ACURA CSX 2006 Service Repair Manual How to Use the Self-diagnostic Function with the HDS
21-10Climate Control
General Troubleshooting Information (cont’d)
1. Make sure the ignition switch is in LOCK (0).
2. Connect the HDS to the data

Page 1890 of 2893

ACURA CSX 2006 Service Repair Manual

How to Use the Self-diagnostic Function without the HDS
Except Type S model
Type S model
Canceling the Self-diagnostic Function
21-11
AUTO BUTTON AUTO INDICATOR MODE BUTTON
TEMPERATURE INDIC

Page 1891 of 2893

ACURA CSX 2006 Service Repair Manual
Checking for DTCs
DTC
(Temperature Indicator
Segment and AUTO
Indicator) Detection Item
21-12Climate Control
General Troubleshooting Information (cont’d)
AUTO INDICATOR
NM
TEMPERATURE INDICATOR

Checking for DTCs
DTC
(Temperature Indicator
Segment and AUTO
Indicator) Detection Item
21-12Climate Control
General Troubleshooting Information (cont’d)
AUTO INDICATOR
NM
TEMPERATURE INDICATOR
EG C
D
H
P
K
L
F
B A
J
The temperature display indicates single or multiple DTCs. If indicator segments A, C, E, G, J, M, and AUTO are on at
the same time, there may be an open in the common ground wire. If no DTCs are present, the indicator remains blank.
A An open in the in-car temperature sensor circuit (see page 21-31)B A short in the in-car temperature sensor circuit (see page 21-32)
C An open in the outside air temperature sensor circuit (see page 21-33)
D A short in the outside air temperature sensor circuit (see page 21-34) E An open in the sunlight sensor circuit (see page 21-35)F A short in the sunlight sensor circuit (see page 21-36)
G An open in the evaporator temperature sensor circuit (see page 21-37) H A short in the evaporator temperature sensor circuit (see page 21-39) J An open in the air mix control motor circuit (see page 21-40)
K A short in the air mix control motor circuit (see page 21-41) L A problem in the air mix control linkage, door, or motor (see page 21-42)
M An open or short in the mode control motor circuit (see page 21-44) N A problem in the mode control linkage, doors, or motor (see page 21-46) P A problem in the blower motor circuit (see page 21-47)
A and AUTO An open in the recirculation control motor circuit (see page 21-52) B and AUTO A problem in the recirculation control linkage, door, or motor (see page 21-51)
C and AUTO Climate control unit internal error (see page 21-28)
D and AUTO Climate control unit lost communication with gauge control module (TACH) (ILLUMI message) (see page 21-28)
E and AUTO A short in the recirculation control motor circuit (see page 21-29) F and AUTO Climate control unit lost communication with gauge control module (TACH) (ECT message) (see page 21-28)
J and AUTO Climate control unit lost communication with gauge control module (TACH) (VSP message) (see page 21-28)
K and AUTO Communication bus line error (see page 22-106) L and AUTO Climate control unit lost communication with gauge control module (TACH) (NE message) (see page 21-28)
08/08/21 14:40:58 61SNR030_210_0013
ProCarManuals.com
DYNOMITE -2009-

Page 1892 of 2893

ACURA CSX 2006 Service Repair Manual Displaying Sensor Inputs at the Climate Control Unit
Check these items before using the sensor input display mode
To run the sensor input display mode, follow these steps
21-13
The climate control uni

