DTC P0325:
11-12611-126PGM-FI System
DTC Troubleshooting (cont’d)
ECM/PCM CONNECTOR C (44P)
KS (RED/BLU)
72. Check for Temporary DTCs or DTCs with the HDS. Check for poor connections or loose
terminals at the ignition coil(s), the injector(s), and
the ECM/PCM. If the ECM/PCM was updated,
substitute a known-good ECM/PCM (see page 11-7),
then go to step 71. If the ECM/PCM was substituted,
go to step 1.
Go to step 73.
73. Monitor the OBD STATUS for DTC P0301, P0302, P0303, or P0304 in the DTCs MENU with the HDS.
If the ECM/PCM was updated,
troubleshooting is complete. If the ECM/PCM was
substituted, replace the original ECM/PCM
(see page 11-228). If any other Temporary DTCs or
DTCs were indicated in step 72, go to the indicated
DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the ignition coil,
the injector, and the ECM/PCM. If the ECM/PCM
was updated, substitute a known-good ECM/PCM
(see page 11-7), then go to step 71. If the ECM/PCM
was substituted, go to step 1. If the screen indicates
EXECUTING, keep driving until a result comes on. If
the screen indicates OUT OF CONDITION, go to
step 71. NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed between 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle.
4. Hold the engine speed between 3,000 4,000 rpm for at least 10 seconds.
5. Check for Temporary DTCs or DTCs with the HDS.
Go to step 6.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the knock sensor and the ECM/PCM.
6. Turn the ignition switch to LOCK (0).
7. Jump the SCS line with the HDS.
8. Disconnect the knock sensor 1P connector (see page 11-223).
9. Disconnect ECM/PCM connector C (44P).
10. Check for continuity between ECM/PCM connector terminal C42 and body ground.Knock Sensor Circuit Malfunction
Terminal side of female terminals
Is DT C P0301, P0302, P0303, or P0304indicated?
Does t he scr een i nd i cat e PASSE D? I s DT C P0325 i nd i cat ed ?
08/08/21 14:18:52 61SNR030_110_0126
ProCarManuals.com
DYNOMITE -2009-
Page 450 of 2893

µ
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
11-127
KNOCK SENSOR 1P CONNECTOR
JUMPER WIRE
KS (RED/BLU)
ECM/PCM CONNECTOR C (44P) KS (RED/BLU)
Repair short in the wire between the ECM/
PCM (C42) and the knock sensor, then go to step 14.
Go to step 11.
11. Connect the knock sensor 1P connector terminal to body ground with a jumper wire.
12. Check for continuity between ECM/PCM connector terminal C42 and body ground.
Go to step 13.
Repair open in the wire between the ECM/
PCM (C42) and the knock sensor, then go to step 14. 13. Replace the knock sensor (see page 11-223).
14. Reconnect all connectors.
15. Turn the ignition switch to ON (II).
16. Reset the ECM/PCM with the HDS.
17. Do the ECM/PCM idle learn procedure (see page
11-310).
18. Hold the engine speed between 3,000 4,000 rpm for at least 10 seconds.
19. Check for Temporary DTCs or DTCs with the HDS.
Go to step 21.
Go to step 20.
20. Monitor the OBD STATUS for DTC P0325 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 19,
go to the indicated DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the knock sensor
and the ECM/PCM, then go to step 1. If the screen
indicates NOT COMPLETED, go to step 18.
(cont’d)
Wire side of female terminals
Terminal side of female terminals
Is there continuity?
Is there continuity? I s DT C P0325 i nd i cat ed ?
Does t he scr een i nd i cat e PASSE D?
08/08/21 14:18:53 61SNR030_110_0127
ProCarManuals.com
DYNOMITE -2009-
Page 451 of 2893

