Page 2369 of 2893

ACURA CSX 2006 Service Repair Manual Î
(#

)

(#

!)
23-8723-87
AM/FM Antenna Amplifier
Replacement AM/FM Antenna Repair
A
B
C
B A
A
1

Page 2370 of 2893

ACURA CSX 2006 Service Repair Manual
(##

)
’08 model with navigation
23-88Audio System
XM Antenna Replacement
A
B
C
1. Remove the headliner (see page 20-84).
2. Remove the nut (A) from t

Page 2371 of 2893

ACURA CSX 2006 Service Repair Manual Î
(##
)
23-89
Navigation System
Component Location Index
GPS ANTENNA
MICROPHONE
(Inside the map light)
NAVIGATION UNIT
ECM/PCM
(Vehicle Speed Pulse)
V

Page 2372 of 2893

ACURA CSX 2006 Service Repair Manual (##
)
General Operation
Anti-theft Feature
Symptom DiagnosisSelf-Inertial Navigation Limitations
23-90Navigation System
General Troubleshooting Information

(#'#
)
General Operation
Anti-theft Feature
Symptom DiagnosisSelf-Inertial Navigation Limitations
23-90Navigation System
General Troubleshooting Information
Refer to the Navigation System manual for the
navigation system operating procedures.
The navigation system has a coded theft protection
circuit. Be sure you have the client’s anti-theft security
code before;
Disconnecting the battery
Disconnecting the navigation unit A (17P) and C (12P) connector
Removing the No. 23 (10 A) fuse from the under-hood fuse/relay box
After service, reconnect power to the navigation unit,
and turn the ignition switch ON (II). Enter the 4-digit
anti-theft security codes, then select Done.
If the code cannot be found, use the interactive Network
(iN) to look it up. You can view the serial number in one
of the Navi ECU diagnostic screen (see page 23-139).
Alternatively, you can find the serial number from the
navigation unit in the dash.
When replacing the navigation unit, be sure to give the
client the new anti-theft security code.
Certain circumstances and system limitations can result
in occasional vehicle positioning errors. Some clients
may think this indicates a problem with the navigation
system when, in fact, the system is normal. Keep the
following items in mind when interviewing clients
about symptoms of the navigation system. The limitations of the self-inertial portion of the
navigation system (the yaw rate sensor and the vehicle
speed signal) can cause some discrepancies between
the vehicle’s actual position and the indicated vehicle
position (GPS vehicle position).
The following circumstances may cause vehicle
positioning errors:
Moving the vehicle with the engine stopped and the vehicle stopped, such as by ferry or tow truck, or if
the vehicle is spun on a turn table.
Tire slippage, changes in tire rolling diameters, and some driving situations may cause discrepancies in
travel distances. Examples of this include:
– Continuous tire slippage on a slippery surface.
– Driving with snow chains mounted.
– Abnormal tire pressure.
– Incorrect tire size.
– Frequent lane changes across a wide highway.
– Continuous driving on a straight or gently curving highway.
Tolerances in the system and map inaccuracies will sometimes limit how precisely the vehicle position is
indicated. Examples of this include:
– Driving on roads not shown on the map (map matching is not possible).
– Driving on a road that winds in one direction, such as a loop bridge, an interchange, or a spiral parking
garage.
– Driving on a road with a series of sharp hair-pin turns.
– Driving near a gradual highway exit or transition.
– Driving on one of two close parallel roads.
– Making many 90 degree turns.
– The direction to destination icon or the destination icon shown or the map may be up to several
hundred feet away from the actual location.