Displaying Sensor Inputs at the Climate Control Unit
Check these items before using the sensor input display mode
To run the sensor input display mode, follow these steps
21-13
The climate control unit has a mode that displays the sensor inputs it receives. This mode shows you what data the
climate control unit is receiving from each of the sensors, one at a time, and it can help you determine if a sensor is
faulty.1. Turn the ignition switch to ON (II), and check the recirculation door function; press the recirculation button to switch from FRESH to RECIRC. The air volume and sound should change slightly.
2. Set the temperature control knob to the desired test temperature. When selecting the test temperature, note these items:
‘‘Lo’’ temperature setting will default to MAX COOL, VENT, and RECIRC.
‘‘Hi’’ temperature setting will default to MAX HOT, FLOOR, and FRESH.
19 through 31 °C settings will use the automatic climate control logic.
3. Turn the ignition switch to LOCK (0).
1. Turn the ignition switch to LOCK (0).
2. Press and hold both the AUTO and MODE buttons, then start the engine.
3. After the engine starts, release both buttons. The display panel will flash the sensor number and then the value for that sensor. Record the value displayed.
4. To advance to the next sensor, press the A/C button. Sensor Item Displayed Value1 Mode Positioning BIT
2 In-car Temperature °C
3 Outside Air Temperature °C
4 Solar Radiation Sensor Value: Dark = 00, Flashlight = 04, Cloudy = 10, Sunny = 65 10 kcal/m ·h
5 Evaporator Outlet Air Temperature °C
6 Air Mix Opening (Low value indicates cooler air distribution, higher value indicates warmer air distribution) % of opening
7 Recirculation Opening % of opening
8 Vehicle Speed (Vehicle must be driven to display speed) km/h
9 Engine Coolant Temperature °C
A Vent Temperature Air Out (TAO) °C
NOTE: The sensor values will be displayed in degrees Celsius (°C) or an alphanumeric code. Use the chart to convert the value to degrees Fahrenheit (°F).
If the sensor value displays ‘‘Er’’ this indicates there is an open or short in the circuit or sensor. Check for DTCs using the HDS, or use the climate control self-diagnostic function.
If necessary, compare the sensor input display to a known-good vehicle under the same test conditions.
If the sensor is out of the normal range, refer to the sensor test or substitute a known-good sensor, and recheck.
5. To cancel the sensor input display mode, press the AUTO button or turn the ignition switch to LOCK (0). (cont’d)
2
08/08/21 14:40:58 61SNR030_210_0014
ProCarManuals.com
DYNOMITE -2009-

Page 1893 of 2893

ACURA CSX 2006 Service Repair Manual µµµµ
µµ µ µµ
µµ µµ µµ
µµ µµ µµ
µµ µµ µµ ••• •••´ ´
Celsius to Fahrenheit Conversion Table
Alphanumeric Conversion Table
Alph

Page 1894 of 2893

ACURA CSX 2006 Service Repair Manual (#
) Checking the DTCs by HDSDTC Detection Item or Symptom ECU DTC type Page
21-15
DTC Troubleshooting Index
B1200 Communication bus line error Climate co

(#'
) Checking the DTCs by HDSDTC Detection Item or Symptom ECU DTC type Page
21-15
DTC Troubleshooting Index
B1200 Communication bus line error Climate control
unit Loss of
communication(see page 22-107)
B1202 Climate control unit internal error Climate control
unit Internal error (see page 21-28)
B1205 Climate control unit lost communication with gauge control module (TACH)
(VSP/NE message) Climate control
unit
Loss of
communication(see page 21-28)
B1206 Climate control unit lost communication with gauge control module (TACH) (ECT
message) Climate control
unit
Loss of
communication(see page 21-28)
B1207 Climate control unit lost communication with gauge control module (TACH)
(ILLUMI message) Climate control
unit
Loss of
communication(see page 21-28)
B1220 A short in the recirculation control motor circuit Climate control
unitSignal error (see page 21-29)
B1225 An open in the in-car temperature sensor circuit Climate control
unitSignal error (see page 21-31)
B1226 A short in the in-car temperature sensor circuit Climate control
unitSignal error (see page 21-32)
B1227 An open in the outside air temperature sensor circuit Climate control
unitSignal error (see page 21-33)
B1228 A short in the outside air temperature sensor circuit Climate control
unitSignal error (see page 21-34)
B1229 An open in the sunlight sensor circuit Climate control unitSignal error (see page 21-35)
B1230 A short in the sunlight sensor circuit Climate control unitSignal error (see page 21-36)
B1231 An open in the evaporator temperature sensor circuit Climate control
unitSignal error (see page 21-37)
B1232 A short in the evaporator temperature sensor circuit Climate control
unitSignal error (see page 21-39)
B1233 An open in the air mix control motor circuit Climate control unitSignal error (see page 21-40)
B1234 A short in the air mix control motor circuit Climate control unitSignal error (see page 21-41)
B1235 A problem in the air mix control linkage, door, or motor Climate control
unitSignal error (see page 21-42)
B1239 An open or short in the mode control motor circuit Climate control
unitSignal error (see page 21-44)
B1240 A problem in the mode control linkage, doors, or motor Climate control
unitSignal error (see page 21-46)
B1241 A problem in the blower motor circuit Climate control unitSignal error (see page 21-47)
B2983 A problem in the recirculation control motor linkage, door, or motor Climate control
unitSignal error (see page 21-51)
B2986 An open in the recirculation control motor circuit Climate control
unitSignal error (see page 21-52)
08/08/21 14:40:58 61SNR030_210_0016
ProCarManuals.com
DYNOMITE -2009-

Page 1895 of 2893

ACURA CSX 2006 Service Repair Manual (#
)
Symptom Diagnostic procedure Also check for
