11-158PGM-FI System
DTC Troubleshooting (cont’d)
ECM/PCM CONNECTOR C (44P)
AFS (RED/YEL)
AFS (RED)
A/F SENSOR (SENSOR 1) 4P CONNECTOR AFS (RED)JUMPER WIRE ECM/PCM CONNECTOR C (44P)
AFS (RED)
10. Check for continuity between ECM/PCM connectorterminals C29 and C30.
Go to step 14.
Go to step 11.
11. Remove the jumper wire from the A/F sensor (Sensor 1) 4P connector.
12. Connect A/F sensor (Sensor 1) 4P connector terminal No. 2 to body ground with a jumper wire. 13. Check for continuity between ECM/PCM connector
terminal C29 and body ground.
Repair open in the wire between the ECM/
PCM (C30) and the A/F sensor (Sensor 1), then go to
step 15.
Repair open in the wire between the ECM/
PCM (C29) and the A/F sensor (Sensor 1), then go to
step 15.
14. Replace the A/F sensor (Sensor 1) (see page 11-221).
15. Reconnect all connectors.
16. Turn the ignition switch to ON (II).
17. Reset the ECM/PCM with the HDS.
18. Do the ECM/PCM idle learn procedure (see page 11-310).
19. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the A/F sensor (Sensor 1) and the ECM/
PCM, then go to step 1. If the connections and the
terminal fits are OK, go to step 21.
Go to step 20.
Terminal side of female terminals
Terminal side of male terminals Terminal side of female terminals
I s t her e cont i nui t y ?
I s t her e cont i nui t y ?
I s DT C P115 7 i nd i cat ed ?
08/08/21 14:20:23 61SNR030_110_0158
ProCarManuals.com
DYNOMITE -2009-
