Page 2393 of 2893
Diagnostic System Diagram
23-111
This diagram below shows and over view of the navigation diagnostic features starting at the center and working
outward in layers. The diagram starts with Key on. From any of the navigation Map or Menu screens, press and
simultaneously hold the keys Menu, MAP/GUIDE, and Cancel.
Finally, the diagram shows the available diagnostic menu choices, starting at the bottom left, and moving clockwise.
In most cases, do not clear or change settings in any diagnostic screen unless instructed to do so in the explanation, or
by the factory. If the factory asks you to insert a PCMCIA memory card into the PC card Slot, then the features specified
on the diagram with PC card are available.(cont’d)
08/08/21 14:06:29 61SNR030_230_0114
ProCarManuals.com
DYNOMITE -2009-
Page 2394 of 2893
Î
Î
Navigation System Connector Location
23-112Navigation System
System Description (cont’d)
NAVIGATION UNIT
CONNECTOR B (22P)
NAVIGATION UNIT
CONNECTOR H (2P)
NAVIGATION UNIT
CONNECTOR A (17P)
NAVIGATION UNIT
CONNECTOR E (14P) NAVIGATION UNIT
CONNECTOR D (5P)
NAVIGATION UNIT
CONNECTOR F (5P)
NAVIGATION UNIT
CONNECTOR C (12P)
NAVIGATION UNIT
CONNECTOR B (22P)
NAVIGATION UNIT
CONNECTOR A (17P)
NAVIGATION UNIT
CONNECTOR C (12P)
NAVIGATION UNIT
CONNECTOR E (14P)
NAVIGATION UNIT
CONNECTOR D (5P)
NAVIGATION UNIT
CONNECTOR F (5P)
NAVIGATION UNIT
CONNECTOR H (2P)
Wire side of female terminals Wire side of female terminals Wire side of female terminals
Wire side of female terminals Wire side of female terminals Wire side of female terminals
Terminal side of female terminals
08/08/21 14:06:30 61SNR030_230_0115
ProCarManuals.com
DYNOMITE -2009-
Page 2395 of 2893

µ
´µ
´ ´
Î
Navigation Unit Inputs and Outputs for Connector A (17P)
Navigation Unit Connector A (17P) TerminalNumber Wire Color Terminal Name Description Voltage (about) Symptom
23-113
1 RED ILL ( )
Ground for
illumination light With full dash
lights brightness,
0VIf open: When brightness = Auto, night mode for the
display is inoperative when lights on.
If short to ground: No change to display.
9 BLK RADIO GND (Ground)Ground for display
unit 0 V
If open: No change to display.
If short to ground: No change to display.
10 GRY ILL ( ) (Illumination
positive)Parking light on
signal from dash
and console lights Light on =
battery voltage,
Lights off = 0 VIf open: When brightness = Auto, night mode for the
display is inoperative when lights on.
If short to ground: Blows fuse No. 14 (7.5 A) in
under-dash fuse/relay box.
13 BLU VSP (Vehicle speed
pulse)Vehicle speed
pulse signal from
ECM/PCM Pulses 0 5 V:
Average 2.5 V,
when movingIf open: No vehicle speed pulses.
Diagnostic screen Car Status, VSP Navi = 0.
If short to ground: No vehicle speed pulses.
Diagnostic screen Car Status, VSP Navi = 0.
17 WHT B ( B power
source)Continuous power
source
Battery voltage If open: Screen completely off (no backlight visible).
If short to ground: Blows fuse No. 23 (10 A) in the
under-hood fuse/relay box.
(cont’d)
Wire side of female terminals
08/08/21 14:06:30 61SNR030_230_0116
ProCarManuals.com
DYNOMITE -2009-
Page 2396 of 2893

´µ
Î
Navigation Unit Inputs and Outputs for Connector C (12P)
Navigation Unit Connector C (12P)TerminalNumber Wire Color Terminal Name Description Voltage (about) Symptom
23-114Navigation System
System Description (cont’d)
1 WHT B BACK UP Continuous power
sourceBattery voltage If open: Display picture goes out (display back light
still on). NOTE: System will reboot to enter code
screen.
If short to ground: Blows fuse No. 23 (10 A) in the
under-dash fuse/relay box.
4 BLK GND Ground for navigation unit0 V If open: No effect on system.
If short to ground: No effect on system.
7 BRN BACK LT Reverse signal of select laver from
Multiplex
integrated Control
unit (A/T) or
backup light switch
(M/T)In reverse,
battery voltage:
Otherwise0V
If open: Navigation never sees the reverse signal
and back-up camera does not come on when in
reverse. Diagnostic screen Car Status, Back = 0.
If short to ground: Blows fuse No. 10 (7.5 A) in the
under-dash fuse/relay box.
Wire side of female terminals
08/08/21 14:06:30 61SNR030_230_0117
ProCarManuals.com
DYNOMITE -2009-
Page 2397 of 2893

