%)Ref. No. Tool Number Description Qty
18-2
Front and Rear Suspension
Special Tools
07AAA-SVAA100
Strut Nut Adapter 1
07AAF-SDAA100 Ball Joint Thread Protector, 12 mm 1
07AAF-SVAA100 Bushing Driver 1
07AAF-SVAA200 Receiver Set 1
07GAD-SD40101 Attachment, 78 x 90 mm 1
07GAF-SD40100 Hub Dis/AssemblyTool, 42 mm 1
07GAF-SE00100 Hub Dis/AssemblyTool, 40 mm 1
07GAF-SE00200 Attachment, 40 mm 1
07MAC-SL0A102 Ball Joint Remover, 32 mm 1
07MAC-SL0A202 Ball Joint Remover, 28 mm 1
071AF-S3VA000 Ball Joint Thread Protector, 14 mm 1
07746-0010500 Attachment, 62 x 68 mm 1
07749-0010000 Driver Handle 1
07965-SD90100 Support Base 1
,
,,
08/08/21 14:56:39 61SNR030_180_0002
