ACURA CSX 2006 Service Repair Manual SWS DTC IndexSRS Unit DTC SWS DTC Detection Item Notes
24-33
Only read DTCs from the SRS menu, not from the SWS menus unless instructed to check SWS DTCs. SWS (ODS unit)
DTCs are subcodes of SRS unit

SWS DTC IndexSRS Unit DTC SWS DTC Detection Item Notes
24-33
Only read DTCs from the SRS menu, not from the SWS menus unless instructed to check SWS DTCs. SWS (ODS unit)
DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs.
81-4x 41-xx Internal failure of the ODS unit (see page 24-178) 42-xx
43-xx
82-14 14-11 Short to power in the front passenger’s weight sensor (front inner side) power circuit (see page 24-179)
14-12 Short to ground in the front passenger’s weight sensor (front inner side) power circuit
14-13 Open in the front passenger’s weight sensor (front inner side) output circuit
14-14 Short to ground in the front passenger’s weight sensor (front inner side) output circuit
82-15 15-3x Internal failure of the front passenger’s weight sensor (front inner side) (see page 24-181)
82-16 16-11 Short to power in the front passenger’s weight sensor (rear inner side) power circuit (see page 24-179)
16-12 Short to ground in the front passenger’s weight sensor (rear inner side) power circuit
16-13 Open in the front passenger’s weight sensor (rear inner side) output circuit
16-14 Short to ground in the front passenger’s weight sensor (rear inner side) output circuit
82-17 17-3x Internal failure of the front passenger’s weight sensor (rear inner side) (see page 24-181)
83-24 24-11 Short to power in the front passenger’s weight sensor (front outer side) power circuit (see page 24-180)
24-12 Short to ground in the front passenger’s weight sensor (front outer side) power circuit
24-13 Open in the front passenger’s weight sensor (front outer side) output circuit
24-14 Short to ground in the front passenger’s weight sensor (front outer side) output circuit
83-25 25-3x Internal failure of the front passenger’s weight sensor (front outer side) (see page 24-181)
83-26 26-11 Short to power in the front passenger’s weight sensor (rear outer side) power circuit (see page 24-180)
26-12 Short to ground in the front passenger’s weight sensor (rear outer side) power circuit
26-13 Open in the front passenger’s weight sensor (rear outer side) output circuit
26-14 Short to ground in the front passenger’s weight sensor (rear outer side) output circuit
83-27 27-3x Internal failure of the front passenger’s weight sensor (rear outer side) (see page 24-181)
81-71 71-xx ODS unit does not calibrate (see page 24-178)
NOTE: The ‘‘x’’ at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that you will see on the HDS display. The character is unrelated to your troubleshooting; it designates the SRS unit
manufacturer and other detail used for product analysis.
08/08/21 13:55:32 61SNR030_240_0033
ProCarManuals.com
DYNOMITE -2009-

Page 2714 of 2893

ACURA CSX 2006 Service Repair Manual (#)
Symptom Diagnostic procedure Also check for
24-34
SRS
Symptom Troubleshooting Index

SRS indicator does not come on Symptom Troubleshoo

Page 2715 of 2893

ACURA CSX 2006 Service Repair Manual
(#)
SRS Components
Airbags
Front Passenger’s Weight Sensors
Driver’s Seat Position Sensor
24-35
System Description
AB
C
D
EF
M
E
I G J
F
L
L
G
H

