) Special Tools Required Special Tools Required
Individual Speaker TestSound Balance Test
23-25323-253
Diagnostics CD 07AAZ-SDBA100
Do this test to identify a faulty speaker.
1. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) into the navigation unit or audio unit.
2. Play track No. 30 (steady 300 Hz tone) at a normal, or slightly higher than normal, volume level.
3. Listen to each speaker for poor sound compared to the other speakers. Use the audio unit’s fader and
balance settings to help isolate the channel with the
problem.
If the sound quality produced by a specific speaker is poor, substitute it with a known-good
speaker. If the poor sound quality continues, go
to the sound balance test.
If the sound quality is OK, go to the sound balance test. Diagnostics CD 07AAZ-SDBA100
Perform this test to identify a faulty channel or speaker.
1. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) into the navigation unit or audio unit.
2. Confirm the bass and treble are set to the center positions.
3. Play track No. 3 (pink noise) at a normal, or slightly higher then normal, volume level.
4. A static type sound should be heard through all speakers.
5. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) into the navigation unit or audio unit of a known-
good vehicle.
6. Set the bass and treble to the center position.
7. Play track No. 3 (pink noise) all the same level as wasplayedinstep3.
8. Compare the sounds made by the two vehicles. If the noise sounds made by the two vehicles arevery similar, go to the Frequency Sweep Test
(see page 23-254).
If the sound does not have as much bass, check the subwoofer and circuit.
If the sound does not have enough hiss, check the tweeters and their circuits.
08/08/21 14:14:15 61SNR030_230_0256
ProCarManuals.com
DYNOMITE -2009-
Page 2538 of 2893

(#'
)
(#'
) Special Tools Required Special Tools Required
Frequency sweepSound judging
23-25423-254Audio System
Sound Quality Diagnosis (cont’d)
Diagnostics CD 07AAZ-SDBA100
Do this test to find rattles or reverberation that may
cause a perception of poor sound quality.
1. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) into the navigation unit or audio unit.
2. Play track No. 13 (sweep from 500 Hz to 35 Hz) at a normal, or slightly higher than normal, volume
level.
3. Listen to each speaker for poor sound quality or reverberations caused by specific frequencies. Use
the voice-over to estimate the frequency that
causes the vibration. Use the audio unit’s fader and
balance settings to help isolate the channel with the
problem.
If vibrations or poor sound quality are heard, go to step 4.
If no vibrations or poor sound quality are heard, go to sound judging.
4. Choose the appropriate track from No. 14 to 25 (small range frequency sweep) or 26 to 53 (single
frequencies) to recreate the frequency that caused
the poor sound quality or vibration located in step
3: this aids in diagnosis of the cause.
NOTE: When you get to the track that recreates the
problem, select the repeat function on the
navigation unit or audio unit, this will help you
isolate the cause.
5. Replace or insulate the source of the vibrations or, if the speaker is the source of the poor sound
quality, replace it. Diagnostics CD 07AAZ-SDBA100
Do this test to compare overall sound quality, imaging, and dynamics between the client’s vehicle
and a known-good vehicle. Only use a vehicle of the
same model and trim level for this test.
Make sure the vehicle is using only OEM speakers.
1. In the client’s vehicle, set the bass, treble, fader, and balance settings to the client’s normal settings
that were written down before beginning testing.
2. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) into the navigation unit or audio unit.
3. Play tracks No. 7 to 12 (sound quality, midland, dynamics, and imaging demonstration tracks) at a
normal, or slightly higher than normal, volume
level. Write down the volume setting being used.
4. Listen to areas of the track that stand out as being either very clear, or poorer than other areas of the
track.
5. Insert the diagnostics CD (T/N: 07AAZ-SDBA100) into the navigation unit or audio unit of a known-
good vehicle.
6. Play the tracks at the same volume level and the same bass, treble, balance, and fader settings as
used in step 3 in the client’s vehicle.
7. Listen to the same area of the track that stood out as being either very clear or poorer than other
areas of the track.