´µµµ
Î
Navigation Unit Inputs and Outputs for Connector D (5P)
Navigation Unit Connector D (5P) TerminalNumber Wire Color Terminal Name Description Voltage (about) Symptom
23-115
1 BRN MIC GND Ground for
microphone signal0 V If open: No microphone signal shown in
diagnostics: Navi System Link and Functional Set
up Mic Level.
If short to ground: No effect on voice recognition.
2 YEL MIC SIG Microphone output signal positive45V(with
navigation TALK
button pressed)If open: No microphone signal shown in diagnostic
screens: Navi System Link and Functional Setup
Mic Level.
If short to ground: No microphone signal shown in
diagnostic screens: Navi System Link and
Functional Setup Mic Level.
3 GRY MIC SH Shield for terminal No.1,2,50 V If open: No effect on voice recognition.
If short to ground: No effect on voice recognition.
4 GRN NAVI GUIDE Steering wheel switch output45V
(navigation TALK
button pressed)
2.5 3 V
(navigation
BACK button
pressed)If open: Steering wheel navigation TALK, and
navigation BACK buttons do not work.
If short to ground: Steering wheel navigation TALK,
and navigation BACK buttons do not work.
5 ORN MIC ADPT Control signal for microphone0 V If open: No effect on voice recognition.
If short to ground: No effect on voice recognition.
: The shielded wires have a heat-shrunk tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic.
(cont’d)
Wire side of female terminals
08/08/21 14:06:30 61SNR030_230_0118
ProCarManuals.com
DYNOMITE -2009-
Page 2398 of 2893
Î
Navigation Unit Inputs and Outputs for Connector F (5P)
Navigation Unit Connector F (5P)TerminalNumber Wire Color Terminal Name Description Voltage (about) Symptom
23-116Navigation System
System Description (cont’d)
2 BLU AC CK
Time set sync
signal 0-battery voltage
pulsesIf open: A/C voice control does not work.
If short to ground: A/C voice control does not work.
3 YEL AC SI A/C input signal 0-battery voltage
pulsesIf open: voice control does not work.
If short to ground: Voice control does not work.
4 RED AC SO A/C output signal 0-battery voltage
pulsesIf open: A/C voice control does not work.
If short to ground: A/C voice control does not work.
Wire side of female terminals
08/08/21 14:06:30 61SNR030_230_0119
ProCarManuals.com
DYNOMITE -2009-
Page 2399 of 2893
•••
•••
Î
Navigation Unit Inputs and Outputs for Connector H (2P)
Navigation Unit Connector H (2P)TerminalNumber Wire Color Terminal Name Description Voltage (about) Symptom
23-117
1
GPSGPS signal
(5 V in, GPS signal
out) 5 V
If open: GPS icon on screen is white, system links
screen ANT shows NG.
If short to ground: GPS icon on screen is white,
system links screen ANT shows NG.
2 GPS SHShield for terminal
No. 1 0 V
If open: GPS icon on screen is white, system links
screen ANT shows NG.
If short to ground: No effect on system.
Terminal side of female terminals
08/08/21 14:06:31 61SNR030_230_0120
ProCarManuals.com
DYNOMITE -2009-
Page 2400 of 2893

(#'#
)
´
µ
´
´
µ
´
´
´
µ
´
µ
23-118 Navigation System
Circuit Diagram
AC CK AC SO AC SI
BLU
BACK-UP LIGHT SWITCH (MT)
K-LINE
MICU
A14
PUR
Q14 Q4
GRNA4 A6
LT BLU
Q8 Q1
WHT
UNDER-DASH FUSE/RELAY BOX
ORN
BRN10
BRN
3 CABLE REEL
B6 D5 ORN 3
A29
2 1
D4 CABLE REEL GRN
RED/BLK
BACKTALK
5
GRY
GRY*
D3 BRN
D1
D2
YEL
GPS
H1
H2 G504
GND
C4
BLK
VSP
BLU
A13
ILL
ILL
F2 F4
RED YEL F3A1
A10
GRY
RED A17
C1 C7
BRN NAVIGATION UNIT
VOICE CONTROL SWITCH
8
GRN 680
10 k
2.2 k
ECM/PCM
(VEHICLE
SPEED SIGNAL)
GPS SH
GND GPS
ANTENNA
MIC SH
GND MIC
GND
MIC
SIG
NA VI
GUIDE
No. 23 (10 A)
FUSE (In the
under-hood
fuse/relay box)
MIC
ADPT
DASH LIGHTS
BRIGHTNESS
CONTROLLER
No. 14 (7.5 A) FUSE
(In the under-dash
fuse/relay box)
No.14(7.5A)FUSE
(In the under-dash
fuse/relay box)
DASH LIGHTS
BRIGHTNESS
CONTROLLER
B
BACK UP BACK
LT
No. 35
(7.5 A)
FUSE B
RADIO
SCTY
RADIO
ACC
RADIO
AUDIO
REMOTE
GND
MULTIPLEX INTEGRATED
CONTROL UNIT (MICU) (AT)
CLIMATE
CONTROL
UNIT G505
RADIO
GND
A9
BLK VSP
GPS
MIC
GND MIC
SIG
MIC
ADPT
E3
BLU
PNK
E9
BUS SH
GND
XM RECEIVER BRN*
BRN*E10
A9
A10
A3
(’08 model) BUS
(GA-NET)
BUS
(GA-NET)
AUDIO
REMOTE
SWITCHBRN
1
2
5
MICROPHONE *1:
: Shielding
This shielded wires have a heat-shrunk tube
insulating the outside of the wire. The color
of the insulating tube, typically black or dark gray,
may not match the color of the wire listed on the
schematic.
G2
BUS SH
GND BUS
(GA-NET)
BUS
(GA-NET) WHT WHT
4