(#')
SRS Components
Airbags
Front Passenger’s Weight Sensors
Driver’s Seat Position Sensor
24-35
System Description
AB
C
D
EF
M
E
I G J
F
L
L
G
H
O N
The SRS is a safety device which, when used with the seat belt, is designed to help protect the driver and front
passenger in a frontal impact exceeding a certain set limit. The system consists of the SRS unit, including safing
sensor and impact sensor (A), the cable reel (B), the driver’s airbag (C), the front passenger’s airbag (D), side airbags
(E), side curtain airbags (F), seat belt tensioners (G), seat belt buckle tensioners (H), side impact sensors (first) (I), front
impact sensors (J), rear safing sensor (K) and side impact sensors (second) (L).
Since the driver’s and front passenger’s airbags use the same sensors, both normally inflate at the same time.
However, it is possible for only one airbag to inflate. This can occur when collision severity is near the threshold for
airbag deployment. In such cases, the SRS system will only deploy airbags when the protection provided by the seat
belt is insufficient.
The front passenger’s weight sensors (M) are part of seat base. The front passenger’s weight sensors detect the
weight on the seat, and send the information to the ODS unit (N). If the total weight is about 30 kg (65 lbs) or less, the
ODS unit sends a signal to the SRS unit to prevent the passenger’s airbag from deploying. When the passenger’s
airbag is disabled, the passenger airbag cutoff indicator on the center panel comes on to alert the driver that the front
passenger’s airbag will not deploy in a front-end collision.
The driver’s seat position sensor (O) is under the driver’s seat on the left side. When the driver’s seat is moved to its
full forward position, the deployment of the driver’s airbag is moderated to decrease its force of impact during a front-
end collision.
(cont’d)
08/08/21 13:55:33 61SNR030_240_0035
ProCarManuals.com
DYNOMITE -2009-

Page 2716 of 2893

ACURA CSX 2006 Service Repair Manual Rear Safing Sensor
For the SRS to operate:
Seat Belt Tensioners and Seat Belt Buckle Tensioners
Driver’s and Front Passenger’s Airbag(s)
Side Airbag(s)
Side Curtain Airbag(s)
Side Airbag Cutoff In

Rear Safing Sensor
For the SRS to operate:
Seat Belt Tensioners and Seat Belt Buckle Tensioners
Driver’s and Front Passenger’s Airbag(s)
Side Airbag(s)
Side Curtain Airbag(s)
Side Airbag Cutoff Indicator/OPDS Operation
Passenger Airbag Cutoff Indicator
SRS Operation
24-36SRS
System Description (cont’d)
The rear safing sensor is located under the rear seat. The rear safing sensor performs the same basic function as the
safing sensor in the SRS unit. It measures sideways G force, such as the force the vehicle would receive in a side
collision in the rear, and sends that information to the SRS unit. The SRS unit uses that information, and the
information from the second side impact sensors to determine the side that is impacted and the force. If the threshold
is met, the SRS unit deploys the side airbag, the side curtain airbag, and the seat belt tensioner on that side.
The indicator comes on when the front passenger’s seat is occupied by a small adult or child who is leaning into the
deployment path, or when an object (grocery bag, briefcase, purse, etc.) is in the seat. This indicates the passenger’s
side airbag is off and will not deploy; there is no problem with the side airbag. If the passenger sits upright or moves
to another seat, or you remove the object from the seat, the light should go off. There will be some delay between the
occupant’s repositioning and when the indicator will turn on or off.
The indicator comes on if the weight on the front passenger’s seat is about 30 kg (65 lbs) or less. This indicates the
passenger’s front airbag is off and will not deploy. The front airbag is shut off to reduce the chance of airbag-caused
injuries.
The main circuit in the SRS unit senses and analyzes the force of impact and, if necessary, ignites the inflator charges.
If battery voltage is too low or power is disconnected due to the impact, the voltage regulator and the back-up power
circuit will keep voltage at a constant level.
(1) A front impact sensor, side impact sensor, or the rear safing sensor must activate and send electric signals to the
microprocessor.
(2) The microprocessor must compute the signals and trigger the tensioners.
(3) The charges must ignite and deploy the tensioners.
(1) A front impact sensor must activate and send electric signals to the microprocessor.
(2) The microprocessor must compute the signals and trigger the airbag inflator(s).
(3) The triggered inflators must ignite and deploy the airbags.
(1) A side impact sensor must activate and send electric signals to the microprocessor.
(2) The microprocessor must compute the signals and trigger the side airbag inflator(s). However, the microprocessor
does not trigger the front passenger’s side airbag if the SRS unit determines that the front passenger’s head is in the
deployment path of the side airbag.
(3) The inflator that receives the signal must ignite and deploy the side airbags.
(1) A side impact sensor or the rear safing sensor must activate, and send electrical signals to the microprocessor.
(2) The microprocessor must compute the signals and trigger the side curtain airbag and side airbag inflator(s).
(3) The triggered inflators must ignite and deploy the side curtain airbag and side airbag at the same time.
08/08/21 13:55:33 61SNR030_240_0036
ProCarManuals.com
DYNOMITE -2009-

