2006 ACURA CSX Service Repair Manual

jump cable warning light headlight aiming towing capacity brake manual radio set

Page 2777 of 2893

ACURA CSX 2006 Service Repair Manual
(#

-)
µ
µ µ
µ
YES
NO Special Tools Required
YES
NO
DTC 31-9x (‘‘x’’ can be 0 thru 9 or A thru F):
24-9724-97
FLOOR WIRE HARNESS
2P CON

(#'
'
-)
µ
µ µ
µ
YES
NO Special Tools Required
YES
NO
DTC 31-9x (‘‘x’’ can be 0 thru 9 or A thru F):
24-9724-97
FLOOR WIRE HARNESS
2P CONNECTOR 070AZ-SNAA300 A
9. Turn the ignition switch to LOCK (0). Disconnect thenegative cable from the battery, then wait at least 3
minutes.
10. Disconnect both seat belt buckle tensioner connectors (see step 8 on page 24-21) and both
seat belt tensioner connectors (see step 7 on page
24-21).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 9 on page 24-21).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the floor wire harness 2P connector.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch to ON (II).
15. Measure the voltage between each terminal of the black SRS simulator lead (A) and body ground.
There should be less than 0.2 V.
Faulty SRS unit or poor connection at SRS
unit connector B (28P) and the SRS unit. Check the
connection; if the connection is OK, replace the
SRS unit (see page 24-203).
Short to power in the floor wire harness;
replace the floor wire harness, then clear the
DTC. SRS inflator simulator 07SAZ-TB4011A
SRS simulator lead L 070AZ-SNAA300
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshooting the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
(cont’d)
Short to Ground in the Driver’s Side Airbag
Inflator
Is the voltage as specif ied? Does the SRS indicator stay on, and is DT C 31-9x
indicated?
08/08/21 13:58:18 61SNR030_240_0097
ProCarManuals.com
DYNOMITE -2009-

Page 2778 of 2893

ACURA CSX 2006 Service Repair Manual

µ
µ
µ
µ
YES
NO
YES
NO
24-98SRS
DTC Troubleshooting (cont’d)
A B
070AZ-SNAA300 07SAZ-TB4011A
FLOOR WIRE HARNESS
2P CONNECTOR
070AZ-SNAA300 A
4. Disconnect the floor wire harness 2P c

Page 2779 of 2893

ACURA CSX 2006 Service Repair Manual
(#

-)
µ
µ
µ
µ
DTC 32-1x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO YES
NO
24-99
A
B
070AZ-SNAA300
07SAZ-TB4011

Page 2780 of 2893

ACURA CSX 2006 Service Repair Manual
(#
-)
µ
µ µ
µ
YES
NO Special Tools Required
YES
NO
DTC 32-3x (‘‘x’’ can be 0 thru 9 or A thru F):
24-10024-100SRS
DTC Troubleshooting

(#'
'-)
µ
µ µ
µ
YES
NO Special Tools Required
YES
NO
DTC 32-3x (‘‘x’’ can be 0 thru 9 or A thru F):
24-10024-100SRS
DTC Troubleshooting (cont’d)
FLOOR WIRE HARNESS
2P CONNECTOR
070AZ-SNAA300 A
9. Turn the ignition switch to LOCK (0). Disconnect thenegative cable from the battery, then wait at least 3
minutes.
10. Disconnect both seat belt buckle tensioner connectors (see step 8 on page 24-21) and both
seat belt tensioner connectors (see step 7 on page
24-21).
11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 9 on page 24-21).
12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the floor wire harness 2P connector.
13. Measure the resistance between the terminals of the black SRS simulator lead (A). There should be
less than 1.0 .
Faulty SRS unit or poor connection at SRS
unit connector B (28P) and the SRS unit. Check the
connection; if the connection is OK, replace the
SRS unit (see page 24-203).
Open in the floor wire harness; replace the
floor wire harness, then clear the DTC. SRS inflator simulator 07SAZ-TB4011A
SRS simulator lead L 070AZ-SNAA300
SRS short canceller 070AZ-SAA0100
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
Short to Another Wire or Decreased
Resistance in the Front Passenger’s Side
Airbag Inflator
Is the resistance as specif ied? Does the SRS indicator stay on, and is DT C 32-3x
indicated?
08/08/21 13:58:19 61SNR030_240_0100
ProCarManuals.com
DYNOMITE -2009-

Page 2781 of 2893

ACURA CSX 2006 Service Repair Manual

µ
µ µ
µ
YES
NO YES
NO
24-101
A
B
070AZ-SNAA300
07SAZ-TB4011A FLOOR WIRE HARNESS
2P CONNECTOR
070AZ-SNAA300 A
4. Disconnect the floor wire harness 2P connector (A)from the front passen

Page 2782 of 2893

ACURA CSX 2006 Service Repair Manual
(#
-)
µ
µ
DTC 32-8x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO
24-102SRS
DTC Troubleshooting (cont’d)
A
B
070AZ-

Page 2783 of 2893

ACURA CSX 2006 Service Repair Manual
µ
µ
µ
µ
YES
NO
YES
NO
24-103
FLOOR WIRE HARNESS
2P CONNECTOR070AZ-SNAA300 A
8. Read the DTC (see page 24-22). Go to step 9.
Short to power in the front passenger’s side
airbag inflator;

Page 2784 of 2893

ACURA CSX 2006 Service Repair Manual
(#
-)
µ
µ
DTC 32-9x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO
24-104SRS
DTC Troubleshooting (cont’d)
A
B
070AZ-
