YES
NO
YES
NO
YES
NO
21-65
BRN
CLIMATE CONTROL UNIT 32P CONNECTOR BRN
CLIMATE CONTROL UNIT 32P CONNECTOR
7. Reconnect the climate control unit 32P connector.
8. Turn the ignition switch to ON (II).
9. Check the blower motor operates at all speeds.
Go to step 10.
Repair the problem in the blower motor
circuit.
10. Turn the ignition switch to LOCK (0).
11. Disconnect the climate control unit 32P connector.
12. Turn the ignition switch to ON (II).
13. Measure the voltage between the climate control unit 32P connector terminal No. 6 and body ground.
Go to step 14.
Go to step 18. 14. Turn the ignition switch to LOCK (0).
15. Reconnect the climate control unit 32P connector.
16. Set the A/C button and fan control switch ON, then
turn the ignition switch to ON (II).
17. Measure the voltage between the climate control unit 32P connector terminal No. 6 and body ground.
Substitute a known-good MICU and recheck.
If the symptom goes away, replace the original
MICU (see page 22-66).
Check for loose wires or poor connections at
the climate control unit 32P connector. If
connections are good, substitute a known-good
climate control unit and recheck. If the symptom/
indication goes away, replace the original climate
control unit.
(cont’d)
Wire side of female terminals Wire side of female terminals
Does t he bl ow er mot or oper at e at al l speed s?
Is there battery voltage? Is t her e 0.5 V or l ess?
08/08/21 14:43:34 61SNR030_210_0066
ProCarManuals.com
DYNOMITE -2009-
Page 1946 of 2893

µ
µ
µ
µ µ
µ
YES
NO
YES
NO YES
NO
21-66Climate Control
A/C Signal Circuit Troubleshooting (cont’d)
A/C COMPRESSOR CLUTCH 3P CONNECTOR
GRN/RED RED/BLK
A/C COMPRESSOR CLUTCH 3P CONNECTOR BRN
CLIMATE CONTROL UNIT 32P CONNECTOR
18. Turn the ignition switch to LOCK (0).
19. Disconnect the A/C compressor clutch 3P connector.
20. Turn the ignition switch to ON (II).
21. Measure the voltage between the A/C compressor
clutch 3P connector terminal No. 1 and body
ground.
Go to step 22.
Repair open in the wire between the A/C
compressor and the MICU. If the wire is OK,
substitute a known-good MICU and recheck. If the
symptom goes away, replace the original MICU
(see page 22-66).
22. Test the A/C compressor thermal protector (see page 21-85).
Go to step 23.
Replace the A/C compressor thermal
protector (see page 21-87). 23. Check for continuity between the climate control
unit 32P connector terminal No. 6 and the A/C
compressor clutch 3P connector terminal No. 3.
Check for loose wires or poor connections at
the climate control unit 32P connector and at the
A/C compressor clutch 3P connector.
Repair open in the wire between the climate
control unit and A/C compressor.
Wire side of female terminals Wire side of female terminalsWire side of female terminals
Is there battery voltage?
I s t he A/ C compr essor t her mal pr ot ect or OK ? Is there continuity?
08/08/21 14:43:34 61SNR030_210_0067
ProCarManuals.com
DYNOMITE -2009-
Page 1947 of 2893

(#'
)
(#'
)
µ
21-6721-67
In-car Temperature Sensor Test In-car Temperature Sensor Replacement
IN-CAR TEMPERATURE SENSOR
10
14 0
32 10
5020
68 30
86
40 °C
104 °F
TEMPERATURE
RESISTANCE
(k )
12
11
10
98
7
6
5
4 3
2
1 A
B
1. Remove the in-car temperature sensor (see page21-67).
2. Test the in-car temperature sensor while holding it in front of the dashboard center vent.
Measure the resistance with the system set to Max Cool.
Measure the resistance with the system set to Max Hot.
3. Compare the resistance reading between terminals No. 1 and No. 2 of the in-car temperature sensor
with the specifications shown in the graph; the
resistance should be within the specifications.
4. If the resistance is not as specified, replace the in-car temperature sensor (see page 21-67). 1. Remove the center panel:
’06-08 models with navigation (see page 23-155)
’06-08 models without navigation (see page23-80)
’09 model with navigation (see page 23-355)
’09 model without navigation (see page 23-256)
2. Remove the self-tapping screw and the in-car temperature sensor (A) from the center panel (B).
3. Install the sensor in the reverse order of removal. Be sure to connect the air hose securely.
08/08/21 14:43:34 61SNR030_210_0068
ProCarManuals.com
DYNOMITE -2009-
Page 1948 of 2893

(#'
)
(#'
)
µ
21-6821-68 Climate Control
Outside Air Temperature Sensor
Test
Outside Air Temperature Sensor
Replacement
OUTSIDE AIR TEMPERATURE SENSOR
10
14 0
32 10
5020
68 30
86
40 °C
104 °F
TEMPERATURE
RESISTANCE
(k )
12
11
10
98
7
6
5
4 3
2 1 A
B C
1. Remove the outside air temperature sensor
(see page 21-68).
2. Dip the sensor in ice water, and measure the resistance. Then pour warm water on the sensor,
and check for a change in resistance.
3. Compare the resistance reading between terminals No. 1 and No. 2 of the outside air temperature
sensor with the specifications shown in the graph;
the resistance should be within the specifications.
4. If the resistance is not as specified, replace the outside air temperature sensor (see page 21-68). 1. Remove the front grille cover (see page 20-163).
2. Lift the tab (A) to release the lock, then remove the
outside air temperature sensor (B) from the bracket.
Disconnect the 2P connector (C) from the outside
air temperature sensor.
3. Install the sensor in the reverse order of removal.
08/08/21 14:43:35 61SNR030_210_0069
ProCarManuals.com
DYNOMITE -2009-
Page 1949 of 2893