µ
(#'
)
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
DTC P0335:
11-12811-128PGM-FI System
DTC Troubleshooting (cont’d)
CKP SENSOR 3P CONNECTOR
IGP (YEL/BLK)
21. Update the ECM/PCM if it does not have the latestsoftware (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
22. Hold the engine speed between 3,000 4,000 rpm for at least 10 seconds.
23. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the knock sensor and the ECM/PCM. If
the ECM/PCM was updated, substitute a known-
good ECM/PCM (see page 11-7), then go to step 22.
If the ECM/PCM was substituted, go to step 1.
Go to step 24.
24. Monitor the OBD STATUS for DTC P0325 in the DTCs MENU with the HDS.
If the ECM/PCM was updated,
troubleshooting is complete. If the ECM/PCM was
substituted, replace the original ECM/PCM
(see page 11-228). If any other Temporary DTCs or
DTCs were indicated in step 23, go to the indicated
DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the knock sensor
and the ECM/PCM. If the ECM/PCM was updated,
substitute a known-good ECM/PCM (see page 11-7),
then go to step 22. If the ECM/PCM was substituted,
go to step 1. If the screen indicates NOT
COMPLETED, go to step 22. NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the CKP sensor and the ECM/PCM.
5. Turn the ignition switch to LOCK (0).
6. Disconnect the CKP sensor 3P connector.
7. Turn the ignition switch to ON (II).
8. Measure the voltage between CKP sensor 3P connector terminal No. 3 and body ground.
Go to step 9.
Repair open in the wire between the CKP
sensor and PGM-FI main relay 1, then go to step 19.CKP Sensor No Signal
Wire side of female terminals
I s DT C P0325 i nd i cat ed ?
Does t he scr een i nd i cat e PASSE D? Is DT C P0335 ind icated ?
Is there battery voltage?
08/08/21 14:18:53 61SNR030_110_0128
ProCarManuals.com
DYNOMITE -2009-
Page 452 of 2893

µ
µ
µ
µ µ
µ
YES
NO
YES
NO YES
NO
11-129
CKP SENSOR 3P CONNECTOR
CKP (BLU/YEL)
CKP SENSOR 3P CONNECTOR IGP (YEL/BLK)
LG (BRN/YEL) ECM/PCM CONNECTOR C (44P)
CKP (BLU/YEL)
CKP SENSOR 3P CONNECTOR CKP (BLU/YEL)
JUMPER WIRE
9. Measure the voltage between CKP sensor 3Pconnector terminal No. 1 and body ground.
Go to step 10.
Go to step 11.
10. Measure the voltage between CKP sensor 3P connector terminals No. 2 and No. 3.
Go to step 17.
Repair open in the wire between the CKP
sensor and G101; A/T model (see page 22-16), M/T
model (see page 22-18), then go to step 19. 11. Turn the ignition switch to LOCK (0).
12. Jump the SCS line with the HDS.
13. Disconnect ECM/PCM connector C (44P).
14. Check for continuity between ECM/PCM connector
terminal C32 and body ground.
Repair short in the wire between the ECM/
PCM (C32) and the CKP sensor, then go to step 19.
Go to step 15.
15. Connect CKP sensor 3P connector terminal No. 1 to body ground with a jumper wire.
(cont’d)
Wire side of female terminals
Wire side of female terminals Terminal side of female terminals
Wire side of female terminals
Is t her e about 5 V ? Is there battery voltage? Is there continuity?
08/08/21 14:18:54 61SNR030_110_0129
ProCarManuals.com
DYNOMITE -2009-
Page 453 of 2893

µ
µ
µ
µ µ
µ
YES
NO
YES
NO YES
NO
11-130
PGM-FI System
DTC Troubleshooting (cont’d)
ECM/PCM CONNECTOR C (44P)
CKP (BLU/YEL)
16. Check for continuity between ECM/PCM connectorterminal C32 and body ground.
Go to step 26.
Repair open in the wire between the ECM/
PCM (C32) and the CKP sensor, then go to step 19.
17. Turn the ignition switch to LOCK (0).
18. Replace the CKP sensor (see page 11-222).
19. Reconnect all connectors.
20. Turn the ignition switch to ON (II).
21. Reset the ECM/PCM with the HDS.
22. Clear the CKP pattern with the HDS.
23. Do the ECM/PCM idle learn procedure (see page 11-310).
24. Do the CKP pattern learn procedure (see page 11-4).
25. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the CKP sensor and the ECM/PCM,
then go to step 1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting. 26. Reconnect all connectors.
27. Update the ECM/PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
28. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the CKP sensor and the ECM/PCM. If
the ECM/PCM was updated, substitute a known-
good ECM/PCM (see page 11-7), then recheck. If the
ECM/PCM was substituted, go to step 1.
If the ECM/PCM was updated, troubleshooting
is complete. If the ECM/PCM was substituted,
replace the original ECM/PCM (see page 11-228). If
any other Temporary DTCs or DTCs are indicated,
go to the indicated DTC’s troubleshooting.
Terminal side of female terminals
Is there continuity?
Is DT C P0335 ind icated ? Is DT C P0335 ind icated ?
08/08/21 14:18:54 61SNR030_110_0130
ProCarManuals.com
DYNOMITE -2009-
Page 454 of 2893

