVER’S VANITY MIRROR LIGHT* PASSENGER’S VANITY MIRROR LIGHT*
1
3
3 22
Test/Replacement,
page 22-197
Test/Replacement, page 22-196
Test/Replacement, page 22-198
Test/Replacement, page 22-200
Test, page 22-200
Test/Replacement, page 22-199
Input Test,
page 22-204 Test/Replacement, page 22-197
Replacement, page 22-198 Replacement, page 22-198
Test/Replacement, page 22-201
Test/Replacement, page 22-201
Test/Replacement, page 22-199 Test/Replacement, page 22-199
08/08/21 14:27:48 61SNR030_220_0195
ProCarManuals.com
DYNOMITE -2009-
Page 2144 of 2893

Î(#')
22-194Interior Lights
Circuit Diagram
D A
B
A C
GRNMICU
UNDER-DASH FUSE/RELAY BOX
GRNE37 E3
LT GRN BRNE17 E2
GRYK4
(8 W) (8 W)
1
(Without moonroof)
LT BLU
PNKDOOR
OFF
PNK
BLU
3
LT BLU LT BLU
LT BLU
(With moonroof)
1
2
(8 W) (8 W)
PNK 1
ON OFF
(8 W) RED
UNDER-HOOD FUSE/RELAY BOX
No. 22 (7.5 A)
No. 1 (BAT) (100 A)
BATTERY
CEILING
LIGHT
INTERIOR
LIGHT SWITCH
(In the moonroof
switch)
RIGHT REAR
DOOR
SWITCH
(Closed:
Door open)
LEFT REAR
DOOR
SWITCH
(Closed:
Door open)
FRONT
PASSENGER’S
DOOR SWITCH
(Closed:
Door open)
DRIVER’S
DOOR
SWITCH
(Closed:
Door open) D2
1 1
1
9*2 8*1
1*1
7*2 LT BLU
LT BLU
FRONT
PASSENGER’S
DOOR
COURTESY
LIGHT LT BLU
VANITY
MIRROR
LIGHTS *2
No. 22 (7.5 A)FUSE
(UNDER-HOOD
FUSE/RELAY BOX) LT BLU
GRN (3.4 W)
DRIVER’S
DOOR
COURTESY
LIGHT
GRN1 No. 22 (7.5 A)FUSE
(UNDER-HOOD
FUSE/RELAY BOX)
LT GRN
GRN (3.4 W)
FRONT
PASSENGER’S
DOOR
COURTESY
LIGHT BLU
BLK 3
2
G701 E36
BLU TRUNK LID
LATCH
SWITCH
(Closed:
Trunk lid open)BLU
TRUNK
LIGHT
FRONT
INDIVIDUAL
MAP LIGHTS
FRONT
INDIVIDUAL
MAP LIGHTS
08/08/21 14:27:49 61SNR030_220_0196