´
µ
µ
µ
(#'
)
(#'
)
21-6921-69
Sunlight Sensor Test Sunlight Sensor Replacement
REDPUR
A
A
B
1. Remove the sunlight sensor (A) from thedashboard (see page 21-69).
2. Turn the ignition switch to ON (II). Measure the voltage between the terminals with the ( ) probe
on terminal No. 2 and the ( ) probe on terminal
No. 1 with the connector connected.
NOTE: The voltage readings will not change under
the light of a flashlight or a fluorescent lamp.
Voltage should be: 3.6 3.7 V or more with the sensor out of direct sunlight.
3.3 3.5 V or less with the sensor in direct sunlight.
3. If the voltage is not as specified, replace the sunlight sensor (see page 21-69). 1. Remove the gauge control module (SPEEDO)
(see page 22-277).
2. Remove the sunlight sensor (A) from the dashboard with a flat-tip screwdriver, then
disconnect the connector (B). Be careful not to
damage the sensor and the dashboard.
3. Install the sensor in the reverse order of removal.
08/08/21 14:43:35 61SNR030_210_0070
ProCarManuals.com
DYNOMITE -2009-
Page 1950 of 2893
(#'
)
21-70 Climate Control
Evaporator Temperature Sensor Test
EVAPORATOR TEMPERATURE SENSOR
40
30
20
10
RESISTANCE
(k )
10
5020
6830 °C
86 °F
TEMPERATURE
0
32
1. Remove the evaporator core and the evaporator
temperature sensor (see page 21-78).
2. Dip the sensor in ice water, and measure the resistance between its terminals.
3. Then pour warm water on the sensor, and check for a change in resistance. 4. Compare the resistance readings with the
specifications shown in the graph; the resistance
should be within the specifications.
5. If the resistance is not as specified, replace the evaporator temperature sensor (see page 21-78).
Terminal side of male terminals
08/08/21 14:43:36 61SNR030_210_0071
ProCarManuals.com
DYNOMITE -2009-
Page 1951 of 2893

(#'
)
21-71
Power Transistor Test
POWER TRANSISTOR (To 12 V Power source on vehicle)JUMPER WIRE
A
1. Remove the passenger’s dashboard undercover
(see page 20-104).
2. Disconnect the 4P connector from the power transistor.
3. Measure the resistance between terminals No. 3 and No. 4 of the power transistor. It should be
about 1.5 k .
If the resistance is within the specifications, go to step 4.
If the resistance is not within the specifications, replace the power transistor.
NOTE: Also check the blower motor. Power
transistor failure can be caused by a defective
blower motor. 4. Carefully release the lock tab on terminal No. 1
(YEL) (A) in the 4P connector, then remove the
terminal and insulate it from body ground.
5. Reconnect the 4P connector to the power transistor.
6. Make sure the YEL wire is completely isolated, then supply 12 V to cavity No. 1 with a jumper wire.
7. Turn the ignition switch to ON (II), and check that the blower motor runs.
If the blower motor does not run, replace the power transistor.
NOTE: A faulty blower motor can cause the
power transistor to fail. If the power transistor is
replaced, also check the blower motor for
binding, and replace it if necessary.
If the blower motor runs, the power transistor is OK.
08/08/21 14:43:36 61SNR030_210_0072
ProCarManuals.com
DYNOMITE -2009-
Page 1952 of 2893

(#'
)
(#'
)
Max Cool: About 0.5 V
Max Hot: About 4.5 V
21-7221-72 Climate Control
Air Mix Control Motor Test
Air Mix Control Motor Replacement
AIR MIX CONTROL MOTOR
B
A
NOTE: Before testing, check for HVAC DTCs (see page
21-9). 1. Disconnect the 7P connector from the air mix control motor.
Incorrectly applying power and ground to
the air mix control motor will damage it.
Follow the instructions carefully.
2. Connect battery power to terminal No. 1 of the air mix control motor, and ground terminal No. 2; the
air mix control motor should run, and stop at Max
Hot. If it doesn’t, reverse the connections; the air
mix control motor should run, and stop at Max Cool.
When the air mix control motor stops running,
disconnect battery power immediately.
3. If the air mix control motor did not run in step 2, remove it, then check the air mix control linkage
and door for smooth movement.
If the linkage and door move smoothly, replace the air mix control motor (see page 21-72).
If the linkage or door sticks or binds, repair them as needed.
If the air mix control motor runs smoothly, go to step 4.
4. Measure the resistance between terminals No. 5 and No. 7. It should be between 4.2 to 7.8 k .
5. Reconnect the air mix control motor 7P connector, then turn the ignition switch to ON (II).
6. Using the backprobe set, measure the voltage between terminals No. 3 and No. 7.
7. If either the resistance or voltage readings are not as specified, replace the air mix control motor
(see page 21-72). 1. Remove the driver’s dashboard undercover
(see page 20-103).
2. Disconnect the 7P connector (A) from the air mix control motor (B). Remove the self-tapping screws
and the air mix control motor from the heater unit.
3. Install the motor in the reverse order of removal. Make sure the pin on the motor is properly
engaged with the linkage. After installation, make
sure the motor runs smoothly.
08/08/21 14:43:37 61SNR030_210_0073
ProCarManuals.com