08/08/21 14:14:15 61SNR030_230_0257
ProCarManuals.com
DYNOMITE -2009-
Page 2539 of 2893

´
´
´
´
(#'
)
Seek Stop Test
23-25523-255
8. Compare the client’s vehicle’s sound quality results to the known-good vehicle’s results.
If the sound quality in the client’s vehicle is comparable to the sound quality in the known-
good vehicle, then the client’s vehicle is
operating as designed.
If the sound quality is not comparable, check these items in order.
– Loose or improperly installed speakers or other hardware that may become excited by
the vibrations generated by the speakers
– Poor power or ground to the stereo amplifier (Type S model)
– Damaged speaker(s)
– Faulty amplifier
– Faulty navigation unit
– Faulty audio unit Do this test to check the performance of the audio unit’s
AM and FM reception. Refer to symptom
troubleshooting: audio sound weak or distorted, or no
sound is heard from speakers (display is normal)
(see page 23-206) before continuing with this test.
NOTE:
Window tint, aftermarket theft-recovery devices and other aftermarket accessories may reduce radio
reception.
Changes in cloud cover and other atmosphere conditions will affect the ab ility of the navigation unit
or audio unit to receive radio signals.
1. Park the client’s vehicle in an open area away from buildings or other obstructions.
2. Park a known-good vehicle (same year, model, and trim level) next to the client’s vehicle, facing the
same direction.
3. Start the engine in the client’s vehicle, and turn on the radio.
4. Set the FM receiver to 87.7 MHz.
5. Press the Seek button and record the first station that the navigation unit or audio unit locks onto.
6. Press the Seek button repeatedly, and write down each station that the navigation unit or audio
unit locks onto until the station recorded in step 5 is
reached again.
7. Set the AM receiver to 530 kHz.
8. Press the Seek button, and record the first station that the navigation unit or audio unit locks
on to.
9. Press the Seek button repeatedly, and write down each station that the navigation unit or audio
unit locks onto until the station recorded in step 8 is
reached again.
(cont’d)
08/08/21 14:14:15 61SNR030_230_0258
ProCarManuals.com
DYNOMITE -2009-
Page 2540 of 2893

(#'#
)
Without navigation
23-25623-256Audio System
Sound Quality Diagnosis (cont’d) Audio Unit Removal/Installation
10. Turn the ignition switch to LOCK (0).
11. Start the engine in the known-good vehicle, and
then do steps 4 thru 10 on the known-good vehicle.
12. Compare the number of stations received in steps 6 and 9 in the client’s vehicle with the number of
stations received in the known-good vehicle.
If the number of stations received is the same, or within 10 %, the audio unit’s tuner performance
is OK. The problem may be atmospheric
conditions, multi path interference, or other
obstructions to the radio signal.
If the customer’s vehicle receives fewer stations by at least 10 %, go to step 2 of poor AM or FM
radio reception of interference, with navigation
(see page 23-196), wit hout navigation (see page
23-199). SRS components are located in this area. Review the
SRS component location (see page 24-11).
Also review the precautions and procedures (see page
24-13) in the SRS section before doing repairs or
service.
NOTE:
Put on gloves to protect your hands.
Take care not to scratch the dashboard and related parts.
Lay a workshop towel under the parts when working on them to protect the face panel from scratches or
other damage.
Do not work in a dusty or dirty place.
Discharge static electricity from your body before and during the work.
Do not touch the circuit board(s) with your bare hands.
Do not work with dirty hands.
Be careful not to fold the flat plate cable.
Do not touch the terminal connector of the flat plate cable with your bare hands (If you have touched it,
wipe it off thoroughly.).
Eject all the discs before removing the audio unit to prevent damaging the CD/DVD player’s load
mechanism.
If you are replacing the audio unit, write down the audio presets (if possible), and enter them into the
new audio unit.
08/08/21 14:14:16 61SNR030_230_0259
ProCarManuals.com
DYNOMITE -2009-
Page 2541 of 2893

(#'#
)
Without navigation
23-25623-256Audio System
Sound Quality Diagnosis (cont’d) Audio Unit Removal/Installation
10. Turn the ignition switch to LOCK (0).
11. Start the engine in the known-good vehicle, and
then do steps 4 thru 10 on the known-good vehicle.