(#'
)
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
DTC P0339:
YES
NO
YES
NO
YES
NO YES
NO
YES
NO
11-131
CKP Sensor Circuit Intermittent
Interruption
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine, and let it idle for 10 seconds.
4. Check the CKP NOISE in the DATA LIST with the HDS.
Go to step 7.
Go to step 5.
5. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters:
ENGINE S PEED
VSS
6. Check the CKP NOISE in the DATA LIST with the HDS.
Go to step 7.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the CKP sensor and the ECM/PCM.
7. Check for poor connections or loose terminals at these locations:
CKP sensor
ECM/PCM
Engine ground
Body ground
Go to step 8.
Repair or replace the connections or the
terminals, then go to step 11. 8. Remove the cam chain case (see step 13 on page
6-19), then check for damage on the CKP sensor
pulser plate.
Replace the CKP sensor pulser plate
(see page 6-34), then go to step 11.
Go to step 9.
9. Turn the ignition switch to LOCK (0).
10. Replace the CKP sensor (see page 11-222).
11. Turn the ignition switch to ON (II).
12. Reset the ECM/PCM with the HDS.
13. Clear the CKP pattern with the HDS.
14. Do the ECM/PCM idle learn procedure (see page 11-310).
15. Do the CKP pattern learn procedure (see page 11-4).
16. Start the engine, and let it idle for 10 seconds.
17. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the CKP sensor and the ECM/PCM,
then go to step 1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Ar e 0 counts indicated?
Ar e 0 counts indicated?
Ar e t he connect i ons and t er mi nal s OK ? Is the pulser plate damaged?
Is DT C P0339 ind icated ?
08/08/21 14:18:54 61SNR030_110_0131
ProCarManuals.com
DYNOMITE -2009-
Page 455 of 2893

(#'
)
µ
µ
µ
µ µ
µ
µ
µ
DTC P0365:
YES
NO
YES
NO YES
NO
YES
NO
11-132PGM-FI System
DTC Troubleshooting (cont’d)
CMP SENSOR B 3P CONNECTOR
IGP (YEL/BLK) CMPB (GRN)
CMP SENSOR B 3P CONNECTOR
IGP
(YEL/BLK)
LG
(BRN/YEL)
CMP SENSOR B 3P CONNECTOR
CMP Sensor B No Signal
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at CMP sensor B and the ECM/PCM.
5. Turn the ignition switch to LOCK (0).
6. Disconnect the CMP sensor B 3P connector.
7. Turn the ignition switch to ON (II).
8. Measure the voltage between CMP sensor B 3P connector terminal No. 3 and body ground.
Go to step 9.
Repair open in the wire between CMP sensor
BandPGM-FImainrelay1,thengotostep18. 9. Measure the voltage between CMP sensor B 3P
connector terminal No. 1 and body ground.
Go to step 10.
Go to step 11.
10. Measure the voltage between CMP sensor 3P connector terminals No. 2 and No. 3.
Go to step 16.
Repair open in the wire between CMP sensor
B and G101; A/T model (see page 22-16), M/T
model (see page 22-18), then go to step 18.
Wire side of female terminals Wire side of female terminals
Wire side of female terminals
I s DT C P0365 i nd i cat ed ?
Is there battery voltage? Is t her e about 5 V ?
Is there battery voltage?
08/08/21 14:18:55 61SNR030_110_0132
ProCarManuals.com
DYNOMITE -2009-
Page 456 of 2893
µ
µ µ
µ
YES
NO YES
NO
11-133
ECM/PCM CONNECTOR C (44P)
CMPB (GRN) CMPB (GRN)
ECM/PCM CONNECTOR C (44P)
CMPB (GRN)
CMP SENSOR B 3P CONNECTOR
11. Turn the ignition switch to LOCK (0).
12. Jump the SCS line with the HDS.
13. Disconnect ECM/PCM connector C (44P).
14. Check for continuity between ECM/PCM connector
terminal C31 and body ground.
Repair short in the wire between the ECM/
PCM (C31) and CMP sensor B, then go to step 18.
Go to step 15. 15. Check for continuity between CMP sensor B 3P
connector terminal No. 1 and ECM/PCM connector
terminal C31.
Go to step 23.
Repair open in the wire between the ECM/
PCM (C31) and CMP sensor B, then go to step 18.
(cont’d)
Terminal side of female terminals Wire side of female terminals
Terminal side of female terminals
Is there continuity? Is there continuity?
08/08/21 14:18:55 61SNR030_110_0133
ProCarManuals.com
DYNOMITE -2009-
