Type S model Front Door Speaker
23-25923-259
Stereo Amplifier Removal/
Installation
Speaker Replacement
A
CB AB
C
B
1. Slide the driver’s front seat forward fully.
2. Remove the amp cover (A), then disconnect the connectors (B).
3. Remove the mounting bolts, then remove the stereo amplifier (C).
4. Install the stereo amplifier in the reverse order of removal. 1. Remove the front door panel (see page 20-7).
2. Remove the screw. Then lift the speaker (A) straight
up to release the lower clips (B).
3. Disconnect the 2P connector (C), and remove the speaker.
4. Install the speaker in the reverse order of removal.
(cont’d)
08/08/21 14:14:17 61SNR030_230_0262
ProCarManuals.com
DYNOMITE -2009-
Page 2546 of 2893
Î
Tweeter
Rear Speaker
23-260Audio System
Speaker Replacement (cont’d)
A
B
A A
A
C
B
1. Carefully pry the tweeter grille (A) out of the
dashboard. Be careful not to damage the tweeter
grille and the dashboard.
2. Disconnect the 2P connector (B) from the tweeter.
3. Remove the tweeter (A) from the speaker grille.
4. Install the tweeter in the reverse order of removal. 1. Remove the rear speaker grille (A).
2. Remove the screw. Then lift the speaker (A) straight
up to release the clips (B).
3. Disconnect the 2P connector (C), and remove the speaker.
4. Install the speaker in the reverse order of removal.
08/08/21 14:14:18 61SNR030_230_0263
ProCarManuals.com
DYNOMITE -2009-
Page 2547 of 2893
Î
(#'
)
Subwoofer (Type S model)
23-26123-261
Auxiliary Jack Assembly
Replacement
A
B A
B
1. Remove the rear tray (see page 20-78).
2. Remove the four mounting bolts from the
subwoofer (A).
3. Disconnect the 2P connector (B), and remove the subwoofer.
4. Install the subwoofer in the reverse order of removal. 1. With navigation: Remove the navigation unit
(see page 23-355).
Without navigation: Remove the audio unit
(see page 23-256).
2. Carefully pull out the auxiliary jack assembly (A), then disconnect the 5P connector (B).
3. Install the auxiliary jack assembly in the reverse order of removal.
08/08/21 14:14:18 61SNR030_230_0264
ProCarManuals.com
DYNOMITE -2009-
Page 2548 of 2893

Î
(#'
)
´
µ
Û
Ý
(#'
) Position Resistance
23-26223-262Audio System
USB Adapter Replacement
Audio Remote Switch Test
B
C
D
A
A
B
1. Remove the center console (see page 20-92).
2. Detach the USB adapter cable (A) from the clip.
Remove the cover (B) and disconnect the USB
adapter cable connector (C).
3. Carefully pull out the USB adapter holder (D) from the center console box.
4. Install the USB adapter in the reverse order of removal. SRS components are located in this area. Review the
SRS component location (see page 24-11).
Also review the precautions and procedures (see page
24-13) in the SRS section before doing repairs or
service.
1. Remove the driver’s airbag assembly (see page 24-188).
2. Remove the 20P connector (A) from the cable reel (B).
3. Measure the resistance between terminals No. 9 andNo.10ineachswitchpositionaccordingtothe
table.
No buttonpressed About 10 k
MODE About 3.7 k
CH ( ) About 1.7 k
CH ( ) About 775
(VOL.UP) About 357
(VOL.DOWN) About 100
4. If the resistance is not as specified, replace the audio remote switch (see page 23-263).
08/08/21 14:14:18 61SNR030_230_0265
ProCarManuals.com
DYNOMITE -2009-
Page 2549 of 2893
(#'
)Î
(#'
)
23-26323-263
Audio Remote Switch Replacement AM/FM Antenna Amplifier Replacement
A
B
SRS components are located in this area. Review the
SRS component location (see page 24-11).
Also review the precautions and procedures (see page
24-13) in the SRS section before doing repairs or
service. 1. Remove the steering wheel (see page 17-6).
2. Remove the audio remote switch (see page 17-7).
3. Install the audio remote switch in the reverse order of removal. 1. Remove the right side C-pillar trim (see page 20-75).
2. Disconnect the connectors (A) from the AM/FM
antenna amplifier (B).
3. Remove the bolt and AM/FM antenna amplifier.
4. Install the unit in the reverse order of removal.
08/08/21 14:14:19 61SNR030_230_0266
ProCarManuals.com
DYNOMITE -2009-
Page 2550 of 2893

Î
(#'#
) Î
Î
(#'
!)
23-26423-264 Audio System
XM Antenna Replacement
AM/FM Antenna Repair
AB
C C
B A
A
1. Remove the headliner (see page 20-84).
2. Remove the nut (A) from the XM antenna (B).
3. Disconnect the connector (C) and remove the XMantenna.
4. Install the antenna in the reverse order of removal. NOTE: To make an effective repair, the broken section
must not be longer than one inch.
1. Lightly rub the area around the broken section (A) with fine steel wool, then clean it with alcohol.
2. Carefully mask above and below the broken portion of the window antenna wire (B) with cellophane
tape (C).
3. Mix the silver conductive paint thoroughly. Using a small brush, apply a heavy coat of paint (A)
extending about 1/8’’ on both sides of the break.
Allow 30 minutes to dry.
4. Check for continuity in the repaired wire.
5. Apply a second coat of paint in the same way. Let it dry 3 hours before removing the tape.
08/08/21 14:14:19 61SNR030_230_0267
ProCarManuals.com
DYNOMITE -2009-
Page 2551 of 2893
Î
(#'#
)
23-265
Navigation System
Component Location Index
ECM/PCM
(Vehicle Speed Pulse)
GPS ANTENNA
HFL-NAVIGATION MICROPHONE
(Inside the map light)
NAVIGATION UNIT
HFL-VOICE CONTROL SWITCH CD, DVD, and PC Card
Removal/Installation, page 23-358
Replacement, page 23-358
Removal/Installation, page 23-355
Test, page 23-357
Replacement, page 23-357 Removal/Installation, page 23-354