Page 2717 of 2893

ACURA CSX 2006 Service Repair Manual
µ
´
Self-diagnostic System
24-37
GAUGE CONTROL MODULE CAN
CAN
MICROPROCESSOR and DIAGNOSTIC CIRCUIT
SRS UNIT
IMPACT GND TRIGGER CIRCUIT
SCS
MES
DLC
VA VB
ODS UNIT
FRONT
PASSENGER’S SEAT
OPD

µ
´
Self-diagnostic System
24-37
GAUGE CONTROL MODULE CAN
CAN
MICROPROCESSOR and DIAGNOSTIC CIRCUIT
SRS UNIT
IMPACT GND TRIGGER CIRCUIT
SCS
MES
DLC
VA VB
ODS UNIT
FRONT
PASSENGER’S SEAT
OPDS
SENSOR RIGHT
SIDE IMPACT
SENSOR
(SECOND)
REAR
SAFING
SENSOR
FRONT
PASSENGER’S
SEAT BELT
BUCKLE
TENSIONER
CABLE
REEL
DRIVER’S
AIRBAG
FIRST
INFLATOR
DRIVER’S
AIRBAG
SECOND
INFLATOR FRONT
PASSENGER’S
AIRBAG
SECOND
INFLATOR
FRONT
PASSENGER’S
AIRBAG
FIRST
INFLATOR
SRS
INDICATOR
SIDE AIRBAG
CUTOFF
INDICATOR
DRIVER’S
SEAT BELT
BUCKLE
TENSIONER
FRONT
PASSENGER’S
SEAT BELT
TENSIONER
DRIVER’S
SEAT BELT
TENSIONER
RIGHT SIDE
CURTAIN
AIRBAG
INFLATOR
LEFT SIDE
CURTAIN
AIRBAG
INFLATOR
DATA
LINK
CIRCUIT
MEMORY
CIRCUIT
SIDE
IMPACT
SENSOR FRONT
IMPACT
SENSOR POWER
SUPPLY
CIRCUIT LEFT
FRONT
IMPACT
SENSOR
RIGHT
FRONT
IMPACT
SENSOR LEFT
SIDE IMPACT
SENSOR
(FIRST)
RIGHT
SIDE IMPACT
SENSOR
(FIRST)DRIVER’S
SIDE AIRBAG
INFLATOR
FRONT
PASSENGER’S
SIDE AIRBAG
INFLATOR
UNDER-DASH
FUSE/RELAY
BOX LEFT
SIDE IMPACT
SENSOR
(SECOND)
FRONT
PASSENGER’S
WEIGHT
SENSORS
FRONT
PASSENGER’S
AIRBAG
CUTOFF
INDICATOR
DRIVER’S SEAT
POSITION
SENSOR
A self-diagnostic circuit is built into the SRS unit; when the ignition switch is turned to ON (II), the SRS indicator comes
on and goes off after about 6 seconds if the system is operating normally.
If the indicator does not come on, or does not go off after 6 seconds, or comes on while driving, it indicates an
abnormality in the system. The system must be inspected and repaired as soon as possible.
For better serviceability, the SRS unit memory stores a DTCs related to the cause of the malfunction, and the unit is
connected to the data link connector (DLC). This information can be read with the HDS when it is connected to the DLC
(see page 24-22).
NOTE: Before you disconnect the negative cable from battery for troubleshooting, review Battery Terminal
Disconnection and Reconnection (see page 22-68).
(cont’d)
08/08/21 13:55:34 61SNR030_240_0037
ProCarManuals.com
DYNOMITE -2009-