12. Compare the number of stations received in steps 6 and 9 in the client’s vehicle with the number of
stations received in the known-good vehicle.
If the number of stations received is the same, or within 10 %, the audio unit’s tuner performance
is OK. The problem may be atmospheric
conditions, multi path interference, or other
obstructions to the radio signal.
If the customer’s vehicle receives fewer stations by at least 10 %, go to step 2 of poor AM or FM
radio reception of interference, with navigation
(see page 23-196), wit hout navigation (see page
23-199). SRS components are located in this area. Review the
SRS component location (see page 24-11).
Also review the precautions and procedures (see page
24-13) in the SRS section before doing repairs or
service.
NOTE:
Put on gloves to protect your hands.
Take care not to scratch the dashboard and related parts.
Lay a workshop towel under the parts when working on them to protect the face panel from scratches or
other damage.
Do not work in a dusty or dirty place.
Discharge static electricity from your body before and during the work.
Do not touch the circuit board(s) with your bare hands.
Do not work with dirty hands.
Be careful not to fold the flat plate cable.
Do not touch the terminal connector of the flat plate cable with your bare hands (If you have touched it,
wipe it off thoroughly.).
Eject all the discs before removing the audio unit to prevent damaging the CD/DVD player’s load
mechanism.
If you are replacing the audio unit, write down the audio presets (if possible), and enter them into the
new audio unit.
08/08/21 14:14:16 61SNR030_230_0259
ProCarManuals.com
DYNOMITE -2009-
Page 2542 of 2893
Î
Î
Î
23-257
A
B
B C
A
A
A B
A
C
1. Make sure you have the anti-theft code for the audio system.
2. Remove the subdisplay visor (see page 20- 100).
3. Remove the center pocket hole lid and bolts, then pull out the center panel (A).
4. Disconnect the connectors (B) and the air hose (C), then remove the center panel. 5. Remove the bolts, screws and the brackets (A).
6. Remove the screws, rear covers (A) and the audio
unit (B) from the center panel display (C).
7. Install the audio unit in the reverse order of removal, and note these items:
Make sure all connectors and antenna lead are secure.
Enter the anti-theft code for the audio system, then set the clock.
08/08/21 14:14:16 61SNR030_230_0260
ProCarManuals.com
DYNOMITE -2009-
Page 2543 of 2893
Î
(#'#
)
Î
(#'
)
23-25823-258 Audio System
XM Receiver Removal/Installation USB Adapter Unit Replacement
A
A
B
B
A
A
1. Open the trunk lid and remove the right trunk side
trim panel (see page 20-80).
2. Disconnect connectors (A) from the XM receiver (B).
3. Loosen the three bolts, and remove the XM receiver.
4. Install the XM receiver in the reverse order of removal. 1. Remove the front passenger’s seat (see page
20-118) and pull back the carpet.
2. Disconnect the connectors (A) from the USB adapter unit (B).
3. Remove the bolts and the USB adapter unit.
4. Install the USB adapter unit in the reverse order of removal.
08/08/21 14:14:17 61SNR030_230_0261
ProCarManuals.com
DYNOMITE -2009-
Page 2544 of 2893
Î
(#'#
)
Î
(#'
)
23-25823-258 Audio System
XM Receiver Removal/Installation USB Adapter Unit Replacement
A
A
B
B
A
A
1. Open the trunk lid and remove the right trunk side
trim panel (see page 20-80).
2. Disconnect connectors (A) from the XM receiver (B).
3. Loosen the three bolts, and remove the XM receiver.
4. Install the XM receiver in the reverse order of removal. 1. Remove the front passenger’s seat (see page
20-118) and pull back the carpet.
2. Disconnect the connectors (A) from the USB adapter unit (B).
3. Remove the bolts and the USB adapter unit.
4. Install the USB adapter unit in the reverse order of removal.
08/08/21 14:14:17 61SNR030_230_0261
ProCarManuals.com
DYNOMITE -2009-
