Page 1833 of 2893

ACURA CSX 2006 Service Repair Manual       (#        )  20-149 Rear Bumper Removal/Installation 6x1.0mm 9.8 N·m (1.0 kgf·m, 7.2 lbf·ft) A B C D E C B D A C C C C Fastener Locations :Clip,2

Page 1834 of 2893

ACURA CSX 2006 Service Repair Manual     20-150Bumpers Rear Bumper Removal/Installation (cont’d) A B C A B C B 4. With the help of an assistant, pull the rear bumper (A) to release the bumper from the hooks (B) on the upper brack

Page 1835 of 2893

ACURA CSX 2006 Service Repair Manual   (#        )  20-151 Rear Bumper Lower Cover Replacement Fastener Locations: Clip, 2 A B C D D NOTE: Take care not to scratch the rear bumper. 1. Remove the re

Page 1836 of 2893

ACURA CSX 2006 Service Repair Manual   (#        ")  20-152Hood Hood Adjustment B C D E A 6x1.0mm 18 N·m (1.8 kgf·m, 13 lbf·ft) A 6x1.0mm 9.8 N·m (1.0 kgf·m, 7.2 lbf·ft) D 1. Remove these item

Page 1837 of 2893

ACURA CSX 2006 Service Repair Manual      (#      )  20-15320-153 Hood Seal Replacement Fastener Locations : Clip, 7 A B B 6. Check that the hood opens properly and closes securely. 7. App

Page 1838 of 2893

ACURA CSX 2006 Service Repair Manual      (#      )  20-15320-153 Hood Seal Replacement Fastener Locations : Clip, 7 A B B 6. Check that the hood opens properly and closes securely. 7. App

Page 1839 of 2893

ACURA CSX 2006 Service Repair Manual   (#       )  20-154Hood Hood Insulator Replacement Fastener Locations :Clip,7 AB 1. Detach the clips with a clip remover. Release the hooks (A), then remove t

Page 1840 of 2893

ACURA CSX 2006 Service Repair Manual   (#        ")  20-155 Trunk Lid Trunk Lid Adjustment A B C D G H E 6x1.0mm 18 N·m (1.8 kgf·m, 13 lbf·ft) E 6x1.0mm 9.8 N·m (1.0 kgf·m, 7.2 lbf·ft) H F F 1