Page 2718 of 2893

ACURA CSX 2006 Service Repair Manual ´
µ´
µ
´
µ ´
µ
µ µ
´ ´

SRS Unit Inputs and Outputs at Connector A (28P)
Terminal
Number Wire Color Terminal Name Description
24-38SRS
System Description (cont’d)
1 GRN
L

Page 2719 of 2893

ACURA CSX 2006 Service Repair Manual ´
µ´
µ
µ
´ ´
µ´
µ
´
µ´
µ ´
µ´
µ
´
µ
´
µ

SRS Unit Inputs and Outputs at Connector B (28P)
Terminal
Number Wire Color Terminal Name Description
24-39
1 R

´
µ´
µ
µ
´ ´
µ´
µ
´
µ´
µ ´
µ´
µ
´
µ
´
µ

SRS Unit Inputs and Outputs at Connector B (28P)
Terminal
Number Wire Color Terminal Name Description
24-39
1 RED
LRPPower source for the driver’s seat belt tensioner
2 BRN LRPGround for the driver’s seat belt tensioner
3 GRN RRPPower source for the front passenger’s seat belt tensioner
4 LT BLU RRPGround for the front passenger’s seat belt tensioner
5 GRY SSGround for the driver’s seat position sensor
6 LT GRN SSPower source for the driver’s seat position sensor
7 ORN LBPPower source for the driver’s buckle tensioner
8 GRN LBPGround for the driver’s buckle tensioner
9 YEL RBPPower source for the front passenger’s buckle tensioner
10 WHT RBPGround for the front passenger’s buckle tensioner
11 YEL LBSC Driver’s seat belt buckle switch un-buckled signal
12 LT GRN LBSO Driver’s seat belt buckle switch buckled signal
15 BLU RBSC Front passenger’s seat belt buckle switch un-buckled signal
16 ORN RBSO Front passenger’s seat belt buckle switch buckled signal
17 GRN LSAPower source for the driver’s side airbag inflator
18 RED LSAGround for the driver’s side airbag inflator
19 WHT RSAPower source for the front passenger’s side airbag inflator
20 BLU RSAGround for the front passenger’s side airbag inflator
21 BRN LCA1Power source for the left side curtain airbag inflator
22 BLU LCA1Ground for the left side curtain airbag inflator
23 GRY RCA1Power source for the right side curtain airbag inflator
24 RED RCA1Ground for the right side curtain airbag inflator
25 PNK LBS1Power source for the left side impact sensor (first), left side
impact sensor (second), and rear safing sensor
26 BLU LBS1Ground for the left side impact sensor (first), left side impact
sensor (second), and rear safing sensor
27 BRN RBS1Power source for the right side impact sensor (first), right side
impact sensor (second)
28 YEL RBS1Ground for the right side impact sensor (first), right side impact
sensor (second)
NOTE: BLU or BRN wires may be substituted for the wire colors in this table.
Wire side of female terminals
08/08/21 13:55:34 61SNR030_240_0039
ProCarManuals.com
DYNOMITE -2009-

Page 2720 of 2893

ACURA CSX 2006 Service Repair Manual Î(#) ’06 model
24-40SRS
Circuit Diagram
GRN
BLU YEL
214 Q
E
G504
G602
BLK
LT GRN*
BLK*
BLK*
ORN*
LT BLU*
WHT*
RED* BLU*RED*
YEL*
2 1
G506 5
22
23

Load next 8 pages

Page: < prev 1-10 ... 2681-2688 2689-2696 2697-2704 2705-2712 2713-2720 2721-2728 2729-2736 2737-2744 2745-2752 ... 2896 next >

night vision jacking points check engine climate settings engine oil manual radio set
