ACURA CSX 2006 Service Repair Manual Î
22-299
DRIVER’S SEAT HEATER SWITCHFRONT PASSENGER’S SEAT HEATER SWITCH
Test/Replacement, page 22-302 Test/Replacement, page 22-302
08/08/21 14:36:48 61SNR030_220_0301
ProCarManuals.com
DYN

Page 2250 of 2893

ACURA CSX 2006 Service Repair Manual Î(#"
)
22-300Seat Heaters
Circuit Diagram
Q16
IG2 HOT in ON (II) G19 C3
M5
LT GRN
GRN/RED LT GRN
OFF 1
2
GRN/RED LT GRN
6
5
3
BLU
BLK HIGH
LOW
4
LT B

Page 2251 of 2893

ACURA CSX 2006 Service Repair Manual Î
µ
µ
¦µ µ §
¦µ µ§
¦µ µ§ ¦µ µ§
22-301
GRN/REDRED
OFF 3
BLU
RED
BLK
ORN
BRN
BLU/YEL
TH
BR2
1
CUSHION
BLKBLK
FRONT PASSENGER’S SEAT HEATER
LT GRN GRY
LT BLU5

Page 2252 of 2893

ACURA CSX 2006 Service Repair Manual
(#"

)
(#"

)
¦§¦§¦§¦§¦§¦§
¦§
Driver’s
22-30222-302 Seat Heaters
Swi

Page 2253 of 2893

ACURA CSX 2006 Service Repair Manual Î

Front Passenger’s
22-303
SEAT-CUSHION HEATER 3P CONNECTOR
SEAT-BACK HEATER 2P CONNECTOR A
4. Reconnect the 2P connector.
5. Check for continuity between seat-cushion heater
3P connector

Page 2254 of 2893

ACURA CSX 2006 Service Repair Manual Î
Î(#
)
22-304Power Mirrors
Component Location Index
POWER MIRRORS/
POWER MIRROR DEFOGGERS
POWERMIRRORSWITCH
POWER MIRROR
DEFOGGER RELAY
UNDER

Page 2255 of 2893

ACURA CSX 2006 Service Repair Manual
(#
)
22-305
Circuit Diagram
C3 N11
G12
DEFOGGER
DEFOGGER 4
6
ORN
BRN
BRNBRN
G503 G502
PUR
PNK BLK PURBLUBLK1
6
8
1
6
8 2
7
2
7
GRN
ORN ORN
WHT
BLK
G50

Page 2256 of 2893

ACURA CSX 2006 Service Repair Manual Î
(#
)
Both mirrors Left mirror
Right mirror
Defogger
22-306Power Mirrors
Function Test
BLK
WHTGRN
WHTPNK BLU PUR
BRN
BLK
A
B
1. Remove the power win

Î
(#'
)
Both mirrors Left mirror
Right mirror
Defogger
22-306Power Mirrors
Function Test
BLK
WHTGRN
WHTPNK BLU PUR
BRN
BLK
A
B
1. Remove the power window master switch (A).
2. Disconnect the 13P connector (B) from the powermirror switch.
3. Choose the appropriate test based on the symptom:
Both mirrors don’t work, go to step 4.
Leftmirrordoesn’twork,gotostep6.
Right mirror doesn’t work, go to step 7.
4. Measure the voltage between terminal No. 2 and body ground with the ignition switch turned to ON
(II).
There should be battery voltage.
If there is no voltage, check for: – Blown No. 36 (10 A) fuse in the under-dash fuse/relay box.
– AnopenintheBRNwire.
If there is battery voltage, go to step 5.
5. Check for continuity between terminal No. 6 and body ground. There should be continuity.
If there is no continuity, check for: – AnopenintheBLKwire.
– Poor ground (G 503).
If there is continuity, check both mirrors individually as described in the next steps. 6. Connect terminals No. 2 and No. 10, and terminals
No. 5 (or No. 12) and No. 6 with jumper wires.
The left mirror should tilt down (or swing left) with
the ignition switch to ON (II).
If the left mirror does not tilt down (or does not swing left), check for an open in the PUR (or PNK)
wire between the left mirror and the 13P
connector.
If the wire is OK, check the left mirror actuator.
If the mirror neither tilts down nor swings left, repair the GRN wire.
If the mirror works properly, check the mirror switch.
7. Connect terminals No. 2 and No. 11, and terminals No. 5 (or No. 13) and No. 6 with jumper wires. The
right mirror should tilt down (or swing left) with the
ignition switch to ON (II).
If the mirror does not tilt down (or does not swing left), check for an open in the PUR (or BLU) wire
between the right mirror and the 13P connector.
If the wire is OK, check the right mirror actuator.
If the mirror neither tilts down nor swings left, repair the WHT wire.
If the mirror works properly, check the mirror switch.
8. Connect the power mirror defogger relay terminals No. 1 and No. 2 in the under-hood fuse/relay box
with a jumper wire, and measure the voltage
between mirror connectors terminal No. 1 and
body ground. There should be battery voltage and
both mirrors should warm up with the ignition
switch to ON (II). If there is no voltage or neither warms up, check for:
– AnopenintheORNwire.
– Blown No. 36 (10 A) fuse in the under-dash fuse/relay box.
If only one fails to warm up, check: – Its defogger.
– Poor ground (G 503).
If both warm up, check the defogger switch.
Wire side of female terminals
08/08/21 14:36:52 61SNR030_220_0308
ProCarManuals.com
