Page 1705 of 2893

ACURA CSX 2006 Service Repair Manual    Rear door 20-30 Doors Front and Rear Door Position Adjustment (cont’d) F 8x1.25mm 29 N·m (3.0 kgf·m, 22 lbf·ft) E 8x1.25mm 29 N·m (3.0 kgf·m, 22 lbf·ft) A A B C E 8x1.25mm 29N·m(3.0k

Page 1706 of 2893

ACURA CSX 2006 Service Repair Manual   (#       ")  20-31 Front and Rear Door Striker Adjustment B 8x1.25mm 18 N·m (1.8 kgf·m, 13 lbf·ft) A C Make sure the door latches securely without slamming

Page 1707 of 2893

ACURA CSX 2006 Service Repair Manual Î  Î (#          )  20-32Mirrors Component Location Index MIRROR HOLDER POWER MIRROR REARVIEW MIRROR Replacement, page 20-34 Replacement, page 20-33 Repla

Page 1708 of 2893

ACURA CSX 2006 Service Repair Manual      (#        )  20-33 Power Mirror Replacement B A Fastener Locations :Nut,3 6x1.0mm 9.8 N·m (1.0 kgf·m, 7.2 lbf·ft)A A B C 1. Raise the door glass

Page 1709 of 2893

ACURA CSX 2006 Service Repair Manual      (#        )  20-34 Mirrors Mirror Holder Replacement A B C A B C D E C E F A B C B A B C A C CB A A B C NO GOOD OK NOTE: Put on gloves to protect yo

Page 1710 of 2893

ACURA CSX 2006 Service Repair Manual    (#       )  20-35 Rearview Mirror Replacement A A B C 1. Turn the rearview mirror base (A) 90 °. 2. Slide the rearview mirror (A) down toward thebottom

Page 1711 of 2893

ACURA CSX 2006 Service Repair Manual Î  Î (#          )  20-36Glass Component Location Index CLIP, 2 UPPER RUBBER DAM WINDSHIELD WINDSHIELD MOLDING MOLDING UPPER SEAL SIDE RUBBER DAM LOWER RU

Page 1712 of 2893

ACURA CSX 2006 Service Repair Manual Î  20-37 UPPER RUBBER DAMREAR WINDOW CLIP, 2 (Self-adhesive-type, glass side) SIDE RUBBER DAM, 2 LOWERRUBBERDAM SIDE FASTENER, 2 (Self-adhesive-type, body side) SIDE FASTENER, 2 (Self-adhesive-ty
